Mega TRIPAR Profile Plus
Master-Slave Configuration:
This function will allows you to link units together to run in a Master-
Slave set-up. In a Master-Slave set-up one unit will act as the controlling
unit and the others will react to the controlling units built-in programs.
Any unit can act as a Master or as a Slave however, only one unit can be
programmed to act as the "Master."
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit.
Use standard XLR data cables to link your units together. Remember
that the Male XLR connector is the input and the Female XLR con-
nector is the ouput. The first unit in the chain (master) will use the
female XLR connector only. The last unit in the chain will use the
male XLR connector only.
2. Connect the first "Slave" unit to the "Master."
3. Set the "Master" unit to your desired mode of operation. Set the
"Slave" unit(s) to the DMX address setting.The "Slave" unit(s) will now
follow the "Master".
ADJ Products, LLC - www.adj.com - Mega TRIPAR Profile Plus User Manual Page 12
Master-Slave Configuration Mega TRIPAR Profile Plus
The ADJ LED RC2 infrared remote (sold seperately) has many dif-
fernet functions and gives you complete control of your Mega TRIPAR
Profile Plus. To control the your desired fixture you must aim the con-
troller at the front of the fixture and be no more the 30 feet away. To
use the ADJ LED RC2 you must first activate the fixtures infrared re-
ceiver, to activate the receiver please see the instructions on page 11.
BLACKOUT - Pressing this button will blackout the fixture.
PROGRAM SELECTION - This button will let you access color
change mode, color fade mode, auto run mode, or static color mode.
Each press of this button will scroll change to the next mode. When
you found your desired mode use the "+" or "-" to scroll through the
programs or static colors. You can also use the number keys to se-
lect your desired program or color. When using the auto run, color
fade, or color change, press the Speed button and use the "+" or "-"
to adjust the running speed.
• If the Red LED's flash you are in Color Fade Mode.
• If the Green LED's flash you are in Color Change Mode.
• If the Blue LED's flash you are in Auto Run Mode.
• If the UV LED flashes you are in Static Color Mode.
FLASH - This button will activate the strobe effect. You can control
the flash rate by pressing the "+" and "-" buttons. Press this button
again to exit strobe mode.
SPEED - Press this button and use the "+" & "-" buttons to adjust
the speed of the auto run, color change, and color fade or adjust the
sound sensitivity in sound active mode.
DMX MODE - Pressing his button will scroll through DMX address-
ing, DMX Channel mode, DMX last state setting, and dimming curves.
Some fixtures will come with different DMX channel modes. When
your desired menu/submenu is found, use the "+" & "-" buttons to
scroll through the settings. See page 14 for DMX control. See pages
16-23 for DMX modes, values, and traits.
SLAVE/SA (SOUND ACTIVE) - This button activate sound active
mode. In sound active mode use the "+" and "-" buttons to scroll
through the 16 sound active programs. You can also use the number
buttons to select your Sound Active program. Press the Speed but-
ADJ Products, LLC - www.adj.com - Mega TRIPAR Profile Plus User Manual Page 13
ADJ LED RC2 Operation
