- Page 1 AIR SOURCE HEAT PUMP WATER HEATER Installation & Instruction Manual Model: SWBC-13.5H-B SWBC-19.5H-B-S SWBC-24.0H-A-S...
-
Page 2: Table Of Contents
Water heater Contents CONTENTS Ⅰ.To our customers(before installation) -------------------------------------------------1 Ⅱ.Product Introducing -----------------------------------------------------------------------2 Ⅲ.Work principle ------------------------------------------------------------------------------3 Ⅳ.Performance Data --------------------------------------------------------------------------4 Ⅴ .Dimension ------------------------------------------------------------------------------------5 Ⅵ.Operation introductions ------------------------------------------------------------------7 Ⅶ.Wire Circuit Diagram --------------------------------------------------------------------11 Ⅷ.Installation instructions -----------------------------------------------------------------13 Ⅸ .Maintenance--- -----------------------------------------------------------------17... -
Page 3: Ⅰ.to Our Customers(Before Installation)
Water heater Ⅰ.To our customers Dear Sir: In order to use this machine safely, please read this INTRUCTION MANUAL carefully before using and installation. Heat pump water heater is a professional machine, it may cause damage or hazard when wrong installed, it should be installed by a competent person in accordance with the relevant standards for the country of use. -
Page 4: Ⅱ.product Introducing
Water heater Ⅱ.Product Introducing Product Introducing Safe and Reliable Unlike traditional electric water heater, heat pump water heater do not directly generate heat by electricity , it use less electricity to move heat from one place to another , electric circuit is separated from water circuit ,which is also not easy for electric shock, inflammable , explosion and poisoning ! Safer and more reliable! Highly efficient &... -
Page 5: Ⅲ.work Principle
Water heater Ⅲ.Work principle Work principle The low temperature and low pressure refrigerant gas come from the evaporate to the compressor, After the compressor compress it , the refrigerant gas became high temperature and high pressure. Then the gas come into the water condensation into liquid, emit a lot of condensation heat, condensing heat absorbed by water, making the water temperature increased, and then the liquid refrigerant come through the expansion valve, with a fan , the evaporate heat in the air, after all evaporation , the low pressure compressor refrigerant gas inhalation in the compressor, after... -
Page 6: Ⅳ.performance Data
Water heater Ⅳ.Performance Data Performance Data Air source heat pump water heater sidewind series Model SWBC-13.5H-B SWBC-19.5H-B-S SWBC-24.0H-A-S Rated heating capacity(w) 24000 13500 19500 Power supply(V/Ph/Hz) 220V/1PH/50HZ 380V/3PH/50HZ Input power(kw) Running current(A) 16.7 7.5x3 11.2x3 Circulating unit hot water generated(L/h) 1020 ℃... -
Page 7: Ⅴ.dimension
Water heater Ⅴ.Dimension The dimension for air source heat pump water heater SWBC-13.5H-B SWBC-19.5H-B-S SWBC-24.0H-A-S Measure: mm Model SWBC-19.5H-B-S SWBC-13.5H-B Size 1115 1115 1250... - Page 8 Water heater Ⅴ.Dimension The dimension for High efficiency tube in shell heat exchanger Measure: mm Model SWBC-13.5H-B Size Measure: mm Model SWBC-24.0H-A-S SWBC-19.5H-B-S Size...
-
Page 9: Ⅵ.operation Introductions
Water heater Ⅵ.Operation introductions 1) Controller introduction Cooling mode Heating mode Tank outlet temp Set point temp First timer Clock Timer on Timer off Timer on/ off sign Second timer ON/OFF MODE TIMER UP/DOWN 2) Wire Controller Operation Press button to turn on or turn off the unit. Press button to choose heating mode. - Page 10 Water heater Ⅵ.Operation introductions Press to directly adjust the temperature. Press button and button at the same time, can turn on/off electrical heating. Press button and buttons for 3 seconds, force defrosting function is on. Press button once, to enter clock setting. Under stand by/start-up state, press button, when the place which shows hour is flashing, press...
- Page 11 Water heater Ⅵ.Operation introductions Press to enter the setting of timer on and timer off (Totally you may set 2 difference timers on and timer off.) Under the stand by/start-up state, press button shows hour data and“ON”“1” flashed, press to adjust the hour; press button again，shows minute data and“ON”“1”flashed，...
- Page 12 Water heater Ⅵ.Operation introductions Malfunction data Code Malfunctions Solution Communication failure Water tank sensor failure Ambient temp sensor failure Coil temp sensor failure Exhaust temp sensor failure Gas suction temp sensor failure Water inlet temp sensor failure Water flow switch protection High pressure protection ( 3 times within 1 hour) Low pressure protection ( 3times within 1 hour) Exhaust temp too high protection...
-
Page 13: Ⅶ.wire Circuit Diagram
Electronic Water inlet temp sensor Wire Expansion Controller S1 Second set point Valve S2 Long distance demand for heating SWBC-19.5H-B-S Applicable model: AIR SOURCE HEAT PUMP WIRING DIAGRAM AC contactor Compressor TO AC CONTACTOR OF E-HEATER TO AC CONTACTOR OF WATER PUMP... - Page 14 Water heater Ⅶ.Wire Circuit Diagram Wire Circuit Diagram Applicable model: SWBC-24.0H-A-S AIR SOURCE HEAT PUMP WIRING DIAGRAM COMP Electronic Expansion Valve 4-WAY C B A OUT1 OUT2 OUT3 OUT4 OUT5 OUT6 OUT7 OUT8 OUT9 TH1 TH2 TH3 TH4 TH5 TH6 TH7 R S T N 2 2 2 2 2 2 2 2...
-
Page 15: Ⅷ.installation Instructions
Water heater Ⅷ.Installation instructions Installation instructions 1. Unit installation 1).Installation location Host unit 1 Should be installed in a larger & well-ventilated place. 1 Installation location should ensure unhindered access outlet (inlet & outlet shown as below). 1 Install gutter or set up positions near the outfall, to facilitate the drainage. 1 The installation base or bracket should be steady, to ensure the smooth operation of running units. -
Page 16: Installation Instructions
Water heater Ⅷ.Installation instructions Installation instructions 2. Pipeline connecting Installation notes: 1 Water drain pipes, overflow pipes should be installed next to the drainage inlets to facilitate drainage, vent valve should be installed on vent pipes. 1 Repair valve should be installed in front of the electromagnetic valve on the pipeline system, which is convenient for future repair. -
Page 17: Installation Instructions
Water heater Ⅷ.Installation instructions Installation instructions High water level Low water level User Water Tank Constant Temp Controller Extra electric thermal controller Cycling pump (Inside) Discharge pipe Single valve Constant temp controller 45℃ water flow meter Constant Temp 50℃ Controller temp sensing controller 55℃... - Page 18 Water heater Ⅷ.Installation instructions Running Test and operation 2.Running test This running test must be performed by professional staff! 1 Overall test can be run if the entire system inspection is conformed to regulations. 1 Connected to power, start the heat pump, host unit delays three minutes then auto-start. For three-phase power supply unit, first check whether the fans and pumps' rotary direction correct or not, if not, immediately shut down the power and adjust phase sequence.
-
Page 19: Ⅸ.maintenance
Water heater Ⅸ.Maintenance Maintenance Heat pump water heater is a high automatic equipment, please perform regular inspection termly. If the unit can be long-term and efficiently maintenance, the operating reliability and service life will have an unexpected increase. 1.The extra water filters should be cleaned regularly to ensure clean water quality of the system, and to avoid damage caused by dirty water filter blocking. - Page 20 Air Source Heat Pump-Water Heater...
