13. USB 3.0 ports 3~6. These 9-pin Universal Serial Bus (USB) ports are for USB 3.0
devices.
• The plugged USB 3.0 device may run on xHCI or EHCI mode, depending on the
operating system's setting.
• USB 3.0 devices can only be used for data storage.
• We strongly recommend that you connect USB 3.0 devices to USB 3.0 ports for faster
and better performance from your USB 3.0 devices.
• Due to the design of the Intel
USB 2.0 and USB 3.0 ports are controlled by the xHCI controller. Some legacy USB
devices must update their firmware for better compatibility.
• Multi-VGA output supports up to three displays under Windows
displays under BIOS, and one display under DOS.
• Intel display architecture design supports the following maximum supported pixel
clocks (Pixel Clock = H total x V Total x Frame Rate (Screen refresh rate)):
-
-
-
-
14. DVI-D port. This port is for any DVI-D compatible device.
DVI-D can not be converted to output from RGB Signal to CRT and is not compatible with
DVI-I.
15. HDMI port. This port is for a High-Definition Multimedia Interface (HDMI) connector,
and is HDCP compliant allowing playback of HD DVD, Blu-ray, and other protected
content.
16. USB 2.0 ports 13 and 14. These two 4-pin Universal Serial Bus (USB) ports are for
USB 2.0/1.1 devices.
ASUS Z170 PRO GAMING
®
DisplayPort port: 553 MHz
DVI port: 165 MHz
VGA port: 180 MHz
HDMI port: 300 MHz
100 series chipset, all USB devices connected to the
OS environment, two
®
1-19
