- Page 1 DVI over one CAT6 Extender ID# 854 Operation Manual...
- Page 2 Introduction The DVI-D Transmitter and Receiver over One CAT6 is an intelligent device for extending your DVI-D signal over long distances to a compatible display. Instead of searching for lengthy DVI cables, your existing CAT6 cables can be utilized to perform advanced functions, along with a bandwidth up to 2.25Gbps per channel.
- Page 3 Operation Controls and Functions Front Panel Transmitter Receiver 1. DVI-D IN: This slot is to connect with source equipment such as PC or graphic card for input signal sending. . DVI-D OUT: This slot is to connect with display monitor or TV for image display.
- Page 4 Specifications Transmitter Input 1 x USB (for Power), 1 x DVI-D Output 1 x CAT6 Receiver Input 1 x USB (for Power), 1 x CAT6 Output 1 x DVI-D Input Cable Distance 12M/ WUXGA or 1080p 8bit, 10M/ WUXGA or 1080p 12bit Output Cable Distance 12M/ WUXGA or 1080p 8 bit, 10M/ WUXGA or...
- Page 5 Connection...
