FriendlyNet 8+2 Ethernet Switch FS3208

Mail Us Your Registration for LIFETIME Warranty

Thank you for purchasing an Asanté Ethernet product. Please mail in your product registration card to
receive toll-free technical support. By returning your registration card you will also receive new
information on updates and new products.

Power Adapter

To ensure that the plug on the power adapter doesn't get disconnected from the DC Power Connector
on the back panel of the FriendlyNet switch, we recommend that you use the twist-tie included with the
power adapter to tie any excess cable from the power adapter to the cable tie anchor loop located next
to the DC Power Connector.
Note: The FriendlyNet 8+2 Ethernet Switch does not have a power switch. The power
is automatically turned on as soon as the power adapter is connected to the
FriendlyNet 8+2 Ethernet Switch and to a power outlet.

Manual Addendum

The manual addendum contains additions to page 2-14 of the User's Manual.

Packet Forwarding

The FriendlyNet switch acts as a high-speed selective bridge between individual segments. Port #9 or
the Uplink port can be used as a backbone port to connect to the corporate networks. Packets received
on the backbone port with an unknown destination address will be filtered out, preserving the MAC
address table. The processing of packets received by the FriendlyNet switch is shown in the table
below.
Source
Any port except port #9
(unicast packet)
Any port except port #9
(unicast packet)
Any port except port #9
(unicast packet)
Any port except port #9
(multicast/broadcast packet)
Port #9 (unicast packet)
Port #9 (unicast packet)
Port #9 (multicast/broadcast
packet)
READ ME FIRST!
Destination
Unknown
Same port as source
Another known port
Not applicable
Unknown
Known port (not port
#9) with destination
address in the MAC
address table
Not applicable
Action
Forwards to all ports
Filters packet
Forwards to specific port only
Forwards to all ports
Filters packet
Forwards to known port only
Forwards to all ports
