- Page 1 ICS Sub 24 Powered Subwoofer Owner‘s Manual ICS Sub 24...
- Page 2 The appliance has been dropped, or the enclosure is damaged. Servicing: The user should not attempt to service the appliance beyond what is described in the operating instructions. For all other servicing, consult your dealer or contact Snell Acoustics.
- Page 3 S P E C I F I C A T I O N S Frequency Response (±3dB) 23-200Hz; 20Hz at -6dB Amplifier Power 450 watts Crossover Low Pass for Subwoofer Variable from 50 to 150Hz Crossover High Pass for Line Out Fixed at 80Hz, 12dB/octave Bass Unit Dual 12-inch (305mm) long throw cast chassis woofers...
- Page 4 CROSSOVER LOW LEVEL IN 80 Hz 70 Hz 100 Hz 60 Hz 125 Hz 150 Hz 50 Hz Bypasses Crossover HIGH LEVEL IN FROM AMP 0° PHASE 180° ALWAYS ON HIGH LEVEL OUT TO MAIN SPEAKERS AUTO ON 12OV 60 Hz 5A FUSE TYPE T5A 250V RISK OF ELECTRIC SHOCK...
- Page 5 Our cabinet shop sequences the veneer, maintaining a match from the left side, across the top, to the right side of the speaker. We even veneer the inside of the cabinet so it won’t warp or...
- Page 6 C O N N E C T I O N Warning: To reduce the risk of electric shock, always switch off the subwoofer and the amplifier and or receiver when making connections to the subwoofer and speakers. THX® Input Use this input when the ICS Sub 24 is connected to a receiver or surround sound controller that has a built-in THX control system.
-
Page 7: High Level Connection
If the electronics in your system does not have Preamp Output/Power Amp Input connections, the ICS Sub 24 can be connected via the speaker wiring using the “High Level” Connections. There are two methods for making high level connections the ICS Sub 24. - Page 8 Alternate High Level Connection The alternate method for making high level connections is to connect both the ICS Sub 24 and the main speakers directly to the amplifier. This type of connection does not take advantage of the high pass filter provided by the High Level Outputs of the ICS Sub 24.
- Page 9 Amplifier, Receiver or Preamp/Power Amp PREAMP To connect two ICS Sub 24’s using speaker-level inputs, use the ”HIGH LEVEL IN FROM AMP“ binding posts on one subwoofer to daisy chain to the second ICS Sub 24. Amplifier, Receiver or Preamp/Power Amp...
- Page 10 If getting the best sound, together with the physical constrains of the room, require that the two units must be closer than that you can purchase a magnetic shielding kit from Snell Acoustics. F I N E - T U N I N G Y O U R S U B W O O F E R Note: If you are connecting the ICS Sub 24 to a THX receiver/controller, use the THX input.
-
Page 11: Bass Level Control
Setting the Phase The proper setting for the Phase Switch changes based upon the location of the speaker. To determine the correct setting for your room, use a source with a full and continuous bass line. Have a second person repeatedly switch the Phase Switch from one position to the other. - Page 12 We will promptly advise you of what action to take. If it is necessary to return your speaker system to the factory, please ship it prepaid in the original factory packaging. Please note that Snell Acoustics will not be held liable for shipping damage due to improper packaging.
