OWNER'S MANUAL
™
Gourmet Series Marine Gas Grill
Model A10-918
For questions regarding performance, assembly,
operation, parts, or returns, contact the experts
at MAGMA by calling TOLL FREE IN U.S.A. AND
CANADA 1-800-86-MAGMA
7:00 a.m. - 5:00 p.m. Pacific Time Monday thru
Friday or e-mail us at mail@MagmaProducts.com
Read all instructions before operating. Save manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Newport A10-918 and is the answer not in the manual?

Questions and answers

Related Manuals for Magma Newport A10-918

Summary of Contents for Magma Newport A10-918

  • Page 1 Model A10-918 For questions regarding performance, assembly, operation, parts, or returns, contact the experts at MAGMA by calling TOLL FREE IN U.S.A. AND CANADA 1-800-86-MAGMA 7:00 a.m. - 5:00 p.m. Pacific Time Monday thru Friday or e-mail us at mail@MagmaProducts.com...

  • Page 2: Important Safety Warnings

    • USE PROPANE GAS ONLY. FUEL STORAGE SHOULD BE IN COMPLIANCE WITH THE AMERICAN BOAT AND YACHT COUNCIL (ABYC) STANDARDS A-1 (9), MARINE LIQUIFIED PETROLEUM GAS (LPG) SYSTEMS. • FOR NATURAL GAS APPLICATION CONTACT MAGMA. • ALWAYS LIGHT GRILL WITH LID OPEN. • NEVER LEAVE HOT GRILL UNATTENDED.
  • Page 3 ON-BOARD FUEL SYSTEMS APPLICATION •For on-board LPG (Propane) Systems, use Magma Type 3-Low Output- Low Pressure LPG Control Valve and Magma Low Pressure LPG Hose Kit. •For on-board CNG (Natural Gas) Systems, use Magma Type 4-Low Output- Low Pressure Natural Gas Control Valve.

  • Page 4: Operating Procedures

    OPERATE ONLY ON “LOW” WHEN LID IS CLOSED. ALWAYS OPERATE WITH GREASE TRAY IN PLACE. WARNING: Do not overheat grill. Magma Grills do not require pre-heating. Stainless Steel loses anti-corrosive characteristics when subjected to extreme heat. Most grilling is done on low temperature with the lid closed. If medium or high heat is required, grill with lid open.
  • Page 5 • Lift radiant plate up & out of left slot (see B) and remove by sliding it out of right slot (see C). • Remove burner screw (see B) and remove burner. Check burner for grease residue or spider webs that may obstruct gas flow. CAUTION: WHEN REPLAC- ING BURNER, CUT SLOT IN BURNER MUST FACE DOWN.

  • Page 6: Maintenance

    Control Valve - All valves are set and tested at our factory. Do not attempt to adjust or disassemble the valve in any way. Call Magma if you suspect it is not adjusted properly. Clean valve with a cloth and remove any debris obstructing the orifice.
  • Page 7 • DO NOT CONNECT A HIGH-PRESSURE SUPPLY HOSE FROM A NON-REGULATED TANK DIRECTLY TO GRILL. Magma's grills are designed for use with small disposable propane canisters or with pre- regulated low-pressure propane and optional low-pressure valves. Running high-pressure propane fuel supply lines on a boat is in violation of American Boat & Yacht Council (ABYC) guidelines and is not considered a safe application.

  • Page 8: Troubleshooting Guide

    Clean igniter electrode Adjust electrode until proper spark appears (see page 5) Reconnect wire between ignit- er & electrode (see page 5) Call Magma Call Magma Check fuel level, refill cylinder or replace canister Clean valve orifice and burner, check all lines (see page 6)

  • Page 9: Limited Warranty

    U.S. Postal Service mail at “Magma Products, Inc., attention Customer Service, 3940 Pixie Ave. Lakewood, CA, 90712.“ The defective part, along with proof of purchase, must be returned postage prepaid to Magma Products, Inc. We suggest that you keep your purchase receipt as we may require reasonable proof of purchase.
  • Page 10 A10-918AU-1, A10-918AU-2, A10-918AU-3 A10-1218AU-1, A10-1218AU-2, A10-1218AU-3 A10-1225AU-1, A10-1225AU-2 & A10-1225AU-3 CAUTION: Accessible parts may be very hot. Keep young children away. • CARBON MONOXIDE HAZARD-THIS APPLIANCE CAN PRODUCE CARBON MONOXIDE (no odour). Do not use in enclosed areas, (for example: car, tent, caravan, mobile home) may cause death.
  • Page 11 Connecting Type 1 & Type 2 Valves to Gourmet Series Grills For Models A10-918AU-3, A10-1218AU-3 & A10-1225AU-3 Connecting Low Pressure Pre-Regulated Propane (LPG) to Gourmet Series Grills Gourmet Gas Grill Align valve stem key to valve chamber lock detent and rotate...
