Circulation Air Blower Data - *9Mpt - ICP C9MPT050F12C1 Technical Support Manual

*9MPT050F12 (1) *
Denotes Brand
Speed
Low
Tap
0.1 826
0.2 804
0.3 770
0.4 735
0.5 698
0.6 657
0.7 ------
0.8 --------
0.9 ------
1.0 ------
*9MPT075F14 (1) *
Denotes Brand
Speed
Low
Tap
0.1 695
0.2 674
0.3 653
0.4 631
0.5 609
0.6 569
0.7 529
0.8 490
0.9 ------
1.0 ------
NOTE: (1) Data based on Bottom Only or One Side return.
(2) Data based on Both Sides or Bottom plus One Side
MAX CFM's for Factory
Washable Filters
Filter Size
14" X 25"
16" X 25"
20" X 25"
24" X 25"
Max CFM based on 600 FPM
NOTE: Disposable filters are typically rated at 300 FPM. These filters only allow
half the airflow when compared to 600 FPM filters. (EXAMPLE, 20 X 25 @ 600
FPM = 200 CFM, @ 300 FPM = 1000 CFM)
440 04 2023 02

Circulation Air Blower Data - *9MPT

Med L Med H Hi
1083 1301 1408
1050 1242 1347
1028 1195 1295
985 1153 1237
952 1093 1183
909 1040 1118
863 935 1053
812 865 976
------ 802 887
------ 720 787
Med L Med H Hi
1025 1455 1724
1001 1410 1662
951 1365 1601
921 1309 1530
891 1252 1460
845 1187 1380
799 1122 1300
730 1030 1190
680 950 1080
------ 831 969
CFM
1400
1600
2000
2500
Specifications are subject to change without notice
*9MPT100J16 (1) *
Denotes Brand
Speed
Low
Tap
0.1 823
0.2 795
0.3 747
0.4 677
0.5 617
0.6 544
0.7 ------
0.8 ------
0.9 ------
1.0 ------
*9MPT125L20 (2) *
Denotes Brand
Speed
Low
Tap
0.1 1720
0.2 1686
0.3 1644
0.4 1600
0.5 1533
0.6 1494
0.7 1413
0.8 1306
0.9 ------
1.0 ------
# CFM -- Cubic feet per minute airflow. Filter required for each return--air
inlet. Airflow performance includes 1" washable (600 FPM max) filter media.
Med L Med H Hi
1109 1527 1850
1087 1482 1791
1056 1426 1720
1016 1382 1648
970 1317 1575
854 1245 1485
763 1154 1401
652 1043 1284
------ 905 1161
------ 737 1028
Med L Med H Hi
1910 2127 2315
1881 2087 2268
1833 2024 2201
1777 1961 2131
1720 1891 2029
1647 1804 1948
1571 1708 1820
1470 1604 1730
1349 1484 1614
------ 1328 1430
3
