LED PROJECTOR User manual
Introduction
Thanks for using our LED mini-projector!
Our mini-projector is designed for home, entertainment, business or other environmental.
In addition to playing the most basic of video images, the ability to play TV (optional) /
MP3/MP4/DVB-T (optional) / VGA/Componet, etc., a variety of sources, it is convenience
your work and leisure activities.
Item features
The projector integrates high-performance sequential color LED driver and the color
sequence LCOS projector engine technology. And friendly user interface to provide you
with high reliability and ease of use.
RGB LED light source and more vivid colors, And color gamut up to 120%
For data / video display can be adjusted to provide the color balance control
Highlight the choice of model to adapt to different use of the environment
Off-axis design let you to be more convenient installation
Instant off & on, no need waiting for complete cooling
HDMI input
Electric Keystone
Important Safety Instructions
1. Please read this user manual before using projector and please keep it for future
reference.
2. Do not look directly at the lens during use, strong beam may damage the eyes.
3. Projection failure only by professional service.
4. When the Projector on the working, do not block the lens with any object in order to
avoid thermal deformation of the object, damage, or even fire.
5. Do not place the projector unstable car, shelf or table, the projector may fall, causing as
serious damage
6. Do not disassemble the projector, the projector is the only place for maintenance of the
machine to the right side of the dust cover, remove dust, people can be use a soft brush
cleaning
7. When the projector on the work, the heat and odor from the discharge outlet, which is
normal is not a product defect.
8. Do not place the projector in any of the following environment
9. Poorly ventilated or confined spaces But please ensure that air circulation around.
10. Excessive heat place , such as the closed car.The place as Humid and dusty smoke ,
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Innovative SP-3000
Summary of Contents for Innovative SP-3000
-
Page 1: Important Safety Instructions
LED PROJECTOR User manual Introduction Thanks for using our LED mini-projector! Our mini-projector is designed for home, entertainment, business or other environmental. In addition to playing the most basic of video images, the ability to play TV (optional) / MP3/MP4/DVB-T (optional) / VGA/Componet, etc., a variety of sources, it is convenience your work and leisure activities. -
Page 2: Projector Exterior View
to avoid contamination of optical devices. 11. Do not plug the outlet and do not place the projector in a blanket or other soft surface, 12. Do not leave flammable materials near the projector and do not cover with a cloth or other materials projector. -
Page 3: Panel Instructions
1：Safety lock 2：Panel Botton 3：Focus 4：Infrared receive window 5：Lens 6：Air Outlet 7：Speaker 8：Speaker 9：Projector Leg 10：Installation Hole 11：Name Plate 12：Air Input 13：DC IN 14：Audio Input 15：HDMI Input 16：VGA Input 17：ANT(TV) Input 18：Componet Input 19：Headphone 20：SDCard Reader 21：USB Panel Instructions 1： Power； 2：... - Page 4 mideele key is OK key，shout press the UP/DOWN/Left/Right key is move and select key, shout press the SOURCEkey is paust; 4-7：Four Direction Key Remote Instructions Mute Power DOWN Photo Broad Left Cast Video Broad Right Cast Audio Broad 0-10 TV0-9 Cast Tv digit Source Source Select -/--...
- Page 5 1. Take down the battery cover from the remote back. • If there is old battery, please take it out。 2. Put the battery in，be sure that the positive pole and negative pole is correct。 3. Put the battery cover back. Please refer to below pictures：...
- Page 6 achieve the normal screen Hanging Front Project Hanging Front Project Table Front Project Hanging back Project Get the size of projected image Projector lens to screen distance, zoom setting (if any) and video formats will affect the projected image size. 4:3 is a natural aspect ratio of the projector.
-
Page 7: Connect Computer
1.24±0.05 1.65±0.05 2.08±0.05 2.49±0.05 2.89±0.05 3.29±0.05 4.14±0.05 4.94±0.05 The figures are for information purposes only, please measure shall prevail in kind Connections When connecting the signal source to the projector, please confirm: 1. To shut down all equipment before making any connections. 2. - Page 8 Many laptop connected to the projector does not turn on their external video port. Typically, according to the key combination [FN] + [F3] or CRT / LCD button to turn on / off external monitor. Found on the notebook labeled CRT / LCD display with function keys or function key symbol.
- Page 9 The TV signal using a standard RF cable to connect to this machine ANT input. For more information, see "Operating Instructions. Instructions 1. Turn on the projector The projector comes with a power adapter required to connect to the DC IN socket on the projector, then indicator will be flashed quickly;...
- Page 10 B: Move【 】 【 】to the source you need，press【OK】to confirm。 2． ． ． ． Picture A: Press【MENU】 ，display like below： B: Move the 【 】 【 】to the sub-menu，press【OK】to enter。By using the【 】 【 】 【 】 【 】to adjust。 a:Picture Moce This option included：User（you can adjust the contrast ratio，brightness，...
- Page 11 C:Under Sub-menu state, press【MENU】 ，return to up menu；press【EXIT】to exit。 3．Sound A:Press【MENU】 ，then press【 】 one time，display like below： B: Move the 【 】 【 】to the sub-menu，press【OK】to enter。By using the【 】 【 】 【 】 【 】to adjust。 a:Sound Mode This option included： user （ you can adjust the high or low pitch under this state）...
- Page 12 minutes，240 minutes。When the option is OFF, there is no time task。 e:Auto Sleep This option included ON, OFF. C: Under Sub-menu state, press【MENU】 ，return to up menu；press【EXIT】to exit。 5．Setting A:Press【MENU】键，press 【 】three times，display like below： B: Move the 【 】 【 】to the sub-menu，press【OK】to enter。By using the【 】 【 】 【...
- Page 13 Mode 1 ——Applied to front projection Mode 2 ——Applied to ceiling front projection Mode 3 ——Applied to ceiling back projection Mode 4 ——Applied to back projection 五．Multimedia Supported Formats: MPEG-2 Video MP@HL （1080i、720p、SDTV） MPEG-4 ASP Video decoding （1080P@30fps） RM/RMVB( 支 持 RV8,RV9,RV10,RA8-LBR 和 HE-AAC,Max1080P@30fps) MPG .
- Page 14 Press【 】 【 】 【 】 【 】to move cursor，select the file, press【OK】to confirm（single selection/multiple selection， selected file marked √） ， press 【 】 to play.press 【 】 to stop. Under Multimedia， press 【OK】 display options， total two layers， press 【 】 【 】 to select: the indications are under below：...
- Page 15 Be sure that the power is off before cleaning the box. • Please use the soft、lint free cloth to clean the box. • Please use the water or neutral cleanser to clear the cloth • Do not use paraffin、alcohol、diluent or other chemical cleanser to clean the box. Projector Storage If you want to storre the projector long term, please refer to below instructions: •...
- Page 16 projector The distance do not exceed Distance too long 8m(26 feet) Compatibility PC Mode Mode Refresh Rate H.Frequency(kHz) Clock(MHz) Resolution (Hz) VGA_60 59.940 31.469 25.175 640 x 480 VGA_72 72.809 37.861 31.500 VGA_75 75.000 37.500 31.500 SVGA_60 60.317 37.879 40.000 800 x 600 SVGA_72 72.188...
