Asanté FriendlyNET FS4016P Installation Guide
Asanté FriendlyNET FS4016P
16-port Dual-speed Fast Ethernet Switch
User's Guide
Product Introduction
Congratulations on your purchase of the Asanté FriendlyNET FS4016P. These switches were
designed to give you the ultimate in performance, flexibility, ease-of-use, and reliability.
Your Asanté FriendlyNET FS4016P can increase performance on your network by bringing full Ether-
net bandwidth to individual workgroups, or straight to the desktop, instead of requiring all stations to
share the bandwidth of a single network. The switch's 100Mbps Fast Ethernet capability can eliminate
bottlenecks in connections to servers, or can link 10Mbps workgroups to a 100Mbps Fast Ethernet net-
work backbone.
For straight-through 10Base-T/100Base-TX connection to servers and workstations, the switch sup-
ports full-duplex connection, effectively doubling the total throughput on individual links. The switch's
store-and-forward switching architecture forwards packets to their destination with a minimum of delay.
The switches can be placed on a tabletop or wall-mounted, and provide the ideal solution for your
small, medium, or large Ethernet/Fast Ethernet network. It is designed to comply fully with the IEEE
802.3 Ethernet and 802.3u Fast Ethernet standards.
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Asante FriendlyNET FS4016P
Summary of Contents for Asante FriendlyNET FS4016P
- Page 1 flexibility, ease-of-use, and reliability. Your Asanté FriendlyNET FS4016P can increase performance on your network by bringing full Ether- net bandwidth to individual workgroups, or straight to the desktop, instead of requiring all stations to share the bandwidth of a single network.
- Page 2 If any of these items are missing, contact your dealer immediately Installation The Asanté FriendlyNET FS4016P switch is easy to install and requires no special training. You should, however, read the following instructions carefully before proceeding to install your switch. The diagram below shows the layout of the front and rear panels.
- Page 3 You can place the switch on a table. In this case, use the four self-adhesive feet, which are provided with the Asanté FriendlyNET FS4016P for cushioning purposes. Stick them on the four corners of the bottom surface of the switch, as shown in diagram below to cushion it against vibration.
- Page 4 FS40016P.fm Page 4 Tuesday, March 16, 1999 5:53 PM Asanté FriendlyNET FS4016P Installation Guide Connecting to Servers and Workstations Use the following procedure to connect a 10Base-T or 100Base-TX Ethernet server or worksta- tion to the switch. Make sure that the length of the straight-through cable between the switch and the station does not exceed 100 meters, including all patch cables and cross-connect wires.
- Page 5 Use a straight-through cable to connect uplink port or use a crossover cable to connect to any port except uplink port. (Do not connect both uplink ports together, and do not use a crossover cable to connect with the uplink port). Asanté FriendlyNET FS4016P Installation Guide Push button in the IN position...
- Page 6 FS40016P.fm Page 6 Tuesday, March 16, 1999 5:53 PM Asanté FriendlyNET FS4016P Installation Guide LED Indicators Front Panel LED Indicators Color Status Green The switch is powered on and ready for use The switch is powered off. Please check the following issues: •...
- Page 7 Yellow Blinking Yellow Table 3: Full Duplex/Collision Color Yellow Blinking Yellow Asanté FriendlyNET FS4016P Installation Guide Status No link is established on the port. A 10Mbps Link is established on the port. A 10Mbps Link is established and traf- fic is being received.
- Page 8 FS40016P.fm Page 8 Tuesday, March 16, 1999 5:53 PM Asanté FriendlyNET FS4016P Installation Guide Full/Auto Dip Switch By default each port is capable of full autonegotiation. In addition, each port may be manually config- ured for full-duplex operation using the DIP switches on the rear panel of the switch.
- Page 9 FS40016P.fm Page 9 Tuesday, March 16, 1999 5:53 PM MOUNTING KIT INSTRUCTION Asanté FriendlyNET FS4016P 16-port 10/100M Switch is supplied with two mounting brackets and six screws for mounting into a 19” rack. Rack mounting in a 19” rack Locate the mounting bracket over the mounting holes on each side of the switch.
-
Page 10: Technical Information
FS40016P.fm Page 10 Tuesday, March 16, 1999 5:53 PM Asanté FriendlyNET FS4016P Installation Guide TECHNICAL INFORMATION StandardsSupported 10/100Base-TX UTP/STP Port Uplink port Cabling Input voltage Operating temperature Operating humidity Certification Dimensions Page 10 IEEE802.3, IEEE802.3u, IEEE 802.3x 16 N-WAY ports... - Page 11 Contacting Technical Support To contact Asanté Technical Support: Telephone E-mail World Wide Web Site Technical Support Hours 6:00 a.m. to 5:00 p.m. Pacific Standard Time USA, Monday - Friday. Asanté FriendlyNET FS4016P Installation Guide (800) 622-7464 (801) 566-3787 support@asante.com http://www.asante.com Page 11...
- Page 12 FS40016P.fm Page 12 Tuesday, March 16, 1999 5:53 PM Asanté FriendlyNET FS4016P Installation Guide ASANTÉ TECHNOLOGIES, INC., 821 FOX LANE, SAN JOSE, CA 95131 PHONE: 800.622.7464 • FAX: 801.566.3787 • e-mail address: sales@asante.com • World Wide Web site: http://www.asante.com ©1999 Asanté Technologies Inc. Asanté is a trademark of Asanté Technologies, Inc.
