UBI EasyCoder 501 – User's Manual
PAPER LOAD – CUT OFF, cont'd.
10a 10b
2.
1.
In case of an EasyCoder 501 E or 501 SA, release the
In case of an EasyCoder 501, adjust the green guide ring slack absorber (1). Adjust the green guide ring so the
so the paper is guided with a minimum of play. paper is guided with a minimum of play (2).
11
12
Thread the paper through the cutter between the two Close the cutter unit while pulling at the end of the paper.
guide plates. Close the right-hand door.
13
14
2x
Feed out and cut two blank copies by pressing the
Turn on the power using the switch on the rear plate. <Print> key twice.
11
