Wasp WPL205 Quick Start Manual

2. Change label stock.
3. Printer initialization.
To do this: Turn off the printer.
Press and hold the Feed button while
turning the power back on. Release the
button when LED becomes red and blinks
2 times.
7. Reset the Printer
This should be done if the printer is not
calibrating the label correctly.
Press and hold the Feed button while
turning the power back on. The LED color
will change in the following order: Amber
red (5 blinks) amber (5 blinks)
green (5 blinks) green/amber (5 blinks)
red/amber (5 blinks) solid green.
Note: Please select gap or black mark
sensor using the GAP or BLINE
command prior to calibrating the
sensor. This can be done in the print
driver.
8. Software
The printer is now ready to print labels.
Labels can be printed from Microsoft Word or
from label printing software. Wasp has
created a full-featured label printing software
program called Labeler that is optimized to
print labels with the WPL205 printer.
9. Documentation
Several documents are included on the CD.
The user guide for the printer includes more
detailed setup instructions and a trouble-
shooting guide.
000000
#
WPL205
Thermal Printer
Quick Start
Guide
© 2007 Wasp Technologies
