- Page 1 HDMI/CAT6 to single CAT6 extender - ID# 855 Operation Manual...
- Page 2 Introduction The HDMI /CAT6 to Single CAT6 Extender is an advanced solution for HDMI and CAT6 signal distribution. The CAT6 output port can be easily connected to CAT6 to HDMI receivers to allow a stable connection between an HDMI source and any compatible HDMI display.
- Page 3 Operation Controls and Functions Front Panel HDMI/CAT6 Input Switch This switch allows users to select either HDMI or CAT6 as the input source. EDID 8/12-bit switch This switch allows users to change the output display’s EDID between 8- or 12-bit resolution.
-
Page 4: Specifications
Specifications Bandwidth Frequency 2.25 Gbps (single link) Input Ports 1 × HDMI female port , 1 × CAT6 input Output Ports 1 × CAT6 output EDID HDMI Cable In 1080p 8-bit (15 m), 12-bit (15 m) CAT6 Cable In/Out 1080p 8-bit (7~45 m), 12-bit (7~15 m) HDMI Resolution 480i~1080p50/60, 1080p24, VGA~WUXGA ESD Protection... - Page 5 Connection...
