Black Widow Security BW2900R2 Installation Instructions Manual

2R / 4-BUTTON SERIES
VEHICLE SECURITY SYSTEM
Button
1
Button
2
Standard Features:
Two 4-Button Remote Transmitters
Status indicator (LED)
Valet / override switch
Multi-tone siren (120dB)
Dual stage impact detector
Remote panic
Remote chirp mute
Remote sensor bypass
Active or passive arming
Optional Features:
Starter disable
Flashing parking lights
Keyless entry
Remote trunk or hatch release
Illuminated entry
Hood and trunk protection
Remote auto start
Power window roll up
Back-up battery w/charging circuit
Glass break sensor
Note: Some features may require additional
parts and labor, and may not be appropriate for
certain vehicles. Consult your authorized dealer.

System Operation

ARMING OPERATION
To arm the system press transmitter button 1:
Button
3
• The siren will chirp once.
• The parking lights will flash once.*
Button
4
• The doors will lock.*
• The LED will turn solid for 10 seconds
then start flashing slowly. After 10
seconds the system is armed.
After Arming, if the system detects a bad
sensor or an open zone, the siren will chirp
and the parking lights will flash 4 times to
indicate a zone is open. The system will
ignore that input, but keep all other areas
protected.
While Armed, the system will trigger if:
• The doors are opened.
• The shock sensor detects an impact to
• The hood or trunk is opened.
When triggered, the siren will sound, the
horn will honk*, and the parking lights will
flash* for 30 seconds.
If the same input triggers the system 3 times
during a single arming cycle, the system will
bypass that input, keeping the other zones
protected, until the next time the system is
armed.
If the shock sensor detects a light impact to
the vehicle, the siren will chirp and the
parking lights will flash 5 times to warn away
the potential intruder.
*
Optional Feature
1
the vehicle.
