- Page 1 Oberflächentechnik Surface Technology Instruction Manual Instruction Manual Belt grinder JBS 100 and 400 Belt grinder JBS 100 and 400 Order no. 0 008 850 and 0 009 950 Order no. 0 008 850 and 0 009 950...
-
Page 2: List Of Contents
The unit is designed exclusively for grinding work with the tools listed and approved in the joke cata- logue for Surface Finishing. Any other use will be deemed to be contrary to its intended purpose. The manufacturer cannot be held liable for any resulting damages. - Page 3 Warranty/identification Joke Technology GmbH warrant the correct manufacture of every joke product which is delivered in accordance with the terms of contract and delivery. This warranty does not cover damages caused by normal wear and tear, incorrect handling, negli- gent use, the fitting of non-original spare parts, inadequate care and/or a failure to comply with this technical manual.
- Page 4 Operation/maintenance/care Screwing the handpieces on to the micromotor Firstly screw the handpiece carefully on to the motor by hand! Important If resistance is felt before the thread is screwed to the stop position, the drive shaft of the motor and the handpiece coupling do not interlock.
- Page 5 4. With excessive working pressure, there is a risk that the grinding belt will run out of the guide rollers. The maximum permissible speed for JBS 100 is 35,000 rpm and for JBS 400 is 40,000 rpm during Important constant operation.
- Page 6 Adjustment of the grinding belt position In order to obtain the optimum working position with the drive belt in each respective case, the grin- ding belt holder can be pivoted around the drive axle. (Symbolic drawing) Figure 5.4 secure feststellen lösen loosen adjustment...
- Page 7 Processing grooves: A minimum groove width of 6.5 mm must be present in this case. (Symbolic drawing) Figure 5.7 Grinding belt dimensions and grit sizes can be found in the joke catalogue. Info Maintenance The belt grinder is maintenance-free. No oil must be applied, since the bearings of the device and the motor are lubricated for life with Important grease.
- Page 8 Order no. 0 009 813 Handpiece JHG 210 Order no. 0 007 650 Handpiece JIG 400 Order no. 0 007 530 Belt grinder JBS 100 Order no. 0 009 950 Belt grinder JBS 400 Order no. 0 008 850 Datum...
- Page 9 Oberflächentechnik Surface Technology joke Technology GmbH Asselborner Weg 14 - 16 D-51429 Bergisch Gladbach Telefon: 022 04 / 8 39-0 Telefax: 022 04 / 8 39-60 Internet: www.joke.de E-Mail: info@joke.de Technical modifications reserved. joke 08/11...
