Models covered by these instructions:
UIB, UIBTF, CMUIB, UIM
Ventilation Inserts & Liners
Intended for Domestic Cooking Only

READ AND SAVE THESE INSTRUCTIONS

Installer: Leave this manual with homeowner.
Homeowner: Use and Care information inside.
Prestige America Ltd.
103 Fairfield Rd.
Fairfield, NJ 07004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UIB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Prestige UIB

Summary of Contents for Prestige UIB

  • Page 1: Read And Save These Instructions

    Models covered by these instructions: UIB, UIBTF, CMUIB, UIM Ventilation Inserts & Liners Intended for Domestic Cooking Only READ AND SAVE THESE INSTRUCTIONS Installer: Leave this manual with homeowner. Homeowner: Use and Care information inside. Prestige America Ltd. 103 Fairfield Rd.

  • Page 2: Table Of Contents

    Handling Precautions……………………………………………………………...2 Important Ventilation Information Before You Begin…………………………2 Parts Sold Separately…………………………………...…………………………3 Cleaning and Maintenance………………………………………………………..3 Packing List for your Inserts a) UIB Inserts with Blowers...………………………………………………………..3-4 b) UIB Inserts without Blowers...………………………………………………………4 c) UIM Inserts………………...…………………………………………………………5 d) UIBTF & CMUIB Inserts without Blowers………………………………………….5 Wiring Diagram……………………………………………………………………….6 Installation Guide for your Insert…….…………………………………………….6...

  • Page 3: Important Safety Instructions

    -Important Safety Instructions- PRESTIGE HOODS ARE FOR RESIDENTIAL USE ONLY! CAUTION: FOR GENERAL VENTILATION USE ONLY. DO NOT USE TO EXHAUST HAZARDOUS OR EXPLOSIVE MATERIALS OR VAPORS. 1. Use this unit only in the manner intended by the manufacturer. (If you have questions, contact that manufacturer at 800.358.8886.

  • Page 4: Handling Precautions

    Before Installing your insert, be sure to read the following! Either an interior, in-line or remote blower may be used with Prestige hood liners and power pack inserts. Other owers CANNOT be substituted. Select the series best suited for your application. Units labeled "LINERS" are for us ith in-line blowers or remote blowers.

  • Page 5: Parts Sold Separately

    Cleaning and Maintenance of your baffle filter All Prestige stainless steel baffle filters are dishwasher safe. You may also hand wash the filters is warm soapy water. Packing List for your UIB Insert UIB22S1, UIB28S1 Blower Pre-Installed in Unit One (1) Stainless Steel Baffle Filter...

  • Page 6: B) Uib Inserts Without Blowers

    Packing List for your UIB Insert (continued) UIB34S2, UIB40S2 Two (2) Blowers Pre-Installed in Unit Two (2) Stainless Steel Baffle Filters Two (2) Pre-Installed Lights Lid for Electrical Box Use and Care Manual with Wiring Diagram Transition Required and NOT supplied...

  • Page 7: C) Uim Inserts

    Packing List for your UIB Hood Liner UIB280WC15 One (1) Stainless Steel Baffle Filters Two (2) Pre-Installed Lights Lid for Electrical Box Use and Care Manual with Wiring Diagram Starter Collar Included UIB340WC15, UIB400WC15 Two (2) Stainless Steel Baffle Filters...

  • Page 8: Wiring Diagram

    Wiring Diagram Installation Guide for your insert 1.) Choose an installation height comfortable for the user. IMPORTANT: Most building codes require a 30" clearance from the top of a surface burner to the underside of any combustible material. 2.) Choose the appropriate cut-out dimension from the enclosed planning guide. Mark the underside of the wood hood, alcove, or hearth making sure you leave adequate clearance for the stainless steel trim overlay and body of the hood liner.

  • Page 9: Hood Operating Instructions

    Hood Operating Instructions The blower should be turned on for about 5 minutes BEFORE cooking in order to establish air currents upward through the hood. Use low speeds for normal use and the higher speeds for strong odors or fumes. Minimize drafts across the range or cooktop, they will reduce the effectiveness of the hood.

  • Page 10: Instructions For Connection Of Wall Switch Kit (Uibwsk)

    Warranty Information Prestige will warranty all parts and related labor to replace them for a term of one (1) year. The one (1) year warranty period applies to the actual parts and NORMAL labor and excludes all other costs, removal and re-installation.
  • Page 18 UCT.
