Summary of Contents for Converters.TV 895
- Page 1 USB/Ethernet to USB Hub - ID# 895 Operation Manual...
- Page 2 Introduction The USB over Ethernet 4 port Extender is a multi functional USB HUB giving you three different modes of operation: A LAN Mode, an Extender Mode and a HUB Mode. The LAN (Local Area Network) Mode is useful for homes and offices with existing network infrastructure to allow users to access 4 USB devices.
- Page 3 Operation Controls and Functions Front Panel 1. DC 5V: Plug the DC 5V power supply and connect the adaptor to AC wall outlet. 2. Power LED: This green LED will illuminate when the device is connected with power supply. 3. LAN IN: This slot is to connect with CAT5e/6 cable from your network system or PC/laptop.
- Page 4 application and driver (both are provided in the CD bundled) are required to be installed on the connected PCs / Laptops for them to identify and hook up with the unit in the same network using TCP/IP protocol. In all 3 modes, USB 2.0 and 1.1 protocols are both supported, while the former can go with a data rate up to 480 Mbps, and the later only 12 Mbps.
- Page 5 Using USB Server Double click on the Launch USB Server icon from the desktop or from the button right side and the USB Server window will appear on the desktop. Connect both PC/Laptop and the device with RJ-45 cable and click on Search and switch the INPUT switch on the device to LAN.
-
Page 6: Specifications
Uninstall the Device Driver Follow the steps below to uninstall the Multi View driver. Step 1: Open the Control Panel: Start → Control Panel → Add or Remove Programs. Step 2: Select USB Server and click Remove. Specifications Input 1 x Ethernet RJ-45; 1 x Mini-USB Network Protocol TCP/IP Network Interface... - Page 7 Connection and Installation...
