- Page 1 USB 3.0 to 4K HDMI Adapter User's Manual...
-
Page 2: Table Of Contents
Table of Contents .......... 1 AFETY NSTRUCTIONS ............ 1 OPYRIGHT ............ 1 RADEMARKS REGULATORY COMPLIANCE ...... 2 .......... 2 ONDITIONS CE .............. 2 WEEE ........... 2 NFORMATION INTRODUCTION .......... 3 ............ 3 EATURES .......... 4 ACKAGE ... - Page 3 ‐ ...... 16 ULTI MONITOR CONFIGURATION .......... 17 XTENDED MODE .......... 18 IRROR MODE ......... 19 ET THE PRIMARY MONITOR ........ 19 INDOWS SHORTCUT UNINSTALLING THE DRIVER ......20 TECHNICAL SUPPORT ........ 22 ...
-
Page 4: Safety Instructions
Before attempting to connect, operate or adjust this product, please save and read the User's Manual completely. The style of the product shown in this User's Manual may be different from the actual unit due to various models. Safety Instructions Always read the safety instructions carefully: Keep this User’s Manual for future reference Keep this equipment away from humidity If any of the following situation arises, get the equipment checked by a service technician: The equipment has been exposed to moisture. The equipment has been dropped and damaged. - The equipment has obvious sign of breakage. - The equipment has not been working well or cannot get it to work according to the User’s Manual. Copyright This document contains proprietary information protected by copyright. All right are reserved. No part of this manual may be reproduced by any mechanical, electronic or other means, in any form, without prior written permission of the manufacturer. Trademarks All trademarks and registered trademarks are the property of their respective owners or companies. ... -
Page 5: Regulatory Compliance
Regulatory Compliance FCC Conditions This equipment has been tested and found to comply with Part 15 Class B of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must ... -
Page 6: Introduction
Introduction The USB 3.0 to 4K HDMI Adapter is a device which enables connection to 4K Ultra HD display device to a computer using USB 3.0 port. It will make your legacy PC with old graphics card to support 4K resolution easily. Besides, with this convenient design, it can connect up to 6 display devices to a computer without installing extra video cards. Simply install the driver, and plug in the USB adapter, the connected monitor will be enabled without the need to reboot the operating system. System performance is an important issue when using multiple monitors. Another benefit of this adapter is that it occupies little computer resource; ensuring users get quality display without comprising computer performance. ® Incorporates HDMI technology. Features Supports High Resolution up to 3840x2160 Pixels Backwards compatible with HD/Legacy monitors Access to 4K Ultra HD displays for legacy PCs Supports up to 6 USB display simultaneously Supports Extend and Mirror mode USB bus‐powered ... -
Page 7: Package Contents
Package Contents USB 3.0 to 4K HDMI Adapter x1 USB Cable x1 CD (Driver and User’s Manual) x1 Quick Installation Guide x1 System Requirements Operating Systems: ® ® ® Windows 7/ Windows 8/ Windows 8.1 ... -
Page 8: Product Overview
Product Overview Micro USB Connector HDMI Connector Micro USB connector: Connect to an available USB connector on a computer. HDMI connector: Connect to a desired HDMI device, including 4K Ultra HD display monitor. To connect different types of monitors, you may need a converter. ... -
Page 9: Specification
Specification Host USB 3.0 Connector Interface Video Output HDMI Connector Host USB 3.0 Micro B Type Connector Upstream Link Up to 6 adapters on a computer Connectivity Power Mode Bus‐powered Power Power Operating Mode: 370mA approx. Consumption 640x480 720x400 720x480 Resolution Video 768x576 800x600 832x624 800x480 848x480 1024x600 1024x768 1152x864 1152x870 1280x720 1280x768 1280x800 1280x960 1280x1024 1360x768 1366x768 1368x768... - Page 10 Supported Extended Desktop (Default), Display Mode Mirrored Desktop, Primary Display ® ® Windows 7, Windows 8, Supported ® Windows 8.1 Operating System Housing ABS (Plastic) Physical Properties Color Black Dimension 75.5 (L) x 44 (W) x13.9 (H) mm Weight 30.2 g Operation 10~40 degree Working Temperature Environment Storage ‐20~70 degree Temperature CE, FCC Compliance ...
-
Page 11: Connection
Connection Make sure the device (Desktop, Laptop…) is HDMI embedded or bundled any adapter/connector with HDMI. HDMI Using Multi‐Adapter (Extended Mode) * Able to connect up to 6 displays ... -
Page 12: Installation
Installation Caution: DO NOT connect the adapter to a computer before installing the provided driver Note that the screenshots on this user's manual may vary slightly from each operating system. ® ® ® Windows 7/ Windows 8/ Windows 1. - Page 13 NOTE: If the AutoPlay does not appear automatically, locate and double-click on the Setup.exe file in the driver folder to launch the setup. Enter the administrator password and then click Yes to start the installation if a User Account Control dialog box appears.
-
Page 14: Verifying The Installation
Be patient with the installation procedure. 5. Connect the adapter to a computer after the driver installation is completed. For connection details, refer to the chapter of Connection. 6. When the operating system detects the adapter, the reminder message will appear on the system tray. - Page 15 ® ® Windows 8/ Windows 8.1: Settings\ Control Panel\ System and Security\ System\ Device manager 2. You will find DisplayLink Adapter device listed as below. NOTE: If you cannot find the driver in the list, the driver may not be properly installed. Please delete the item, unplug the adapter and repeat the installation step ...
-
Page 16: Display Configuration
Display configuration NOTE: The following screenshots in this section are ® using Windows 7 operating system. It may not match your operating system but the definitions of buttons, tabs and menus are the same. Utility settings The supplied utility allows configuring the display mode, screen rotation, screen resolution, and physical arrangement of your monitors. -
Page 17: Description Of The Settings
Description of the settings Options Description Displaylink Enable the Windows screen resolution manager page Check for updates Check the latest driver and download if available Audio Setup Enable the Windows audio configuration page. This function works only in specific models. Video Setup Enable the Windows screen resolution page. - Page 18 Mirror Duplicate the primary monitor to the monitor which connects with the adapter Turn off the monitor Fit to TV Adjust the size of Windows Desktop on the TV NOTE: This function works only when one add-on monitor is connected. Besides, this option will also only work in extended mode.
-
Page 19: M Ulti ‐ Monitor Configuration
Multi-monitor configuration An extra HDMI monitor can be connected through the adapter directly. Once the extra monitor is connected, it can be configured to use either “mirror mode”, “extended mode” or be the primary display. Position the mouse anywhere on the Windows Desktop, Right‐click and select Screen Resolution. Alternatively, click the utility icon in the Windows ... -
Page 20: E Xtended Mode
Extended mode Refer to the Multi-monitor configuration section to bring up the configuration window. In the Display drop-down menu, select the preferred monitor. Select Multiple Displays > Extend these displays. Click OK to confirm and exit. 2 3 Once the setting is completed, simply drag and drop the application icons or the opened windows to the add-on monitor. -
Page 21: M Irror Mode
Mirror mode Refer to the Multi-monitor configuration section to bring up the configuration window. In the Display drop-down menu, select the preferred monitor. Select Multiple Displays > Duplicate these displays. Click OK to confirm and exit. ... -
Page 22: S Et The Primary Monitor
Set the primary monitor Refer to the Multi-monitor configuration section to bring up the configuration window. In the Display drop-down menu, select the preferred monitor. Check the box of Make this my main display. NOTE: For some computers, you may need to disable the main display by unchecking the box of Extend the desktop onto this monitor or Extend my Windows desktop onto this... - Page 23 Uninstalling the driver 1. Follow the instructions to find the driver path, and then right-click on DisplayLink Graphics to uninstall the driver. ® Widnows Control Panel > Programs > Programs and Features > Uninstall or change the program ® ®...
- Page 24 3. Click Yes to restart your computer. You can also disconnect the video connection now. ...
-
Page 25: Technical Support
Technical Support Good Way offers customers diversified products and complete sales services. We look forward to your comments to provide you with better service. If you have any technical or application issues about our products, please contact us through Good Way FAQ website: http://www.goodway.com.tw/faq.asp Simply fill in the required information on the website... - Page 26 USB 3.0 to 4K HDMI Adapter User's Manual V1.0...
