Models covered by these instructions:
Pro Line, Pyramid Classic & WMPLDF
Ventilation Hoods
Use & Care Manual
Intended for Domestic Cooking Only
READ AND SAVE THESE INSTRUCTIONS
Installer: Leave this manual with homeowner.
Homeowner: Use and Care information inside.
Prestige America Ltd.
25 Riverside Dr. Suite 4
Pine Brook, NJ 07058
Advertisement
Table of Contents
Related Manuals for Prestige Pro Line
Summary of Contents for Prestige Pro Line
-
Page 1: Read And Save These Instructions
Models covered by these instructions: Pro Line, Pyramid Classic & WMPLDF Ventilation Hoods Use & Care Manual Intended for Domestic Cooking Only READ AND SAVE THESE INSTRUCTIONS Installer: Leave this manual with homeowner. Homeowner: Use and Care information inside. Prestige America Ltd. -
Page 3: Table Of Contents
Packing List for your Vent Hood a) Pro Line Hoods ....................4 b) Pyramid Classic Hoods ................. 4-6 c) Pro Line Duct Free Hoods ................5 Planning your Location a) Pro Line Hoods ....................5-7 b) Pyramid Classic Hoods ................. 6-7 c) Pro Line Duct Free Hoods ................ -
Page 5: Important Safety Instructions
-Important Safety Instructions- PRESTIGE HOODS ARE FOR RESIDENTIAL USE ONLY! CAUTION: FOR GENERAL VENTILATION USE ONLY. DO NOT USE TO EXHAUST HAZARDOUS OR EXPLOSIVE MATERIALS OR VAPORS. 1. Use this unit only in the manner intended by the manufacturer. (If you have questions, contact that manufacturer at 800.358.8886.) -
Page 6: Handling Precautions
- Handling Precautions - Remove all rings, watches, belt buckles, jewelry and any clothing with metal buttons or snaps to prevent damage to hood. 2. DO NOT REMOVE HOOD FROM ITS ORIGINAL CARTON UNTIL YOU ARE READY TO INSTALL When you are ready to begin the installation process, remove the hood from its carton and place it on a clean soft blanket. -
Page 7: Important Ventilation Information Before You Begin
NOTE TO INSTALLER: Make sure blowers are free from obstructions (packing and debris). Test run blowers before finalizing installation. Check with manufacturer before attempting to use other than Prestige blower systems. (800.358.8886 for technical information) Cleaning and Maintenance Your hood will not function properly if not cleaned regularly and maintained properly. Clean the filters regularly (at least twice a month or every 24 hours of use) by soaking them in soapy water and rinsing them in the dishwasher at the normal cycle. -
Page 8: A) Pro Line Hoods
ANY DAMAGE MUST BE REPORTED BEFORE INSTALLING THE HOOD. ONCE THE HOOD HAS BEEN INSTALLED, NO RETURN WILL BE ACCEPTED. Packing List for Pro Line hood series PL36240, PL42240, PL36270 & PL42270 - 36" & 42" ducted, 24" and 27" depth No blower (Sold and Packaged Separately) -
Page 9: C) Pro Line Duct Free Hoods
Duct Free Kit (PLDFK36 or PLDFK42) to make the unit fully ductless.* Planning your location for your Pro Line Hood Select the proper height to mount the hood. Take into consideration the stature of the person or persons who will be cooking. -
Page 10: B) Pyramid Classic Hoods
6” 15 ½” Planning your location for your Duct Free or Pro Line Hood Select the proper height to mount the hood. Take into consideration the stature of the person or persons who will be cooking. A height of 30" to 36" above the cooking surface will suit most users. If mounted at a height greater than 36"... -
Page 11: Installation Guide
Planning your height location for your Pro Line, Pyramid Classic, or Duct Free hood The bottom of the hood should be 30" minimum to 36" maximum above the countertop. This would typically result in the bottom of the hood being 66" to 72" above the floor. The bottom of the hood should never be more than 72"... -
Page 12: B) Pyramid Classic Hoods
9. Connect Fan #2 wire to terminal block #3. 9.) Connect Fan #2 wire to terminal block #5. Installation Guide for your Pro Line Duct Free hood *All Prestige duct free hoods have a blower pre-installed. Installation includes wiring to the terminal block only. -
Page 13: Wiring Diagram
Wiring Diagrams for all Prestige Hoods Installing the Optional Wall Hood Duct Cover (PL & DF Models Only) Pro Line Hood Duct Cover Duct Free Hood Duct Cover All specifications are subject to change without prior notification Page 9... -
Page 14: Installing The Wall Hood Duct Cover (Flue) (Pc Models Only)
Installing the Wall Hood Duct Cover (Flue) (PC Models Only) 1. Measure from top of the canopy to ceiling and subtract 1/8" for clearance. 2. Place the duct cover top inside the duct cover base and lower until desired height is found. (To eliminate scratches, make a mark on the duct cover top for the desired lowering point by subtracting 15"... -
Page 15: Instructions For Connection Of Wall Switch Kit (Uibwsk)
* Warranty Information Prestige will warranty all parts and related labor to replace them for a term of one (1) year. The one (1) year warranty period applies to the actual parts and NORMAL labor and excludes all other costs, removal and re-installation.
