- Page 1 RS232 over CAT5 Cable Transmitter & Receiver Extender Operation Manual...
- Page 2 Introduction The CAT 5 RS-232 extender is an affordable, hardware-based solution providing control of any RS-232 protocol device. With regular RS-232 devices you are limited to an immediate area of control. The CAT5 RS-232 extender extends control to over 250 meters and provides a tremendous amount of flexibility in your topology.
- Page 3 connector. ③ . Connect the 5V DC power adaptor into the unit and plug the adaptor to AC wall outlet. Note: Only an adaptor is needed for both Transmitter and Receiver. ① . Connect from Transmitter side the CAT 5 cable. ②...
- Page 4 Specifications Input Port RS232 D-Sub-9 female CAT 5 Output Port RS232 D-Sub-9 male CAT 5 Power Supply 5V/1A DC (US/EU standards, CE/FCC/UL certified) Dimensions (mm) 50(W) x 67(H) x 23(D) / each Weight (g) 80 / each Chassis Material Aluminum Silkscreen Color Silver Operating Temperature...
