- Page 1 Basis 300 Powered Subwoofer Owner‘s Manual Basis 300...
- Page 2 For all other servicing, con- its proper functioning. For example, the appliance sult your dealer or contact Snell Acoustics. should not be situated on a bed, sofa, rug, or simi- lar surface that may obstruct the heat sink sur-...
- Page 3 25Hz (-3dB) and output over 105dB at a typical listening position in a 3,000 cubic-foot room, the Basis 300 meets the demands of digital 5.1 formats. Yet, the Basis 300 is so compact, it easily fits within a typical AV cabinet. Tuned for Flexibility We tuned the Basis 300 to match the speed and sonic presentation of the Snell K7 and LCR7.
- Page 5 C O N N E C T I O N S Line-Level Input: Line level is the preferred choice in systems using a separate amp and preamp or in receivers that have a line level or preamp out. These inputs include a built-in fixed high-pass filter at 80Hz. You should use this input for ”SUBWOOFER OUT“...
- Page 6 Speaker-Level Wiring The simplest way to wire the subwoofer is via the speaker connections. This does not present any additional load to your amplifier. The Sub300 is not sensitive to wire length, therefore you may want to use long wires at first to allow for experi- mentation with placement.
- Page 7 Option 2 Connect both the subwoofer and the main speakers to the back of the receiver. Receiver Main Amplifier Panel Speakers HIGH LEVEL IN FROM AMP – – HIGH LEVEL OUT TO MAIN SPEAKERS Option 3 Connect the amplifier to the main speaker system and the main speaker system to the subwoofer in.
- Page 8 P L A C E M E N T Subwoofers often are smoothest when placed snugly against a side or back wall. Placement in a corner generally offers up the smoothest response. These positions will also increase the subwoofers‘ sensitivity, allowing you to run them at a reduced power.
- Page 9 The warranty period for all parts of the Basis 300, except the amplifier, is five (5) years. The warranty period on the amplifier is one (1) year.
