- Page 1 Ableconn Mini DP 1.2 to VGA Adapter User's Manual User's Manual www.ableconn.com support@ableconn.com...
- Page 2 User's Manual...
-
Page 4: Table Of Contents
Table of Contents - Safety Instructions ............2 - Copyright ..............2 - Trademarks ..............2 Introduction............- Features ................ 3 - Package Contents ............4 - System Requirements..........4 Product Overview ..........- Connection ..............5 Extended/mirror mode ......... Specification ............ -
Page 5: Safety Instructions
Before attempting to connect, operate or adjust this product, please save and read the User's Manual completely. The style of the product shown in this User's Manual may be different from the actual unit due to various models. Safety Instructions Always read the safety instructions carefully: ■... -
Page 6: Introduction
Introduction The Mini DisplayPort to VGA Adapter enable you to connect any VGA interface embedded device (Monitor, Projector…) with a Mini DisplayPort interface (Desktop, Laptop) and no need to purchase any Mini DisplayPort embedded terminal device. Features Compliance with Mini DP specification V1.2, VESA DDM ■... -
Page 7: Package Contents
Package Contents ■ Mini DP to VGA Adapter ■ User’s Manual System Requirements ® 7, Windows ® 8 Windows ® 8.1 ■ It works with Windows Windows ® 10 and Mac ® OS... -
Page 8: Product Overview
Product Overview receptacle Mini DisplayPort plug Connection Check the following information before connecting to a mini display device. ■ The product DO NOT need any external drivers. ■ This product is the adapter for connecting mini DisplayPort to VGA port. ■... - Page 9 ■ A VGA male to male cable is necessary when connecting to a terminal device. (Note this cable is not supplied) Windows ® 8.1 ® ® ■ Windows 7, Windows Windows ® 10 operation system is necessary when switching to eyefinity mode...
-
Page 10: Extended/Mirror Mode
Extended/mirror mode Plug a VGA male connector into the VGA receptacle of Adapter, and the other end to a VGA embedded (Cable of VGA male to male is not supplied) device. Plug the Mini DisplayPort into a Mini-DisplayPort embedded device. Configure the display settings ®... - Page 11 Mac ® OS System Preference>Displays. Adjust your preference mode by Arrangement. Note: Move white top bar can set your Main screen.
- Page 12 Eyefinity mode Eyefinity is a technology of multi-display from AMD (previously ATI) which supporting to connect three to six displays to one graphic card. For the supported graphic cards, refer to AMD website. Connect an embedded Mini-DisplayPort device to an embedded VGA device as diagram below.
-
Page 13: Specification
Specification Item Description Host Interface MiniDP Connectors Power Mode MiniDP Normal Mode: 230mA Power Consumption 1920x1200 Housing Aluminum Windows ® 7, Windows ® 8, OS compliance Windows ® 8.1, Windows ® 10, Mac OS ® X 40 x20 x 14 mm Dimensions (LxWxH) Weight 32.4g... -
Page 14: Regulatory Compliance
Regulatory Compliance FCC Conditions This equipment has been tested and found to comply with Part 15 Class B of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received and include interference that may cause undesired operation. - Page 17 Mini DP 1.2 to VGA Adapter User's Manual V2.0...
