Risco RVCM11H Installation Manual page 14

To define camera trigger settings:
1. From the Control Panel Cameras page, click the Triggers tab, the Camera
Triggers List page is displayed.
Figure 12 Camera Triggers List
2. Click Add Trigger; the Add Triggers dialog box appears.
Figure 13 Add Trigger
3. Define the following fields in the Add Trigger dialog box:
Field Description
Label Enter a name for the camera trigger
Camera Choose a camera from the list
Event Type Choose an event type from the list
Event Choose the event from the list, e.g.
alarm, duress, etc.
Event Type
Partition and Detector events
Partition and Detector events
Partition and Detector events
Partition and Detector events
12
