- Page 1 USER’S MANUAL Uninterruptible Power Supply GX 200 Series Model M-UPS050AD2B M-UPS075AD2B M-UPS100AD2B INR-HG5687...
- Page 2 (VCCI). Using this product in a residential area may cause radio interference. In this case, the user may be requested to take an appropriate measure. About Prevention of Harmonic Current Interference M-UPS050AD2B conforms to the Guideline of harmonic restraint measures for general-purpose UPS. M-UPS075AD2B and M-UPS100AD2B conform to IEC61000-3-12.
-
Page 4: Introduction
Introduction An uninterruptible power supply is a device for supplying stable electric power to OA devices, FA devices, and computer devices. This manual describes installation, running, daily management, troubleshooting, and maintenance of an uninterruptible power supply. Use an uninterruptible power supply correctly in accordance with this manual. - Page 5 Introduction About warning display In this manual, the following warning displays are described so that user or the people around the UPS do not suffer damage to the body and property. "Warning" indicates that death or serious injury may result, if the Warning UPS is not used correctly.
-
Page 6: Caution About Safety
Caution about Safety List of important warnings The important warnings described in this manual are as follows. "Warning" indicates that death or serious injury may result, if the Warning UPS is not used correctly. Electric shock Do not remove the cover of the UPS. Since there are some portions with high voltage in the inside of the UPS, there is fear of an electric shock. - Page 7 The weight of the UPS is as follows: M-UPS050AD2B : 63kg (without battery : 29kg) M-UPS075AD2B : 127kg (without battery : 59kg) M-UPS100AD2B : 127kg (without battery : 59kg) Fire This UPS can be installed laying down.
- Page 8 Caution about Safety Damage Do not use the UPS for the uses that may hurt the human body or exert an important influence on the society and public. Medical instrument affecting human life directly Device that may hurt the human body Socially and publicly important computer system Do not put an object (display or floppy disk etc.) vulnerable to magnetism around the UPS.
-
Page 9: Caution For Use
Caution for Use Be careful about the following when using the UPS. Important "Important" indicates caution about the use of the UPS. Do not install and store the UPS in the following places: In an outdoor location A place exposed to the elements An extremely humid place and a dusty place A place with corrosive gas or salinity A place subjected to direct sunlight... - Page 10 Caution for Use The permissible voltage between the input electric cable of the UPS and the ground is 250V AC. If the voltage more than 250V AC is applied, the filter circuit of the input part may be damaged. The permissible input surge voltage of the UPS is 5kV peak (1.2 50µs).
- Page 11 Caution for Use When using a generator temporarily during the rolling blackouts, use a generator satisfying the following specification. If connecting a generator not satisfying the following specification to the input part of the UPS, there is a possibility of becoming the cause of the malfunction or damage of the UPS.
-
Page 12: Table Of Contents
Index Introduction.......................i Caution about Safety ..................iii Caution for Use....................vii Unpacking Opening the Packing ................1 Opening the packing Confirming the contents of the packing Outline Name and Main Function of Each Part ..........2 Mechanism of the UPS................. 5 At the normal operation At the battery operation (In the event of an input power failure) At the automatic bypass operation At the manual bypass operation... - Page 13 Caution and Measures for the Rolling Blackouts......27 Operation before the rolling blackouts Operation after the rolling blackouts Inspecting the Battery (Battery Check)..........29 Confirming the state of the UPS Using the manual check function Charging the battery Troubleshooting If a Warning Beep Sounds ..............34 Operation Mode List................
-
Page 14: Unpacking
Work by a suitable number of persons. And pay enough attention to prevent an accident such as an overturn or a drop. The weight of the UPS is as follows: M-UPS050AD2B : 63kg (without battery: 29kg) M-UPS075AD2B : 127kg (without battery: 59kg) M-UPS100AD2B : 127kg (without battery: 59kg) Open the packing box and take out the UPS. -
Page 15: Outline
Outline Name and Main Function of Each Part This chapter describes the name and main function of each part of the UPS. 〈M-UPS050AD2B〉 (17) (18) (19) (10) (15) (12) (16) (13) (11) (14) - 2 -... - Page 16 2.1 Name and Main Function of Each Part 〈M-UPS075AD2B, M-UPS100AD2B〉 (17) (16) (19) (18) (10) (12) (15) (11) (14) (13) - 3 -...
- Page 17 2 Outline Name Main function It lights up (green) while the UPS is operating normally. It lights up (orange) when the abnormalities occurred inside the ALARM UPS. It lights up (orange) when the load capacity of the connection OVER LOAD device exceeded the rated specification.
-
Page 18: Mechanism Of The Ups
2.2 Mechanism of the UPS Mechanism of the UPS At the normal operation While the UPS is operating normally, the UPS operates an AC power supply as an input, and supplies the output of constant voltage to connection device. Simultaneously, the UPS charges an internal battery and prepares for the battery operation. -
Page 19: At The Automatic Bypass Operation
2 Outline At the automatic bypass operation When the abnormalities occurred in the UPS during the normal operation, the UPS switches to the bypass operation automatically. During the bypass operation, the UPS sends the input voltage to the output directly and supplies the electric power to the connection device. -
Page 20: Installation
Installation Installing the UPS Caution about installation Caution Injury Do not ride on or put an object on the UPS. There is fear of an injury or an overturn. Damage Do not put an object (display or floppy disk etc.) vulnerable to magnetism around the UPS. - Page 21 3 Installation The following spaces are required for an installation location. The UPS takes in air through the vent hole on the front of the UPS and exhausts air through the cooling fan on the back of the UPS. Therefore, the space of 10cm or more is required in the front and rear of the UPS.
-
Page 22: Determining The Installation Method
3.1 Installing the UPS Determining the installation method Caution Fire This UPS can be installed laying down. If installing laying the UPS down, tilt it only to the right side, seeing from the front. Damage Never tilt the UPS to the left side. If tilting the UPS to the left side, the liquid leak of a battery may occur, there is fear of a fire or the UPS failure in the case. -
Page 23: Installation Method
Work by a suitable number of persons. And pay enough attention to prevent an accident such as an overturn or a drop. The weight of the UPS is as follows: M-UPS050AD2B : 63kg (without battery: 29kg) M-UPS075AD2B : 127kg (without battery: 59kg) - Page 24 3.1 Installing the UPS After attaching the stabilizer to the UPS, be sure to fix the stabilizer to the floor. 〈M-UPS050AD2B〉 〈M-UPS075AD2B, M-UPS100AD2B〉 189.5 251.5 - 11 -...
-
Page 25: Connecting The Cable
3 Installation Connecting the Cable Caution about connecting the cable Caution Electric The UPS should be connected to ground. (more than class D shock grounding) When connecting to an input power supply, connect the grounding wire to the ground terminal. There is fear of an electric shock. -
Page 26: Preparation Before Connecting The Cable
3.2 Connecting the Cable Preparation before connecting the cable Important When connecting the UPS to the electrical power equipment with the earth leakage breaker, select the earth leakage breaker not to trip due to current leakage. When connecting the UPS to the electrical power equipment with the earth leakage breaker, select the earth leakage breaker in consideration of total number of current leakage of the UPS plus current leakage of the connection device. - Page 27 Note) The input frequency of the using area is chosen automatically. The specification of the terminal block is as follows. Select the crimp contact which is suitable for specification. 〈M-UPS050AD2B〉 UPS side Specification Connect with Terminal...
-
Page 28: Connecting The Output Cable
3.2 Connecting the Cable Connecting the output cable Remove the input and output terminal block cover on the back of the UPS, and connect the AC output cable to the output terminal block. Confirm that the ground is connected. Connecting the input cable Remove the input and output terminal block cover on the back of the UPS, and connect the AC input cable to the input terminal block. -
Page 29: Interface Port
3 Installation Interface Port The interface port (D-sub 9 pins) is mounted on the back of the UPS and can take out the following signals. Use as necessary. CN1 (No-voltage contact signal interface) D-sub 9 pins, male (3 mm screw) Classification Name of Content... -
Page 30: Cn2 (Rs-232C Interface)
3.3 Interface Port CN2 (RS-232C interface) 5 4 3 9 8 7 D-sub 9 pins, female (#4-40 inch screw) Classification Name of Content of signal signal "Close" It is the no-voltage contact signal which is Input power outputted when the abnormalities, such as at operation supply the power failure, occur at an input power... -
Page 31: Setting Up The Output Voltage
3 Installation Setting up the Output Voltage This UPS can change the rated output voltage by the switch of voltage setting on the back of the UPS. Caution Damage Confirm that the voltage set up by the switch of voltage setting is within the range of input voltage of the connection device. - Page 32 3.4 Setting up the Output Voltage Press the RUN/STOP switch on the front of the UPS for approximately 1 second. The buzzer will sound if the switch is received. AC voltage set up is outputted from the output terminal block. The RUN LED (green) on the front of the UPS lights up.
-
Page 33: Running
When turning on the input breaker on the back of the UPS, the RUN LED (green) on the front of the UPS blinks slowly (in the cycles of approximately 1.6 sec.). 〈M-UPS050AD2B〉 〈M-UPS075AD2B, M-UPS100AD2B〉 If the UPS is not connected: Refer to Chapter 3.2 "Connecting the Cable". -
Page 34: 4.1 Turning On The Ups
4.1 Turning on the UPS Turning on the UPS Press the RUN/STOP switch on the front of the UPS for approximately 1 second. The buzzer will sound if the switch is received. 〈M-UPS050AD2B〉 〈M-UPS075AD2B, M-UPS100AD2B〉 Press the RUN/STOP switch for approximately 1 second. -
Page 35: Turning On The Connection Device
The battery check is performed automatically. The BATTERY CONDITION LED (orange) on the front of the UPS blinks (in the cycles of approximately 1.6 sec.). 〈M-UPS050AD2B〉 〈M-UPS075AD2B, M-UPS100AD2B〉 The battery check is performed for approximately 5 seconds. Then, if the battery is normal, the BATTERY CONDITION LED (green) on the front of the UPS indicates the amount of battery charge again, and the UPS returns to the normal operation. -
Page 36: Turning Off The Ups
Turn off the connection device. Turning off the UPS Press the RUN/STOP switch on the front of the UPS for approximately 1 second. The buzzer will sound if the switch is received. 〈M-UPS050AD2B〉 〈M-UPS075AD2B, M-UPS100AD2B〉 Press the RUN/STOP switch for approximately 1 second. - Page 37 4 Running An output stops. The RUN LED (green) on the front of the UPS blinks slowly (in the cycles of approximately 1.6 sec.). 〈M-UPS050AD2B〉 〈M-UPS075AD2B, M-UPS100AD2B〉 If an output does not stop normally: Refer to Chapter 6 "Troubleshooting". Turn off the input breaker on the back of the UPS.
-
Page 38: Inspection
Inspection Care and Daily Inspection In order to use the UPS safely over the long term, perform the following care and daily inspection regularly. Warning Electric Do not remove the cover of the UPS. shock Since there are some portions with high voltage in the inside of the UPS, there is fear of an electric shock. -
Page 39: How To Care For The Ups
5 Inspection How to care for the UPS Turn off the UPS after turning off the connection device, and remove the dust adhering to the vent hole and cooling fan of the UPS with a cleaner, etc. Wipe the surface of the UPS with a dry and soft cloth. Daily inspection Confirm that the dust is not adhering to the vent hole and the cooling fan. -
Page 40: Caution And Measures For The Rolling Blackouts
5.2 Caution and Measures for the Rolling Blackouts Caution and Measures for the Rolling Blackouts Important When using a generator temporarily during the rolling blackouts, use a generator satisfying the following specification. If connecting a generator not satisfying the following specification to the input part of the UPS, there is a possibility of becoming the cause of the malfunction or damage of the UPS. -
Page 41: Operation After The Rolling Blackouts
5 Inspection Operation after the rolling blackouts Confirm that the UPS is connected to an input power supply and the connection device. The RUN LED (green) on the front of the UPS blinks slowly (in the cycles of approximately 1.6 sec.). Press the RUN/STOP switch on the front of the UPS for approximately 1 second. -
Page 42: Inspecting The Battery (Battery Check)
Confirming the state of the UPS Confirm that the UPS is operating normally. 〈M-UPS050AD2B〉 〈M-UPS075AD2B, M-UPS100AD2B〉 Confirm that the RUN LED (green) is lighting. -
Page 43: Using The Manual Check Function
5 Inspection Using the manual check function Press the BATT CHECK switch on the front of the UPS for approximately 2 seconds. 〈M-UPS050AD2B〉 〈M-UPS075AD2B, M-UPS100AD2B〉 Press the BATT CHECK switch for approximately 2 seconds. The buzzer sounds, and the BATTERY CONDITION LED (orange) blinks (in the cycles of approximately 1.6 sec.). - Page 44 5.3 Inspecting the Battery (Battery Check) 〈M-UPS075AD2B, M-UPS100AD2B〉 A buzzer sounds. Pi― The BATTERY CONDITION LED (orange) blinks. (Not sound) A buzzer sounds. Pi― - 31 -...
- Page 45 If the battery is fully charged: The RUN LED (green) on the front of the UPS lights up, and the UPS returns to the normal operation. 〈M-UPS050AD2B〉 〈M-UPS075AD2B, M-UPS100AD2B〉 The RUN LED （green） lights up. If the battery is not fully charged: A warning beep sounds and the BATTERY CONDITION LED (orange) on the front of the UPS blinks.
-
Page 46: Charging The Battery
When pressing the RESET switch, once the BATTERY CONDITION LED (orange) on the front of the UPS goes out, and is switched to the indication (green) of the amount of battery charge. 〈M-UPS050AD2B〉 〈M-UPS075AD2B, M-UPS100AD2B〉 Press the RESET switch. Remarks. In this state, even if a power failure occurs, the battery operation may not be performed. -
Page 47: Troubleshooting
Troubleshooting If a Warning Beep Sounds Confirm the state of LED on the front of the UPS, and the type of a warning beep. Refer to the "Operation mode list", and deal with it according to directions. If the UPS is not connected to an input power supply, connect. For details, refer to Chapter 3.2 "Connecting the Cable". -
Page 48: Operation Mode List
6.2 Operation Mode List Operation Mode List When it seems that the abnormalities occur inside the UPS or the connection device stops, confirm the LED and a warning beep by the following lists, and deal with the trouble in accordance with the remarks in the "Operation mode list". Types of blink of LED (The symbols correspond to the symbols in the "... - Page 49 6 Troubleshooting Operation mode list Symbols of LED: ···· Lighting ········· Not lighting ········ Blinking The BATTERY CONDITION LED (green) indicates the amount of battery charge according to the sort of lighting as follows: (Not lighting)········· 0 to 50% : The battery is not fully charged. Even if a power failure occurs, the UPS may not be able to back up.
-
Page 50: 6.2 Operation Mode List
6.2 Operation Mode List Warning Operational BATTERY Remarks OVER beep status ALARM BYPASS CONDITION LOAD (green) (orange) (orange) (green/ (orange) orange) Lighting Lighting Bypass The UPS became the failure state operation due and switched to the bypass to UPS failure operation. - Page 51 6 Troubleshooting Warning Operational BATTERY Remarks OVER beep status ALARM BYPASS CONDITION LOAD (green) (orange) (orange) (green/ (orange) orange) Lighting Output During the bypass operation, the Slow overload capacity of the connection device blink during the exceeds the rated value. Reduce the bypass capacity of the connection device operation...
- Page 52 6.2 Operation Mode List Warning Operational BATTERY Remarks OVER beep status ALARM BYPASS CONDITION LOAD (green) (orange) (orange) (green/ (orange) orange) Lighting Battery check There is possibility that the battery Fast blink error is not fully charged. Perform the (orange) battery check manually after operating the UPS 12 hours or more to charge the battery.
-
Page 53: Maintenance
In the following cases, it is the end of battery life. Replace the battery. When the BATTERY CONDITION LED (orange) on the front of the UPS lights up and a warning beep sounds 〈M-UPS050AD2B〉 〈M-UPS075AD2B, M-UPS100AD2B〉 Pip-pip- pip-pip・・・... -
Page 54: The Method Of Battery Replacement
7.1 Replacing the Battery The method of battery replacement Caution Electric Perform the battery replacement by maintenance personnel. shock There is fear of an electric shock. Damage Replace the battery with one specified by our company and a new one. If using the un-specified battery or mixing an old battery and a new battery, it becomes the cause of a liquid leak of battery, a smoking, an ignition, and the UPS failure and trouble. -
Page 55: Disposal And Storage Of Battery
7 Maintenance Disposal and storage of battery Pay enough attention to disposal and storage of the battery. Prevent mixing with a dry cell, etc. after taking a measure (for example, stick the insulating tape on the terminal) to prevent a short circuit, when taking out the battery in order to discard. This UPS uses the small sealed lead storage battery as battery. -
Page 56: Replacing The Cooling Fan
In the following cases, it is the end of cooling fan life. Replace the cooling fan. When the ALARM LED (orange) and the BYPASS LED (orange) light up, after a warning beep sounded for 120 seconds 〈M-UPS050AD2B〉 The ALARM LED (orange) lights up. -
Page 57: The Method Of Cooling Fan Replacement
Use the following cooling fan. For the method of purchasing the cooling fan, consult with an agent from which you purchased the UPS or a maintenance company. Fan for M-UPS050AD2B (RRAF-GX11×1 / RRAF-GX12×1) Type of cooling fan : Fan for M-UPS075AD2B (RRAF-R1×2 / RRAF-GX12×2) Fan for M-UPS100AD2B (RRAF-R1×2 / RRAF-GX12×2) -
Page 58: When Not Using The Ups (Storage)
7.3 When Not Using the UPS (Storage) When Not Using the UPS (Storage) Work before storage Important Do not store the UPS in the following places: In an outdoor location A place exposed to the elements An extremely humid place and a dusty place A place with corrosive gas or salinity A place subjected to direct sunlight A place near sparks or heating element... -
Page 59: Appendix 8.1 Rated Specification
Appendix Rated Specification Model M-UPS050AD2B Rating capacity 5000VA/4000W Voltage 200/208/220/230/240V ± 2% Frequency 50/60Hz (automatic changeover inside the UPS) Frequency At the normal operation Depend on input frequency accuracy At the battery operation Within ±0.1% Number of phase Single-phase two-wire (with a ground terminal) - Page 60 8.1 Rated Specification Model M-UPS075AD2B M-UPS100AD2B Rating capacity 7500VA/6000W 10000VA/8000W Voltage 200/208/220/230/240V ± 2% Frequency 50/60Hz (automatic changeover inside the UPS) Frequency At the normal operation Depend on input frequency accuracy At the battery operation Within ±0.1% Number of phase Single-phase two-wire (with a ground terminal) Load condition Linear load or rectified load with a crest factor of up to three times...
-
Page 61: Additional Description For Ul Type
INPUT & GROUND BREAKER TIGHTENING TORQUE MODEL WIRE Type of (N・m) Vin(V) Iin(A) SIZE Closed-loop Terminal M-UPS050AD2B-U R5.5-5 AC240 200,208 220,230 M-UPS075AD2B-U 37.5 R8-8 AC240 M-UPS100AD2B-U R14-8 AC240 Table 2. Output rating, wire size, torque, external output circuit breaker size... - Page 62 AC Input/Output AC Input/Output Terminal Block Terminal Block L1/R l1/U Dual Conveter L2/S l2/V PE(G) Boost Chopper Figure 1 - Circuit diagram of Models M-UPS050AD2B-U AC Input/Output AC Input/Output Terminal Block Terminal Block L1/R l1/U Dual Conveter L2/S l2/V PE(G)
- Page 63 ・ Capacitor stores hazardous energy. Do not remove cover until 7 minutes after disconnecting all sources of supply. ・ For M-UPS050AD2B, 2 pole circuit breaker is not provided on this UPS. If this UPS installs, removes or does any services, for disconnecting all sources of supply, be off the external input circuit breaker.
- Page 64 8.2 Additional Description for UL Type ■ A battery can present a risk of electrical shock and high short-circuit current. The following precautions should be observed when working on batteries: a) Remove watches, rings, or other metal objects. b) Use tools with insulated handles. c) Wear rubber gloves and boots.
