Ventilation Inserts & Liners
Use & Care Manual
Intended for Residential Cooking Only
READ AND SAVE THESE INSTRUCTIONS
Models covered by these instructions:
UIB, UIBTF, CMUIB, UIM
Installer: Leave this manual with homeowner.
Homeowner: Use and Care information inside.
Prestige America Ltd.
25 Riverside Dr. Suite 4
Pine Brook, NJ 07058
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Prestige UIB28-600
Summary of Contents for Prestige UIB28-600
- Page 1 Intended for Residential Cooking Only READ AND SAVE THESE INSTRUCTIONS Models covered by these instructions: UIB, UIBTF, CMUIB, UIM Installer: Leave this manual with homeowner. Homeowner: Use and Care information inside. Prestige America Ltd. 25 Riverside Dr. Suite 4 Pine Brook, NJ 07058...
-
Page 2: Table Of Contents
UIBTF & CMUIB Inserts without Blowers............5 Rear ducting Instructions.................10 Instructions for connection of Wall Switch Kit (UIBWSK) ......10 Installation Guide for your Insert..............11-12 Hood Operating Instructions................13 Warranty Information..................14 Prestige Products Division Signature Marketing Group Ltd. 25 Riverside Drive Suite 4 Pine Brook, NJ 07058 800-358-8886... -
Page 3: Important Safety Instructions
-Important Safety Instructions- PRESTIGE® INSERTS ARE FOR RESIDENTIAL USE ONLY! CAUTION: FOR GENERAL VENTILATION USE ONLY. DO NOT USE TO EXHAUST HAZARDOUS OR EXPLOSIVE MATERIALS OR VAPORS. Use this unit only in the manner intended by the manufacturer. (If you have questions, contact Prestige®... - Page 4 -Important Safety Instructions- WARNING - IN THE EVENT OF RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING: 1. Smother the flames with a close fitting lid, cooking sheet or other metal tray, and then turn off the burner. BE CAREFUL TO PREVENT BURNS. If the flames do not go out immediately, EVACUATE AND CALL THE FIRE DEPARTMENT.
-
Page 5: Handling Precautions
• Units with model numbers ending in 1200 require the use of transition model TR6x15/10 (NOT INCLUDED AND SOLD SEPERATELY). • All Prestige® ventilation inserts have a variable speed blower switch as well as a light dimmer switch. Inserts can be set up for ductless applications. See product guide for optional •... -
Page 6: Important Ventilation Information Before You Begin
Before installing your insert, be sure to read the following! Prestige® inserts are designed to utilize internal, in-line, or remote blowers. Other blowers CANNOT be substituted. Select the series best suited for your application. Units labeled "NB" are for use with in-line blowers or remote blowers. Units labeled "600" or “1200” come with pre- installed 600 or 1200 CFM motors. - Page 7 -Cleaning and Maintenance- Be sure lights are cool before cleaning your insert. Your insert will not function properly if not cleaned regularly and maintained properly. Clean the filters regularly (at least twice a month or every 24 hours of use) by soaking them in soapy water and rinsing them in the dishwasher at the normal cycle.
-
Page 8: Accessories Sold Separately
-Accessories Sold Separately- • In-line blowers IL600, IL1200 and IL1600 • Remote blowers, RB1000, RB1200, RB1600, RB2000 • Transitions TR6x15/8, TR6x15/10 (for use with 1200 blower system), TRC8/6 transition collar (for use with 600 blower) • Wall Caps, WC6HD, WC8HD, WC10HD. T he WC6x15/HD is for use with the 1200 blower system when rear ducting. - Page 9 -Packing List for UIB Insert- UIB20-600, UIB26-600 UIB30-600 UIB28-600 Blower Pre-Installed in Unit One (1) Stainless Steel Baffle Filter Two (2) Pre-Installed Lights L id for Electrical Box UIB34-600 Blower Pre-Installed in Unit Two (2) Stainless Steel Baffle Filters ...
- Page 10 -Packing List for UIB Hood Liner- UIB28-NB One (1) Stainless Steel Baffle Filters T wo (2) Pre-Installed Lights L id for Electrical Box Starter Collar Included UIB34-NB, UIB40-NB Two (2) Stainless Steel Baffle Filters Two (2) Pre-Installed Lights Lid for Electrical Box ...
- Page 11 -Packing List for UIBTF or CMUIBTF Hood Liner- UIBTF34-NB, UIBTF40-NB Four (4) Stainless Steel Baffle Filters T wo (2) Pre-Installed Lights L id for Electrical Box UIBTF48-NB, UIBTF58-NB Six (6) Stainless Steel Baffle Filters Three (3) Pre-Installed Lights ...
-
Page 12: Rear Ducting Instructions
Disconnect wires from Fan and Light switches from the wiring harness supplied with your insert. Connect Fan and Light switches to harness supplied with Prestige® wall switch Make all electrical connections between supplied harness and wires for wall switch inside of insert electrical box Before hanging your hood and wall switch kit, be sure that the connections made are fully operational. - Page 13 -Installation Guide- NOTE: During installation, protect countertop and/or cooking appliances. Choose an installation height that is comfortable for the user. IMPORTANT: Most building codes require a 30" minimum clearance from the top of a surface burner to the underside of any combustible material. Choose the appropriate cutout dimension from the cutout dimension section (page 13).
- Page 14 -Cutout Dimensions- Use the below dimensions to make the cutout for your Prestige® Model# Width Depth UIB28-600 25 1/8" 13 5/8" UIB34-600 31 1/8" 13 5/8" UIB34-1200 31 1/8" 13 5/8" UIB40-1200 37 1/8" 13 5/8" UIB46-1200 44 5/8" 16 5/8"...
-
Page 15: Hood Operating Instructions
-Installation of In-Line or Remote blower- Using the harness supplied with your Prestige® in-line or remote blower, plug into connector located near insert finger guard. Make all connections between supplied harness and wiring connected to the blower using wire nuts (not included) inside of insert electrical box. -
Page 16: Warranty Information
Warranty Information Prestige® will warranty all parts and related labor to replace them for a term of one (1) year. The one (1) year warranty period applies to the actual parts and NORMAL labor and excludes all other costs, removal and re-installation.
