- Page 1 U S E R ’ S G U I D E 5770/5990/6100/6405 SERIES Safety Instructions Product View Assembly 6–9 Operations 10–15 Maintenance and Care 16–17 Troubleshooting Consumer Services Replacement Parts Warranty EN-CA-REV2_ug203-1369_5770_706.i1 1 8.8.2006 16:02:54...
- Page 2 Consumer Services department, so, should you ever have a question, you’ll receive fast, considerate assistance. My great-grandfather invented the floor sweeper in 1876. Today, BISSELL is a global leader in the design, manufacture, and service of high quality homecare products like your Healthy Home Vacuum.
-
Page 3: Important Safety Instructions
MPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic T urn off all controls before plugging or unplugging ■ precautions should be observed, including vacuum cleaner. the following: U se extra care when cleaning stairs. ■ REaD all InStRUctIonS Unplug before attaching the TurboBrush. - Page 4 Upper Handle Power Switch Hose TurboBrush Release Button Carrying Handle Brush Switch Filter Door Latch HEPA Filter Cartridge (inside) Quick Release Screen Cord Wraps Power Cord Crevice Tool Dirt Container Headlight Hose Wand Filter Tray (foam Height filter inside) Wand Base Adjustment Dial Diverter...
-
Page 5: A Ssembling Your Vacuum
caUtIon : ssembling your vacuum Do not plug in your vacuum cleaner until tool required: phillips screwdriver you are familiar with 1. Slide upper handle onto lower handle. Insert all instructions and one screw into hole marked with an arrow operating procedures. and tighten until snug. 2. Attach hose by lining up the tabs on the collar with the corresponding notches on the back of the vacuum as shown. Turn clockwise to lock the hose into place. 3. Wrap the hose by routing it down and into the lower hose clip then up and over the top of the handle. Insert the hose wand fully into the hose base. note: It is important that the hose is fully inserted into the base for the suction air to be directed properly to the foot during floor... -
Page 6: Handle Positions
sing your vacuum cleaner Transporting your cleaner Use the handle on the front to carry the cleaner or place the cleaner in the upright position and tip back to roll on the rear wheels. Releasing the power cord the upper and lower cord wraps rotate to allow for quick and easy removal of the power cord. - Page 7 sing your vacuum continued Fingertip brush switch the rotating brush is turned on or off using the switch at the side of the top of the handle. the brush will start rotating when the unit is reclined. the brush should be on for most carpeted floors. you may want to turn the brush off for bare floor cleaning or other delicate surfaces.
-
Page 8: Using The Tools
attEntIon : sing the tools always place the vacuum cleaner on the floor in its fully Make sure the cleaner is in the upright upright position when using position. tools. placing the vacuum in this position automatically Remove the hose wand from the wand stops the rotating brush. base. This automatically diverts the suction to the hose. Unwind the hose from the cleaner. note: to help prevent the machine from tipping, the hose should remain in the bottom hose clip. -
Page 9: E Mptying The Dirt Container
caUtIon : Make sure vacuum cleaner mptying the dirt container has been switched off and unplugged before removing Empty the dirt container as soon as the dirt dirt container. reaches the “full” line on the side of the container. 1. Press the release button on top of the carrying handle to remove the dirt container. -
Page 10: Cleaning The Foam Filter
aintenance and care Cleaning the dirt container to reduce the risk of electric shock, turn power additional steps can be taken to clean the dirt switch off and disconnect container as necessary. polarized plug from electrical 1. Ensure the dirt container has been emptied. outlet before performing maintenance or troubleshooting checks. - Page 11 More or less frequent replacing may be required based on individual vacuuming habits and types of debris picked up. note: to have the benefits of the airetight hEpa System, you must use the bISSEll hEpa filter cartridge. To remove the HEPA filter cartridge, push down on the filter door latch and pull door away from the cleaner. Lift the tab at the top of the HEPA filter cartridge and pull cartridge away from the cleaner.
- Page 12 aintenance and care continued clearing clogs low suction or poor pickup may be due to a clog in the vacuum cleaner. If you notice a change in the sound of the motor or a reduction in the spinning action in the dirt container, check for a clog.
-
Page 13: Thermal Motor Protection
When the motor cools for approximately 30 minutes, the thermal protector automati- cally resets and cleaning may continue. If the cleaner will not turn on or the thermal protector continues to activate, your cleaner may need servicing. Call BISSELL Consumer Services or visit the website. note: the thermal protector controls the main vacuum motor only, not the brush motor. If the thermal protector activates, the brush will continue to operate normally; however, there will be no suction. -
Page 14: Brush Maintenance
Do not attempt to disassemble the vacuum foot or to remove the brush roll. If you feel it needs to be checked or replaced, call bISSEll consumer Services or visit the website to locate an authorized service centre. Belt maintenance... -
Page 15: Changing The Light Bulb
aintenance and care continued Changing the light bulb 1. Unplug cleaner from electrical outlet. 2. Recline handle for easier access to light bulb and remove screw to lift off lens. 3. Remove the bulb by grasping bulb and pull- ing straight out of the socket. Install the new bulb by pushing gently into the socket until the bulb snaps into place. TurboBrush maintenance the turbobrush should be checked regularly for clogs or debris wrapping around the brush. 1. Remove tool from hose or front of vacuum. 2. Twist collar so opening is at the top and lift top cover to remove. 3. Remove the brush from the belt and clean debris. -
Page 16: Troubleshooting
roubleshooting to reduce the risk of electric shock, turn power off and discon- nect polarized plug from electrical outlet before performing maintenance or troubleshooting. Vacuum cleaner won’t turn on possible causes Remedies 1. Power cord not plugged in 1. Check electrical plug 2. Blown fuse/tripped breaker 2. Check/replace fuse or reset breaker. 3. Thermal protector activated 3. Allow cleaner to cool for 30 minutes, see pg. 13. -
Page 17: Please Do Not Return This Product To The Store
If you should happen to need assistance during assembly or operations, call 1-800-263-2535 please do not return this product to the store for any questions or concerns, bISSEll is happy to be of service. contact us directly at 1-800-263-2535. w w w . b i s s e l l . c a 8 0 0 . - Page 18 Niagara Falls, ON L2E 6W2 ATTN: Consumer Services Or visit the BISSELL website - www.bissell.ca When contacting BISSELL, have model number of cleaner available. Please record your Model Number: ___________________ Please record your Purchase Date: ___________________ notE: please keep your original sales receipt. It provides proof of date of purchase in the event of a warranty claim.
- Page 19 Replacement parts are available through bISSEll consumer Services, an authorized bISSEll Service centre or by visiting our website. below is a list of common replacement parts*. While not all of these parts may have come with your specific model, they are avail- able for purchase if desired.
-
Page 20: Limited Two-Year Warranty
Niagara Falls, ON L2E 6W2 bISSEll canaDa coRpoRatIon IS not lIablE foR IncIDEntal oR conSEQUEntIal DaMaGES of any natURE aSSocIatED WIth thE USE of thIS pRoDUct. bISSEll’S lIabIlIty WIll not EXcEED thE pURchaSE pRIcE of thE pRoDUct. *EXcEptIonS anD EXclUSIonS fRoM thE tERMS of thE lIMItED WaRRanty thIS WaRRanty IS EXclUSIVE anD In lIEU of any othER WaRRantIES EIthER oRal oR WRIttEn.
