PS.10mk2 Powered Subwoofer
Owner's Manual
1 0mk2
PS.

Advertisement

loading

Related Manuals for Snell PS.10mk2

Summary of Contents for Snell PS.10mk2

  • Page 1 PS.10mk2 Powered Subwoofer Owner‘s Manual 1 0mk2...
  • Page 2 For all other servicing, con- its proper functioning. For example, the appliance sult your dealer or contact Snell Acoustics. should not be situated on a bed, sofa, rug, or simi- lar surface that may obstruct the heat sink sur-...
  • Page 3 3,000 cubic-foot room, the PS.10mk2 meets the demands of digital Easy to Hide 5.1 formats. Yet, the PS.10mk2 is so compact, it The PS.10mk2 cabinet is small enough to tuck easily fits within a typical AV cabinet.
  • Page 4 F E A T U R E S CROSSOVER LOW LEVEL IN HIGH PASS OUT 80 Hz 70 Hz 100 Hz 60 Hz 125 Hz 50 Hz FROM PREAMP TO AMP HIGH LEVEL IN FROM AMP 0° PHASE – – 180°...
  • Page 5 Speaker-Level Inputs The Bass Level control adjusts the sound level The PS.10mk2 utilizes high-level inputs. The 5- output of the PS.10mk2. It is located on the way gold-plated terminals accept spade lugs to front of the cabinet, behind the grille.
  • Page 6 Most surround sound receivers and preamps now offer a ”SUBWOOFER OUT“ feature. When using this option, the subwoofer filter will most likely be set within the electronics. The signal being sent to your main speakers will be full range. You should then set the PS.10mk2‘s internal crossover for ”EXT“ (External).
  • Page 7 1. Use the line-level RCA inputs, connecting to ”PREAMP OUT“ on your receiver. 2. From the PS.10mk2 line-level out, connect to ”AMPLIFIER IN“ on your receiver. 3. Choose a setting for the PS.10mk2 crossover that allows the subwoofer to blend seamlessly with the main speakers.
  • Page 8 WIRING FOR 2-CHANNEL AUDIO Using speaker-level wiring Option 1 Connect from the main speaker out on the receiver to the PS.10mk2. Connect the main speakers to the output of the subwoofer. NOTE: The main speakers will be high pass filtered in this configuration.
  • Page 9 Option 2 Connect both the subwoofer and the main speakers to the back of the receiver. Receiver PS10mk2 Main Amplifier Panel Speakers HIGH LEVEL IN FROM AMP – – HIGH LEVEL OUT TO MAIN SPEAKERS Option 3 Connect the amplifier to the main speaker system and the main speaker system to the subwoofer in.
  • Page 10 CONNECTING TWO PS.10mk2’s You may wish to use two PS.10mk2’s, particularly if you are in a large room. Double subwoofers may be wired with either speaker-level or line-level connections. Be sure the Phase Switch is set the same on both units.
  • Page 11 P L A C E M E N T Subwoofers often are smoothest when placed snugly against a side or back wall. Placement in a corner generally offers up the smoothest response. These positions will also increase the subwoofers‘ sensitivity, allowing you to run them at a reduced power.

  • Page 12: Limited Warranty

    L I M I T E D W A R R A N T Y During the warranty period, Snell Acoustics will repair, for the original owner, any defect in materials or workmanship that occurs in normal use of the speaker system, without charge for parts and labor. The warranty period for all parts of the PS10Mk2, except the amplifier, is five (5) years.
