Z170 PRO GAMING specifications summary
ASUS gaming
features
Rear Panel I/O
ports
viii

Performance Optimization

ASUS Dual Intelligent Processors 5
- 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+
VRM, Fan Xpert 3, and Turbo App
DIGI+ VRM
- ASUS DIGI+ VRM utility
EPU
- EPU
TPU
- Auto Tuning, TurboV, GPU Boost
Fan Xpert 3 featuring Fan Auto Tuning function and multiple thermistors
selection for optimized system cooling control
RAMCache
Media Streamer
- Pipe music or movies from your PC to a smart TV, your entertainment goes
wherever you go!
- Media Streamer app for portable smartphone/tablet, supporting iOS 7 &
Android 4.0 systems
EZ DIY
Push Notice
- Monitor your PC status with smart devices in real time
UEFI BIOS EZ Mode featuring friendly graphics user interface
- O.C. Tuner
- CrashFree BIOS 3
- EZ Flash 3
Q-Design
- ASUS Q-Shield
- ASUS Q-DIMM
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
ASUS Exclusive Features
- USB 3.1 Boost featuring speedy USB 3.1 transmission
- AI Suite 3
- Disk Unlocker
- AI Charger+
- ASUS CPU-Z
1 x PS/2 keyboard/mouse combo port
1 x Optical S/PDIF out
1 x DisplayPort
1 x DVI port
1 x HDMI port
1 x D-Sub port
1 x LAN (RJ-45) port
2 x USB 2.0 / 1.1 ports
4 x USB 3.0 / 2.0 ports
2 x USB 3.1 ports (1 Type-A, red; 1 Type-C, black)
8-channel audio I/O ports
(continued on the next page)
