Page 1: Read And Save These Instructions
INSTALLATION INSTRUCTIONS Pro Line Model Hoods (PL) Intended for Domestic Cooking Only READ AND SAVE THESE INSTRUCTIONS Installer: Leave this manual with homeowner Homeowner: Use and Care Information inside Prestige America - 103 Fairfield Rd. Fairfield, NJ 07004... -
Page 2: Table Of Contents
Important Ventilation Information Before You Begin......4 Cleaning and Maintenance............5 Planning your Location..............6 - 7 Installation Guide & Wiring Diagram..........8 - 9 Installing the Optional Wall Hood Duct Cover.......10 Warranty Information..............10 PRESTIGE PRODUCTS DIVISION Signature Marketing Group LTD. 103 Fairfield Road Fairfield, NJ 07004 1-800-358-8886... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS PRESTIGE HOODS ARE FOR RESIDENTIAL USE ONLY! CAUTION: FOR GENERAL VENTILATION USE ONLY. DO NOT USE TO EXHAUST HAZARDOUS OR EXPLOSIVE MATERIALS OR VAPORS 1. Use this unit only in the manner intended by the manufacturer. (If you have questions, contact the manufacturer at 800-358-8886. -
Page 4: Handling Precautions
d) Use an extinguisher only if: 1) You know you have a class ABC extinguisher and you already know how to operate it. 2) The fire is small and contained in the area where it started. 3) The fire department is being called. 4) You can fight the fire with your back to an exit. -
Page 5: Packing List For Pl 24" Hoods
INSPECT ALL MOLDED PACKAGING FOR PARTS BEFORE DISCARDING. ANY DAMAGE MUST BE REPORTED BEFORE INST ALLING THE HOOD. ONCE THE HOOD HAS BEEN INSTALLED, NO RETURN WILL BE ACCEPTED. Packaging List for Pro Line Hood Series PL36240, & PL42240 - 36” & 42” Ducted No blower (Sold and Packaged separately) Two (2) Stainless Baffle Filters Two (2) Pre-installed Lights... -
Page 6: Important Ventilation Information Before You Begin
NOTE TO INSTALLER: Make sure blowers are free from obstructions (packing and debris). Test run blowers before finalizing installation. Check with manufac- turer before attempting to use other than Prestige blower systems. (1-800-358- 8886 for technical information.) - 4 -... -
Page 7: Cleaning And Maintenance
CLEANING & MAINTENANCE Your hood will not function properly if not cleaned regularly and maintained properly. Clean the filters regularly, (at least twice a month or every 24 hours of use) by soaking them in soapy water and rinsing them in the dishwasher at the normal cycle. When the filters are re- moved, the accessible interior of the hood can be cleaned from grease, using again only soap and water. -
Page 8: Planning Your Location
PLANNING YOUR LOCATION Select the proper height to mount the hood. Take into consideration the stature of the person or persons who will be cooking. A height of 30” to 36” above the cooking surface will suit most users. If mounted at a height greater than 36”... -
Page 9: Planning Your Location
PLANNING YOUR LOCATION HEIGHT OF THE HOOD The bottom of the hood should be 30” (76.2 cm) min. to 36” (91.4 cm) max. above the countertop. This would typically result in the bottom of the hood being 66” (167.6 cm) to 72” (175.3 cm) above the floor. -
Page 10: Installation Guide & Wiring Diagram
INSTALLATION GUIDE & WIRING DIAGRAM Installation of Internal Blower Kit (IBPL600 600CFM) 1.) Remove shipping bracket from hood. DO NOT DISCARD SCREWS. 2.) Install blower bracket with the screws removed from the shipping bracket. 3.) Locate the terminal block inside the electrical supply box. 4.) Connect Fan #1 wire (RED) to terminal block #4. - Page 11 INSTALLATION GUIDE & WIRING DIAGRAM Installation of In-Line or Remote Blower 1.) Locate the terminal block inside the electrical supply box. 2.) Connect Fan #1 wire (RED) to terminal block #4. 3.) Connect Fan #1 wire (BLACK) to terminal block #6. 4.) Connect the 115 volt supply wire (WHITE) to terminal block #2.
-
Page 12: Installing The Optional Wall Hood Duct Cover
: ONE (1) YEAR Prestige will warranty all parts and related labor to replace them, during the one (1) year warranty period. This applies to the actual parts and normal labor and excludes all other costs, removal and re-installation.
