- Page 1 Owner's Manual Mobile DVD/CD Player with 10.2" TFT Monitor Model: MV1020 / MV1020C For operational or technical assistance, after reading this manual, please call us toll free at (800) 638-3600 or visit www.magnadyne.com...
-
Page 2: Table Of Contents
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Magnadyne Corporation and other rights owners. Use of this copyright protection technology must be authorized by Magnadyne... -
Page 3: Use This Product Safely
Driving Be aware of road and traffic conditions. Keep the volume at a low level. Moisture Do not expose the product to water or excessive moisture. This could cause electrical shorts, fire or other damage. Parking Parking in direct sunlight can produce very high temperatures inside your vehicle. -
Page 4: Disc And Sd Card Notes
Disc Formats Supported by this Player: (Single-sided disc only) 8 cm disc Discs which cannot be played with this player: • DVD-ROM • DVD-R/DVD-RAM • CDV • CD-G SD Card File Format Compatibility: • AVI (Video) • MP3 (Audio) • JPEG (Pictures) Disc and SD Card Notes 8 cm disc Disc Handling... -
Page 5: Screen And Dvd/Cd Functions
1. POWER Button: Press this button to turn the unit On/Off. 2. SOURCE Button: Press this button to change the play source between DVD/CD player and an auxiliary input source. 3. STOP Button: Stops play of picture or audio. 4. Power On LED Indicator 5. -
Page 6: Turning The Unit On
Turning the Unit On: Press the POWER on either the remote or the screen housing. Adjusting the Monitor: 1. Press the MODE button on the remote to activate the monitor adjustment menu. The following will be displayed on the screen: BRIGHTNESS BRIGHTNESS 2. -
Page 7: Screen And Dvd/Cd Functions
Wireless Transmitter Modules: Wireless Transmitter Modules Vehicle’s FM Stereo Receiver The audio signal is converted to an infrared light and FM frequency that is transmitted to the IR headphones or the vehicle’s FM stereo receiver. Selecting the Wireless Transmitter Frequency: 1. -
Page 8: Operation
Remote Control Locations and Operation POWER TITLE SOURCE AUDIO ANGLE SUBTITLE DISPLAY SETUP PLAY/PAUSE ENTER PROG CLEAR PREV NEXT VOL– ZOOM SLOW REPEAT MUTE 1. POWER: Turns the unit On/Off. 2. AUDIO: Press the button to change audio languages. 3. ANGLE: Press the button to change DVD’s picture angle. -
Page 9: Basic Operation And Special Functions
Remote Control Locations and Operation POWER TITLE SOURCE AUDIO ANGLE SUBTITLE DISPLAY SETUP PLAY/PAUSE ENTER PROG CLEAR PREV NEXT VOL– ZOOM SLOW REPEAT MUTE Use CURSOR buttons when selecting items or to move cursor up, down, left or right. 27. A-B: Press the button during play to set point A and point B, then program A and B will be... -
Page 10: Play Function
Basic Operation and Special Functions PLAY FUNCTION (Continued) Advance to Next Chapter or Track Press the NEXT button during playback and the play advances to the beginning of the next chapter or track. Removing Disc Press the STOP button, then press the EJECT button to eject the disc. -
Page 11: Dvd Special Functions
DVD SPECIAL FUNCTIONS Multi-Subtitle Language Function Press the SUBTITLE button during playback. Each time the button is pressed the subtitle language on the screen changes. Multi-Audio Language Function Press the AUDIO button during playback. Each time the button is pressed the audio sound- track language on the screen changes. -
Page 12: Disc Settings
DISC SETTINGS Use the CURSOR buttons DISC setting selections. Press the ENTER button to confirm the setting. Audio Setting Use this screen to setup the audio language on multi-language discs. Subtitle Language Setting Use this screen to setup the subtitle language on multi-subtitle language discs. -
Page 13: Display Settings
VIDEO SETTINGS Use the CURSOR buttons VIDEO setting selections. Press the ENTER but- ton to confirm the setting. TV Aspect Setting Use this screen to setup the desired TV Aspect Ratio. TV System Setting Use this screen to select the TV system. Choose between three modes: NTSC, PAL and Auto. - Page 14 OTHER FUNCTION SETTINGS Use the CURSOR buttons OTHERS setting selections. Press the ENTER button to confirm the setting. JPEG Time Setting Use this screen to setup the JPEG image dis- play time from 1 to 180 seconds. Default Settings Use this screen to reset all menus to the fac- tory default setting Setup Menu Last Play Function...
-
Page 15: Installation
The MV1020 can be mounted using either a Custom Bracket System or a Custom Shroud/ Bracket System (purchased separately). Visit www.magnadyne.com to find a custom mounting system for your vehicle. Custom Bracket Mounting System (Optional) Custom Shroud/Bracket Mounting System (Optional) Installation Vehicle’s Ceiling Support Beams... -
Page 16: Wiring Diagram
Mini DIN Connector Wiring Diagram Audio Video Input (Female RCA) Audio Video Output (Female RCA) Red Wire - Ignition Black Wire - Ground Yellow Wire - Battery Blue Wire - Door (+) Yellow (Video In) White (L-Audio In) Red (R-Audio In) Black (Video Out) White (L-Audio Out) Red (R-Audio Out) -
Page 17: Wiring Instructions
Power Harness Wiring: The 4-wire harness provides battery and ignition 12 volts as well as a chassis ground. Route the power harness to the point in the vehicle that you will make the connections. Red Wire: The red wire in the harness should be connected to a +12 volt power wire that is turned on and of by the position of the ignition key. -
Page 18: Troubleshooting
Only qualified service personnel can remove the cover or service this player. Otherwise the warranty will become invalid. No Power: • Check to see if the player is set to “On”. • Check to see that the power plug of the main unit is properly connected. -
Page 19: Replacement Parts
9 a.m. and 5 p.m. weekdays. If UPS is unable to deliver, your order will be returned and additional shipping charges will be required. We Accept Checks, Money Orders, Visa and Master Card Make Checks Payable to: Magnadyne Corporation FIRST NAME STATE... -
Page 20: Warranty
DVD Remote Control Magnadyne Corporation or its authorized agents will within 1 year from the date of sale to you, repair, replace or refund the retail sales price of said product or any part thereof, at the option of the...
