- Page 1 LOW AMBIENT HEAT PUMP WATER HEATER Installation & Instruction Manual MODEL: SWBM-10.5H-B/P-S SWBM-17.5H-B/P-S SWBM-35.0H-B-S...
-
Page 3: Table Of Contents
Water heater Contents CONTENTS Ⅰ.To our customers ----------------------------------------------------------------------------1 Ⅱ.Product Introducing -----------------------------------------------------------------------2 Ⅲ.Work principle ------------------------------------------------------------------------------3 Ⅳ.Performance Data --------------------------------------------------------------------------4 Ⅴ .Dimension ------------------------------------------------------------------------------------5 Ⅵ.Operation introductions ------------------------------------------------------------------8 Ⅶ.Wire Circuit Diagram --------------------------------------------------------------------14 Ⅷ.Installation instructions -----------------------------------------------------------------16 Ⅸ.Maintenance --------------------------------------------------------------------------------20... -
Page 4: Ⅰ.to Our Customers
Water heater Ⅰ.To our customers Dear Sir: In order to use this machine safely, please read this INTRUCTION MANUAL carefully before using and installation. Heat pump water heater is a professional machine, it may cause damage or hazard when wrong installed, it should be installed by a competent person in accordance with the relevant standards for the country of use. -
Page 5: Ⅱ.product Introducing
Water heater Ⅱ.Product Introducing Product Introducing Safe and Reliable Unlike traditional electric water heater, heat pump water heater do not directly generate heat by electricity , it use less electricity to move heat from one place to another , electric circuit is separated from water circuit ,which is also not easy for electric shock, inflammable , explosion and poisoning ! Safer and more reliable! Highly efficient &... -
Page 6: Ⅲ.work Principle
Water heater Ⅲ.Work principle Work principle The low temperature and low pressure refrigerant gas come from the evaporate to the compressor, After the compressor compress it , the refrigerant gas became high temperature and high pressure.Then the gas come into the water condensation into liquid, emit a lot of condensation heat,condensing heat absorbed by water, making the water temperature increased, and then the liquid refrigerant come through the expansion valve, with a fan , the evaporate heat in the air, after all evaporation , the low pressure... -
Page 7: Ⅳ.performance Data
Water heater Ⅳ.Performance Data Performance Data Model SWBM-10.5H-B/P-S SWBM-17.5H-B/P-S SWBM-35.0H-B-S 10.5 17.5 Rated Heating Capacity BTU/h 36000 60000 120000 Heating Input Power 2800 4800 9700 Running Current Heating 4.5 ×3 7.6×3 15.3×3 Power Supply V/PH/Hz 380/3/50 380/3/50 380/3/50 Compressor Type Scroll Compressor Nos. -
Page 8: Ⅴ.dimension
Water heater Ⅴ.Dimension The dimension for air source heat pump water heater SWBM-10.5H-B/P-S Measure: mm... - Page 9 Water heater Ⅴ.Dimension The dimension for air source heat pump water heater low ambient SWBM-17.5H-B/P-S 1300 Measure: mm...
- Page 10 Water heater Ⅴ.Dimension The dimension for low ambient air source heat pump water heater SWBM-35.0H-B-S 1580 Measure: mm...
-
Page 11: Ⅵ.operation Introductions
Water heater Ⅵ.Operation introductions Operation introductions 1. Initialization Initialization Stand by state Start-up state ◎ Under start-up state, LCD screen left side displays the water inlet setting temperature, right side displays the actual water inlet temperature ; Under stand-by state, LCD main interface only displays the actual water inlet temperature on the right side . - Page 12 Water heater Ⅵ.Operation introductions Operation introductions " for Timer 2.5 " 2.5.1 Press to enter the setting of Timer On and Timer Off (Totally you may set 3 sets of different Timer On and Timer Off), and press “ ”/ “ ”...
- Page 13 Water heater Ⅵ.Operation introductions Operation introductions Timer on Timer off Timer setting setting setting 3.4 Timer On & Timer Off Setting 3.4.1 On main interface, press to switch among 3 sets of Timer setting. “ ” 3.4.2 After entering the Timer On setting interface, press once to enter current “...
- Page 14 Water heater Water heater Ⅵ.Operation introductions Ⅵ.Operation introductions Operation introductions Operation introductions 3.5 System Parameter & Status Inquiry On main interface, press “ ” to enter the inquiry interface of temperature sensor ”and“ ”can check each parameter status. and electric expansion status, press“ Parameter Content Range...
- Page 15 Water heater Ⅵ.Operation introductions Operation introductions 3.5.2 On the interface of Parameter and Status inquiry , if not pressing any button within 10 seconds, system automatically exit the inquiry interface and return to main interface, To press directly “ ”ON/OFF or “ ”...
- Page 16 Water heater Ⅵ.Operation introductions Operation introductions 3.8.2 When S1 disconnected, set point temp control by LCD controller. (Refer to the setting of Parameter 20 (default setting 40 deg c). 3.8.3 Heat pump will turn on when S2 switch has well connected.However, S2 well connected, and suddenly press the off button on the LCD controller.Heat pump will stop for 3 minutes.
-
Page 17: Ⅶ.wire Circuit Diagram
Ⅶ.Wire Circuit Diagram Water heater Wire Circuit Diagram Applicable model: SWBM-10.5H-B/P-S SWBM-17.5H-B/P-S LOW AMBIENT HEAT PUMP WIRING DIAGRAM Inlet Water Temp Water Pump Economizer outlet Temp Fan Motor Outlet Water Temp Ambient Temp Economizer inlet Temp Air fin evaporater coil tube Temp... - Page 18 Ⅶ.Wire Circuit Diagram Water heater Wire Circuit Diagram Applicable model: SWBM-35.0H-B-S LOW AMBIENT HEAT PUMP WIRING DIAGRAM SWBM-35.0H-B-S Fan Motor Fan Motor F M 4 F M 3 F M 2 F M 1 Electric heater Water Pump 9 10 11 12 13 14 Compressor side air discharge Temp.
-
Page 19: Ⅷ.installation Instructions
Ⅷ.Installation instructions Water heater Installation instructions 1. Unit installation 1).Installation location Host unit 1 Should be installed in a larger & well-ventilated place. 1 Installation location should ensure unhindered access outlet (inlet & outlet shown as below). 1 Install gutter or set up positions near the outfall, to facilitate the drainage. 1 The installation base or bracket should be a steady, to ensure the smooth operation of generating units. - Page 20 Ⅷ.Installation instructions Water heater Installation instructions 2. Pipeline connecting Installation notes: 1 Water drain pipes, overflow pipes should be installed next to the drainage inlets to facilitate drainage, vent valve should be installed on vent pipes. 1 Repair valve should be installed in front of the electromagnetic valve on the pipeline system, which is convenient for future repair.
- Page 21 Ⅷ.Installation instructions Water heater Running Test and operation 1. Preparatory work before the running test. a) Inspection of heat pump water heater units: 1Check if the unit appearance and the pipeline system were damaged during transport. 1Check if there is air exist in the water pipes, if yes, should empty all the air inside by the manual exhaust valve and the exhaust valve on the water pumps.
- Page 22 Ⅷ.Installation instructions Water heater Running Test and operation 2.Running test This running test must be performed by professional staff! 1 Overall test can be run if the entire system inspection is conformed to regulations. 1 Connected to power, start the heat pump, host unit delays three minutes then auto-start. For three-phase power supply unit, first check whether the fans and pumps' rotary direction correct or not, if not, immediately shut down the power and adjust phase sequence.
-
Page 23: Ⅸ.maintenance
Ⅸ.Maintenance Water heater Maintenance Heat pump water heater is a high automatic equipment, please perform regular inspection termly. If the unit can be long-term and efficiently maintenance, the operating reliability and service life will have an unexpected increase. 1.The extra water filters should be cleaned regularly to ensure clean water quality of the system, and to avoid damage caused by dirty water filter blocking. - Page 24 Air Source Heat Pump-Water Heater...
