- Page 1 HDMI & IP over single cat6 Extender - ID# 866 Operation Manual...
- Page 2 Introduction Are you searching for a device that can make your home or office more efficient? Then the HDMI™ & IP over a Single CAT5e/CAT6 cable is for you. This cutting edge product is more powerful than previous generations of CAT5e/CAT6 Transmitters and Receivers, because with one Ethernet cable you are able to control the device through the built-in RS-232 / IR ports, send uncompressed audio/video and provide power to the receiver.
-
Page 3: Operation Controls And Functions
Operation Controls and Functions Front Panel Power LED: This red LED will illuminate when the power is connected with AC wall outlet. DC 5V: These slots are where you plug the 5V DC power supply into the unit and connect the adaptor to an AC outlet. IR 1/2 Blaster: These slots are to connect with the IR blaster cables included in the package for IR signal transmitting. - Page 4 D-Sub 9 Pin Definitions Define Specifications Transmitter -Inputs 1 x HDMI, 1 x HDMI Bypass, 3 x Ethernet, 1 x IR, 1 x RS-232 -Output 1 x CAT5e/CAT6 Receiver -Inputs 1 x CAT5e/CAT6 -Output 1 x HDMI , 3 x Ethernet, 1 x IR, 1 x RS-232 ESD Protection Human body model: +/- 8kV (air gap discharge)
- Page 5 Connection and Installation...
