- Page 1 Business Solutions User Manual EAP1200H version 1.0 Dual Band AC1200 Indoor Access Point Ceiling Mount Design...
- Page 2 IMPORTANT To install this Access Point please refer to the Quick Installation Guide included in the product packaging.
-
Page 3: Table Of Contents
Considerations for Wireless Installation......11 WPS (Wi-Fi Protected Setup)..........43 Computer Settings..............12 WDS Link Settings............... 44 Hardware Installation..............15 Mounting the EAP1200H............. 16 Chapter 8 Management............45 Administration................46 Chapter 3 Configuring Your Access Point......18 Management VLAN Settings..........47 Default Settings................ -
Page 4: Chapter 1 Product Overview
Chapter 1 Product Overview... -
Page 5: Key Features/Introduction
Features and specifications subject to change without notice. Trademarks and registered trademarks are the property of their respective owners. For United States of America: Copyright © 2015 EnGenius Technologies, Inc. All rights reserved. -
Page 6: System Requirements / Package Contents
The EAP1200H supports the 2.4 GHz frequency band under System Requirements the 802.11b/g/n mode while at the same time providing a The following are the Minimum System Requirements in 5 GHz band for communicating or transferring files in a less order configure the device: congested network frequency band. • Computer with an Ethernet interface or wireless network capability The EAP1200H also delivers faster wireless speeds • Windows OS (XP, Vista, 7, 8), Mac OS, or Linux-based operating compared to modern 802.11a/b/g/n wireless devices. Even systems though the EAP1200H has been designed and engineered •... -
Page 7: Applications
• Small Office and Home Office (SOHO) Networks: SOHO users require a cost-effective, easy, and quick installation of a small network. • Wireless Extensions to Existing Ethernet-based Networks: Devices like the EAP1200H enable network administrators, installers, and end-users to extend the range and reach of an existing Ethernet-based network. -
Page 8: Technical Specifications
Technical Specifications Security Standard: WEP (64/128bit) IEEE802.11b/g/n on 2.4 GHz WPA/WPA2 (TKIP/AES) IEEE 802.11ac/a on 5 GHz Hidden ESSID IEEE802.3at MAC address filtering, up to 50 fields Antenna L2 Isolation Four Internal 5 dBi Omni-Directional Antennas 802.1X Authenticator (MD5/TLS/TTLS/PEAP) Guest Network Physical Interface 1 x 10/100/1000 Gigabit Ethernet Port QoS (Quality of Service) 1 x Reset Button WMM (Wireless Multimedia) 1 x Power Connector Physical/Environment Conditions LED Indicator Operating: Power Temperature: 32°F to 104°F (0°C to 40°C) -
Page 9: Physical Interface
5 Ceiling (Wall) Mount Hole: Using the provided hardware, the 2 LED Indicators: LED lights for WPS, WLAN 5G, WLAN 2.4G, EAP1200H can be attached to a ceiling or wall. Ethernet port, and Power 6 Kensington Security Slot: To protect your EAP1200H, use the 3 LAN Port (802.3at PoE): Ethernet port for RJ-45 cable. -
Page 10: Chapter 2 Before You Begin
Chapter 2 Before You Begin... -
Page 11: Considerations For Wireless Installation
The operating distance of all wireless devices can often maximize the Access Point’s performance. Avoid placing not be pre-determined due to a number of unknown the EAP1200H in an enclosed space such as a closet, obstacles in the environment in which the device is cabinet, or stairwell. deployed. Obstacles such as the number, thickness, and location of walls, ceilings, or other objects that the EAP1200H’s wireless signals must pass through can... -
Page 12: Computer Settings
Computer Settings Windows XP/Windows 7/Windows 8 1b. In Windows 8, move your mouse to the lower right hot corner to display the Charms Bar and select the Control In order to use the EAP1200H, you must first configure the Panel. TCP/IPv4 connection of your Windows OS computer system. 1a. In Windows XP and Windows 7, click the Start button and open the Control Panel. Windows 8 2a. In Windows XP, click on Network Connections. - Page 13 3. Right click on Local Area Connection and select Properties. 5. Select Use the following IP address and enter an IP address that is different from the EAP1200H and Subnet mask, then click OK. Note: Ensure that the IP address and Subnet mask are on the same subnet as the device.
- Page 14 Apple Mac OS X 4. In Configure IPv4, select Manually. 1. Go to System Preferences (it can be opened in the 5. Enter an IP address that is different from the EAP1200H Applications folder or by electing it in the Apple Menu). and Subnet mask, then click OK.
-
Page 15: Hardware Installation
EAP1200H and the computer. 3. Connect the Power Adapter DC connector to the DC-IN port of the EAP1200H and the Power Adapter to an available electrical outlet. Once both connections are secure, verify the following: a) Ensure that the POWER light is on (it will be orange). -
Page 16: Mounting The Eap1200H
If extra space is required, use the provided spacers and long To attach the EAP1200H to a ceiling or wall screws from the T-Rail mounting hardware kit to increase using the mounting bracket: the space between the unit and the mounting bracket. - Page 17 Attaching the EAP1200H to a ceiling using the provided T-Rail connectors: 1. Attach the T-Rail connectors to the bottom cover of the 2. Line up the connected T-Rail connectors with an EAP1200H using the provided short screws. appropriately sized rail and press the unit onto the rail until it snaps into place.
-
Page 18: Chapter 3 Configuring Your Access Point
Chapter 3 Configuring Your Access Point... -
Page 19: Default Settings
IP Address 192.168.1.1 Username/Password admin/admin Web Configuration 1. Open a web browser (Internet Explorer/Firefox/Safari) 3. If successful, you will be logged in and see the and enter the IP Address http://192.168.1.1. EAP1200H User Menu. Note: If you have changed the default LAN IP Address of the Access Point, ensure you enter the correct IP Address. -
Page 20: Chapter 4 Building A Wireless Network
Chapter 4 Building a Wireless Network... -
Page 21: Access Point Mode
The EAP1200H has the ability to operate in various modes. This chapter describes the operating modes of the EAP1200H. Access Point Mode In Access Point Mode, the EAP1200H behaves like a central connection for stations or clients that support IEEE 802.11ac/a/b/ g/n networks. The stations and clients must be configured to use the same SSID (Service Set Identifier) and security password to associate with the EAP1200H. The EAP1200H supports up to eight (8) SSIDs per band (16 total) at the same time for secure access. 2.4 GHz 5 GHz Client Client EAP1200H AP/AP Client Client Client Client... -
Page 22: Wds Ap Mode
WDS AP Mode The EAP1200H also supports WDS AP mode. This operating mode allows wireless connections to the EAP1200H using WDS technology. In this mode, configure the MAC addresses in both Access Points to enlarge the wireless area by enabling WDS Link settings. WDS supports up to four (4) AP MAC addresses. 5 GHz 5 GHz Client Client Computer Computer 2.4 GHz... -
Page 23: Wds Bridge Mode
WDS Bridge Mode In WDS Bridge Mode, the EAP1200H can wirelessly connect different LANs by configuring the MAC address and security settings of each EAP1200H device. Use this mode when two wired LANs located a small distance apart want to communicate with each other. The best solution is to use the EAP1200H to wirelessly connect two wired LANs, as shown in the following figure. WDS Bridge Mode can establish up to four (4) WDS links, creating a star-like network. Note: WDS Bridge Mode does not act as an Access Point because Access Points linked by WDS use the same frequency channel. More Access Points connected together may lower throughput. This configuration can also be susceptible... -
Page 24: Chapter 5 Overview
Chapter 5 Overview... -
Page 25: Overview
Basic link shows wireless information such mode. as Operating Mode, Frequency, and Channel. Since the The Device Status section shows general system • EAP1200H supports multiple-SSIDs, information about information such as Device Name, MAC address, Current each SSID and security settings are displayed. Time, Firmware Version, and Management VLAN ID Note: Profile Settings is only applicable in Access Point Note: VLAN ID is only applicable in Access Point or WDS... -
Page 26: Connections
Connections The EAP1200H automatically logs (records) events of possible interest in its internal memory. To view the logged information, click the Connections link under the Device Status menu. If there is not enough internal memory to log all events, older events are deleted from the log. When powered down or rebooted, the log will be cleared. Click Refresh to refresh the Connections List page. -
Page 27: Chapter 6 Network
Chapter 6 Network... -
Page 28: Device Settings
Operation Modes Operation Mode: Use the radio button to select an operating mode. The EAP1200H supports three operating modes: Band Steering: Enable Band Steering to sends 802.11n Access Point, WDS AP, and WDS Bridge. clients to the 5 GHz band, where 802.11b/g clients cannot go, and leaves the 802.11b/g clients in 2.4 GHz to Device Settings operate at their slower rates. Band Steering works within the Access Point by directing 5 GHz-capable clients to that band. -
Page 29: Ip Settings/Spanningtree Settings
IP Network Settings Select whether the device IP address will use the static IP address specified in the IP Address field or be obtained automatically when the device connects to a DHCP server. IP Address: The IP Address of this device. Spanning Tree Status: Enables or disables the Spanning IP Subnet Mask: The IP Subnet mask of this device. Tree function. - Page 30 Forward Delay: Specifes Bridge Forward Delay, in seconds. Forwarding Delay Time is the time spent in each of the Listening and Learning states before the Forwarding state is entered. This delay is provided so that when a new bridge comes onto a busy network, it analyzes data traffic before participating. Priority: Specify the Priority Number. A smaller number has greater priority.
-
Page 31: Chapter 7 Wireless
Chapter 7 2.4GHz & 5GHz Wireless... -
Page 32: Wireless Network
Wireless Network This page displays the current status of the Wireless Channel/Frequency: Select the channel and frequency settings of the EAP1200H. appropriate for your country’s regulation. Access Point/WDS AP mode: Auto: Check this option to the enable the Auto-Channel feature. - Page 33 2.4GHz/5 GHz SSID Profile Wireless Security: See the Wireless Security section on page 36. Under Wireless Settings, you can edit the SSID profile to Isolation: Check the box to Enable or Disable the Isolation fit your needs. Click Edit under the SSID you would like to feature. make changes to. Save: Click Save to accept the changes. SSID: Specifies the SSID for the current profile.
-
Page 34: Wireless Security
Wireless Security The Wireless Security section lets you configure the WEP Encryption: EAP1200H’s security modes: WPA-PSK WPA2-PSK WPA-PSK Mixed WPA-Enterprise WPA2-Enterprise Auth Type: Select Open System or Shared Key. WPA Mixed Enterprise. Input Type: ASCII: Regular Text (Recommended) It is strongly recommended that you use WPA2-PSK. Click HEX: Hexadecimal Numbers (For advanced users) on the Edit button under Wireless Settings next to the SSID to change the security settings. - Page 35 WPA2-PSK Encryption: Encryption Key: Enter the Key Value or values you wish to use. The default is none. WPA-PSK (WPA Pre-Shared Key) Encryption: Encryption: Select the WPA encryption type you would like to use. Please ensure that your wireless clients use the same settings. Passphrase: Wireless clients must use the same Key to associate the device. If using ASCII format, the Key must Encryption: Select the WPA encryption type you would like be from 8 to 63 characters in length. If using HEXformat,...
- Page 36 WPA-PSK Mixed Encryption: WPA-Enterprise Encryption: Encryption: Select the WPA encryption type you would like to use. Please ensure that your wireless clients use the same settings. Encryption: Select the WPA encryption type you would like. Passphrase: Wireless clients must use the same Key to Please ensure that your wireless clients use the same settings. associate the device. If using ASCII format, the Key must Group Key Update Interval: Specify how often, in seconds, be from 8 to 63 characters in length. If using HEXformat,...
- Page 37 Radius Accounting Server: Enter the IP address of the WPA2Enterprise Encryption: Radius accounting server. Radius Accounting Port: Enter the port number used for connections to the Radius accounting server. Radius Accounting Secret: Enter the secret required to connect to the Radius accounting server. Interim Accounting Interval: Specify how often, in seconds, the accounting data sends.
- Page 38 Radius Accounting Server: Enter the IP address of WPA Mixed Enterprise Encryption: the Radius accounting server. Radius Accounting Port: Enter the port number used for connections to the Radius accounting server. Radius Accounting Secret: Enter the secret required to connect to the Radius accounting server. Interim Accounting Interval: Specify how often, in seconds, the accounting data sends.
-
Page 39: Guest Network Settings
Radius Accounting Server: Enter the IP address of the Radius accounting server. Radius Accounting Port: Enter the port number used for connections to the Radius accounting server. Radius Accounting Secret: Enter the secret required to connect to the Radius accounting server. Interim Accounting Interval: Specify how often, in seconds, the accounting data sends. -
Page 40: Fast Roaming
Fast Handover Fast Roaming Enable the Fast Handover feature by ensuring that Enable the function to serve mobile client devices each client is served by at least one Access Point at that roam from access point to access point. Some any time. -
Page 41: Wireless Mac Filtering
MAC address table on this page. can manually add a MAC address to restrict permission to Choices given are: Disabled, Deny MAC in the list, or Allow access EAP1200H. The default setting is: Disable Wireless MAC in the list. MAC Filter. MAC Address: Enter the MAC address of the wireless client. -
Page 42: Wireless Advanced
This page allows you to configure wireless advanced Data Rate: Select a data rate from the drop-down list. The settings. It is recommended that the default settings are data rate affects throughput of data in the EAP1200H. used unless the user has experience with more advanced The lower the data rate, the lower the throughput, though networking features. -
Page 43: Wps (Wi-Fi Protected Setup)
WPS (Wi-Fi Protected Setup) The Wi-Fi Protected Setup (WPS) feature complies with the Configured or Unconfigured. When it is configured, the Wi-Fi Alliance WPS standard and makes it easier to quickly WPS has been used to authorize a connection between the add client devices to an established, security-enabled Wi-Fi device and wireless clients. -
Page 44: Wds Link Settings
WDS Link Settings 2.4 GHz/5 GHz WDS Link Settings Using WDS (Wireless Distribution System) will allow a network administrator or installer to connect to Access Points wirelessly. Doing so will extend the wired infrastructure to locations where cabling is not possible or inefficient to implement. -
Page 45: Chapter 8 Management
Chapter 8 Management... -
Page 46: Administration
Administration This page allows you to change the EAP1200H username Apply: Click Apply to save the changes. and password. By default, the username is admin and the Note: it is highly reccomended that you change you password is admin. The password can contain from 0 to 12 password to something more unique for greater security. -
Page 47: Management Vlan Settings
VID before enabling VLAN under Management VLAN ID. Note: Note: Only applicable in Access Point and WDS AP mode. 1. If you reconfigure the Management VLAN ID, you may lose your connection to the EAP1200H. Verify that the Profile Isolation: Restrict clients from communicating with DHCP server supports the reconfigured VLAN ID, then different VIDs by checking the Isolation box for the SSID reconnect to the EAP1200H using the new IP address. -
Page 48: Wireless Traffic Shaping
Wireless Traffic Shaping Traffic Shaping regulates the flow of packets leaving an interface to deliver improved Quality of Service. To edit Wireless Traffic Shaping, click Edit for the SSID you would like to configure under Wireless Settings. Enable Traffic Shaping: select this option from the drop- down box to enable Wireless Traffic Shaping. Download Limit: Specifies the wireless transmission speed used for downloading. Upload Limit: Specifies the wireless transmission speed used for uploading. -
Page 49: Snmp Settings
SNMP Settings Status: Enables or Disables the SNMP feature. Contact: Specifies the contact details of the device. This page allows you to assign the Contact Details, Location, Community Name, and Trap Settings for Simple Network Location: Specifies the location of the device. Management Protocol (SNMP). This is a networking Port: Displays the port number. management protocol used to monitor network attached devices. SNMP allows messages (called protocol data units) to Community Name (Read Only): Specifies the password be sent to various parts of the network. - Page 50 Priv Protocol: Select the Privacy Protocol type: DES. Priv Key: Specifies the privacy key for privacy. Engine ID: Specifies the Engine ID for SNMPv3. Save: Click Save to apply the changes.
-
Page 51: Backup/Restore
Reset to Default: Click the Reset button to restore the button in the Revert to Factory Default Settings section EAP1200H to its factory default settings. to restore all the configurations of the EAP1200H to the original default settings. To Configure the Backup/ Restore Settings, click Firmware under the Systems User Settings Manager tab. -
Page 52: Auto Reboot Settings
Wi-Fi Scheduler tab on the side bar under Management. Auto Reboot Setting: Enables or disables the Auto Reboot function. Frequency of Auto Reboot: Specifies the time and frequency in rebooting the EAP1200H by Min, Hour, Day and/or Week. Click Save to apply the changes. -
Page 53: Firmware Upgrade/Time Settings
Synchronize with PC: Click to Synchronize the 3. Click the Upload button to commence the Firmware EAP1200H with the computer’s internal clock. upgrade. Automatically Get Date and Time: Enter the IP address Note: The device is unavailable during the upgrade of an NTP server or use the default NTP server to have process and must restart when the upgrade is completed. - Page 54 Click Apply to save the changes. would like to remote to. Log Server IP Address: Enter the IP address of the log server. Apply: Click Apply to save the changes.
-
Page 55: System Log/Tools
This page allows you to analyze the connection quality log functions of the EAP1200H. Click Log under the of the EAP1200H and trace the routing table to a target Systems Manager tab to open up the System Log page. in the network. -
Page 56: Ping Test Parameters/Traceroute Parameters
Ping Test Parameters Traceroute Parameters Target IP/Domain Name: Enter the IP address you Target IP/Domain Name: Enter an IP address or domain would like to search. name you wish to trace. Ping Packet Size: Enter the packet size of each ping. Start: Click Start to begin the trace route operation. -
Page 57: Speed Test Parameters/Led Control
Speed Test Parameters LED Control Target IP/Domain Name: Enter an IP address or This page allows you to control the LED control functions: domain name you wish to run a Speed Test for. Power status, LAN interface, 2.4G/5G WLAN interface and WPS. Time Period/Check Interval: Enter the time in seconds that you would like the test to run for and in Click Apply to save the settings after selecting your how many intervals. -
Page 58: Device Display/Reset
Device Discovery Under Device Discovery, you can choose for the EAP1200H to Automatically scan for local devices to connect to. Click Scan to begin the process. Reset In some circumstances, you may be required to force the device to reboot. Click on Reboot the Device to reboot the EAP1200H. -
Page 59: Appendix
Appendix... -
Page 60: Fcc Interference Statement
Appendix A Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 61: Ce Interference Statement
Appendix B - CE Interference Statement Europe – EU Declaration of Conformity This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the R&TTE Directive 1999/5/EC: • EN60950-1 Safety of Information Technology Equipment • EN50385 Generic standard to demonstrate the compliance of electronic and electrical apparatus with the basic restrictions related to human exposure to electromagnetic fields (0 Hz - 300 GHz) • EN 300 328 Electromagnetic compatibility and Radio spectrum Matters (ERM);... - Page 62 This device is a 5GHz wideband transmission system (transceiver), intended for use in all EU member states and EFTA countries, except in France and Italy where restrictive use applies. In Italy the end-user should apply for a license at the national spectrum authorities in order to obtain authorization to use the device for setting up outdoor radio links and/or for supplying public access to telecommunications and/or network services.
- Page 63 Français [French] Par la présente [nom du fabricant] déclare que l’appareil [type d’appareil] est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. Italiano [Italian] Con la presente [nome del costruttore] dichiara che questo [tipo di apparecchio] è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
