- Page 1 English 06-10 Manuel d‘utilisation Francais 11-15 Ersatzteile - Spare Parts - Pièces de rechange 16-20 Montage - Assembly - Montage 21-35 Einstelltipps - Setup tips - Indication de ajustage 35-36 Garantie - Warranty - Garantie GM-Racing 90191 MRX5 Street Bike...
-
Page 2: Saftey Precautions
INTRODUCTION Thank you for buying the MRX5 Street Bike by GM-Racing. This introduction contains the basic instructions for the operation of your new vehicle. The Street Bike is a great model for RC Beginners, but it also requires a degree of crafts- manship and with Drivers under 14 years, the guidance from the parents. -
Page 3: The Remote Control System
THE REMOTE CONTROL SYSTEM Here you get an overview of the remote control system of the MRX5 Street Bike and its various functions and settings. Before the fi rst trip you should be sure all of these functions and settings have read and understood. -
Page 4: Operating The Remote Control
With correctly adjusted ESC, in neutral position the LED lits green, throttle or brake the LED shines red. REFERENCES TO THE ARTR VERSION The ARTR version of the MRX5 Street Bike is pre-mounted, so only the remote control (servo and receiver) and the electronic speed control have to be inserted. -
Page 5: Troubleshooting
The car is diffi cult to steer Transmitter batteries empty Change or charge batteries Steering servo trim not adjusted Trim steering servo properly Interferences Make a short break an then try again or change crystals GM-Racing 90191 MRX5 Street Bike... -
Page 6: Eg Declaration Of Conformity
1) Cd: Cadmium 2) Hg: Mercury 3) Pb: Lead LIABILITY FOR PRINTING ERRORS EXCLUDED! WE RESERVE THE RIGHT TO INTRODUCE MODIFICATIONS! The newest version of this manual can be found in the Internet under www.graupner.de (No. 90191.XX) GM-Racing 90191 MRX5 Street Bike... - Page 7 / Pour effectuer un virage à droite, tourner le volant vers la droite pour faire pencher la moto dans la même direction. Start / To start / Départ GM-Racing 90191 MRX5 Street Bike...
- Page 8 Ersatzteile (1) Spare Parts Pièces de rechange GM-Racing 90191 MRX5 Street Bike...
- Page 9 Ersatzteile (2) Spare Parts Pièces de rechange GM-Racing 90191 MRX5 Street Bike...
- Page 10 Ersatzteile (3) Spare Parts Pièces de rechange GM-Racing 90191 MRX5 Street Bike...
- Page 11 Ersatzteile (4) Spare Parts Pièces de rechange GM-Racing 90191 MRX5 Street Bike...
- Page 12 Ersatzteile (5) Spare Parts Pièces de rechange GM-Racing 90191 MRX5 Street Bike...
- Page 13 Ersatzteile (6) Spare Parts Pièces de rechange GM-Racing 90191 MRX5 Street Bike...
- Page 14 Clé Allen Clé Allen Tournevis à douille Mutternschlüssel 4mm Mutternschlüssel 4.5mm Mutternschlüssel 5.5mm Schraubendreher (M, L) Nut Driver Nut Driver Nut Driver Phillips Screwdriver Tournevis à douille Tournevis à douille Tournevis à douille Tournevis cruciformes GM-Racing 90191 MRX5 Street Bike...
- Page 15 Note: Reères dirigés vers l'interieur 90191.16 90191.13 M2.6x10mm Schraube / 90190.33 Screw / Vis 90190.15 6x10mm Kugellager / 90190.15 Ball Bearing / Roulement Stift / Pin / Goupille 6x13mm Kugellager / Ball Bearing / Roulement 90190.17 90191.30 GM-Racing 90191 MRX5 Street Bike...
- Page 16 Screw / Vis Roulement Screw / Vis 3x6mm Schraube / 90191.35 Screw / Vis 90191.26 3x6mm Schraube / Screw / Vis 4x10mm Beilagscheibe / 90191.27 Washer / Rondelle 90191.3 M4x10mm Schraube / Screw / Vis GM-Racing 90191 MRX5 Street Bike...
- Page 17 5x10mm F Kugellager / 3x12mm Ball Bearing / 90191.4 Schraube / Roulement Screw / Vis 90191.21 M3x8mm 90191.5 Schraube / 90191.6 Screw / Vis M3x12mm Schraube / Screw / Vis 90191.8 90191.9 90191.28 90191.23 90191.8 90191.24 GM-Racing 90191 MRX5 Street Bike...
- Page 18 Schraube / 90191.22 Screw / Vis 90501.50 3x6mm Schraube / Screw / Vis 90501.50 90191.9 5x11mm Kugellager / Ball Bearing / Roulement 3x10mm Schraube / Screw / Vis 3x6mm Schraube / Screw / Vis 90191.31 90191.31 GM-Racing 90191 MRX5 Street Bike...
- Page 19 90191.31 Schraube von Servo verwenden / Screw included with servo / Vis inclus avec servo M3x10mm Schraube / Screw / Vis 90191.11 90191.2 90191.59 GM-Racing 90191 MRX5 Street Bike...
- Page 20 Screw / Vis 3x10mm Schraube / Screw / Vis 90191.9 3x8mm Schraube / Screw / Vis 90191.9 3x12mm Schraube / Screw / Vis 3x12mm 90191.1 Schraube / Screw / Vis 3x10mm Schraube / Screw / Vis GM-Racing 90191 MRX5 Street Bike...
- Page 21 M2x5mm Schraube / Screw / Vis 90501.33 90501.33 2.5x6mm Beilagscheibe / Washer / Rondelle 90501.32 90501.32 90501.33 90501.32 90501.32 90501.29 GM-Racing 90191 MRX5 Street Bike...
- Page 22 3x12mm Schraube / Screw / Vis 3x12mm Schraube / Screw / Vis M4x40mm Schraube / Screw / Vis M3x20mm Schraube / Screw / Vis GM-Racing 90191 MRX5 Street Bike...
- Page 23 / Move to adjust the chain to the right tightness and then screw on / Pour régler la tension de la chaîne déplacer le support-moteur, jusqu'à ce que la tension correcte et serrez les deux vis 90191.10 3x8mm Schraube / Screw / Vis GM-Racing 90191 MRX5 Street Bike...
- Page 24 90191.14 3x6mm Schraube / Screw / Vis 90191.37 90191.10 3x8mm Schraube / Screw / Vis 3x10mm Schraube / Screw / Vis GM-Racing 90191 MRX5 Street Bike...
- Page 25 Schrauben fest / Tighten the screws with a sheet of paper between both gears / Serrer les vis avec une Feuille de papier dans l'engrenage / Apriete los tornillos colocando una lámina de papel entre ambos pinones GM-Racing 90191 MRX5 Street Bike...
- Page 26 Empfänger / Receiver / Récepteur Doppelseitiges Klebeband / Double sided tape / Adhésif double-face 90191.56 GM-Racing 90191 MRX5 Street Bike...
- Page 27 2.6x12mm Schraube / Screw / Vis 90191.38 90191.39 - 90191.43 2.6x6mm Schraube / Screw / Vis 3x10mm Schraube / Screw / Vis 3x10mm Schraube / Screw / Vis GM-Racing 90191 MRX5 Street Bike...
- Page 28 90191.44 - 90191.48 90200.63 4x8mm Gleitlager / Bushing / Roulement 90191.36 GM-Racing 90191 MRX5 Street Bike...
- Page 29 Schraube / Screw / Vis 90191.54 - 90151.55 3x8mm Beilagscheibe / Washer / Rondelle 2.6x12mm 3x12mm 90191.49 - 90191.53 Schraube / Schraube / Screw / Vis Screw / Vis 90200.63 3x8mm Schraube / Screw / Vis GM-Racing 90191 MRX5 Street Bike...
- Page 30 GM-Racing 90191 MRX5 Street Bike...
-
Page 31: For Your Notes
