CASSETTE TYP FANCOIL UNIT SERVICE MANUAL
(GC201109-I)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GC201109-I and is the answer not in the manual?

Questions and answers

Related Manuals for Gree GC201109-I

Summary of Contents for Gree GC201109-I

  • Page 1 CASSETTE TYP FANCOIL UNIT SERVICE MANUAL (GC201109-I)

  • Page 2: Table Of Contents

    Contents PRODUCT.....................2 1. MODELS LIST ......................2 2. NOMENCLATURE OF THE UNIT ................3 3. FUNCTION ......................3 4. PRODUCT DATA.....................4 CONTROL....................10 1. WIRELESS REMOTE CONTROLLER ..............10 2. RED REMOTE CONTROLLER ................13 INSTALLTION .....................20 1. NAMES AND FUNCTIONS OF PARTS ..............20 2. DRAINAGE PIPE....................20 3.
  • Page 3 Cassette Type Fan Coil Unit Service Manual PRODUCT...

  • Page 4: Product

    Cassette Type Fan Coil Unit Service Manual PRODUCT 1. MODELS LIST Cooling Model Name Code Capacity volume Remarks (V, Ph, Hz) FP-8XD-E EM52000051 4600 220-240V~-1Ph-50Hz FP-8XD/A-E EM5200045010 4640 220-240V~-1Ph-50Hz FP-10XD-E EM52000061 5400 1020 220-240V~-1Ph-50Hz FP-10XD/A-E EM5200046010 5400 1020 220-240V~-1Ph-50Hz FP-12.5XD-E EM52000031 6700 1270...

  • Page 5: Nomenclature Of The Unit

    Cassette Type Fan Coil Unit Service Manual FP-51XD-E EM52000011 3000 220-240V~-1Ph-50Hz FP-68XD-E EM52000021 3500 2. NOMENCLATURE OF THE UNIT Description Options Fan coil Number×10 m /h(FP-51XD-E;FP-68XD-E);Number×100 m /h(8,10,12.5,14,16,18) Ceiling Type Arranged by A, B,C… E=220-240V~-1Ph-50Hz 3. FUNCTION 1. Novel pattern: the exposed skin plates of unit look so elegant and luxurious that they can be taken as the indoor decorations.

  • Page 6: Product Data

    Cassette Type Fan Coil Unit Service Manual 4. PRODUCT DATA Model FP-8XD/A-E FP-10XD/A-E FP-12.5XD/A-E FP-14XD/A-E Code EM5200045010 EM5200046010 EM5200047010 EM5200048010 High 1020 1250 1430 Medium volume 1030 1363 1200 Cooling 4640 5400 6700 7740 Capacity Heating 7500 9100 10500 11200 V-Ph- Type 220-240V~-1Ph-50Hz...
  • Page 7 Cassette Type Fan Coil Unit Service Manual Model FP-16XD/A-E FP-18XD/A-E Code EM5200049010 EM5200050010 1060 High 1640 1800 1035 Medium 1460 1760 1327 1584 Cooling 8700 9600 Capacity Heating 12900 14600 Type V-Ph-Hz 220-240V~-1Ph-50Hz 220-240V~-1Ph-50Hz Input Exterior static pressure 1.554 1.714 Water system Pressure drop Type...
  • Page 8 Cassette Type Fan Coil Unit Service Manual Model FP-8XD-E FP-10XD-E FP-12.5XD-E FP-14XD-E Code EM52000051 EM52000061 EM52000031 EM52000071 Type V-Ph-Hz 220~240V-1-50Hz 220~240V-1-50Hz 220~240V-1-50Hz 220~240V-1-50Hz system Input High 1020 1250 1430 Medium volume 1030 1363 1198 Cooling 4640 5400 6700 7740 Capacity Heating 7500 9100...
  • Page 9 Cassette Type Fan Coil Unit Service Manual Model FP-16XD-E FP-18XD-E Code EM52000081 EM52000041 Type V-Ph-Hz 220~240V-1-50Hz 220~240V-1-50Hz Input 1059 High 1640 1800 1035 Medium 1450 1760 1328 1584 Cooling 8700 9600 Capacity Heating 12900 14600 1400 1400 1.53 1.68 Water system Pressure drop dB(A) Type...
  • Page 10 Cassette Type Fan Coil Unit Service Manual Model FP-51XD-E FP-68XD-E Code EM52000011 EM52000021 Type V-Ph-Hz 220~240V-1-50Hz 220~240V-1-50Hz Input High Medium Cooling 3000 3500 Capacity Heating 4000 5000 0.49 0.616 Water system Pressure drop dB(A) Type Coil Operating pressure Type FN11T FN11T Motor Capacitor...
  • Page 11 Cassette Type Fan Coil Unit Service Manual CONTROL...

  • Page 12: Control

    Cassette Type Fan Coil Unit Service Manual CONTROL 1. WIRELESS REMOTE CONTROLLER 1.1 Names and functions –Remote control Note SWING button FAN button When it is pressed,the louvers start to totate automatically and Press this button to change the fan speed of: AUTO FAN TEMP.
  • Page 13 Cassette Type Fan Coil Unit Service Manual 1.2 Name and Function-Remote controller. (Remove the cover) Note SLEEP button repressed. As the unit is cooling or dry, 1°C in 1 hour and 2 °C in 2 hours. As the unit is heating, if in °C 1 hour and 2°C in 2 hours.
  • Page 14 Cassette Type Fan Coil Unit Service Manual 1.3 How to insert batteries 1. Remove the cover from the back of the remote controller. 3. Re-attach the cover. NOTE: 3. The lifetime of the batteries is about one year. appliances. 5. Bad batteries are forbidden. CONTROL...

  • Page 15: Red Remote Controller

    Cassette Type Fan Coil Unit Service Manual 2. RED REMOTE CONTROLLER 2.1 Operation instruction of wired controller (optional) NOTE Fig.1 Time display MODE button Defrosting display Button for temp. increase Button for temp. decrease FAN button Ambient temp. display Fresh air display TIMER button Mode(COOL, DRY, FAN, AUTO) ON/OFF button...
  • Page 16 Cassette Type Fan Coil Unit Service Manual 1) ON/OFF (Fig.2) Fig.2 2) Fan control MODE MODE Press this button to change the fan speed of: AUTO PEED automatically. WIN G TIME R ON/OFF Fig. 3 3) Temperature adjustment(Fig.4) Press the temperature adjustment button. MODE SWING decreased by 1...
  • Page 17 Cassette Type Fan Coil Unit Service Manual 4) Swing mode set up(Fig.5) MODE MODE SWING Note remote controller. WIN G TIME R ON/OFF Fig.5 5) Running mode setup(Fig.6) MODE temperature. If the setting temperature is higher than the ambient COOL DRY AUTO FAN HEAT TIMER...
  • Page 18 Cassette Type Fan Coil Unit Service Manual 7) Energy saving setting (Fig. 8) enters cool or dry energy saving mode for setting temp. With the display original value:26 ). Then, press mode button onto heat energy originalvalue:20 . In the region of displaying setting temperature, ).
  • Page 19 Cassette Type Fan Coil Unit Service Manual 9) Key lock (Fig.10) in the region of displaying seting temp. ,and all buttons are in locked MODE MODE Monitoring the manual controller. AUTO centralized or long- displayce montitoring. WIN G COOL TIME R ON/OFF Fig.10 10) Connecting with centralized controller(Fig.11)
  • Page 20 Cassette Type Fan Coil Unit Service Manual 12) Weekly Timer (optional) Week Timing controller (With Centralized Control Function) four timing ON/OFF periods for any unit every day, so as to achieve fully Automatic operation. No timing control can be set for holidays. can be done through the Timer On/Off of this WEEKLY the button shield operation and temperature adjustment and other operations are done through the manual control at every unit.
  • Page 21 Cassette Type Fan Coil Unit Service Manual INSTALLATION...

  • Page 22: Installtion

    Cassette Type Fan Coil Unit Service Manual INSTALLTION 1. NAMES AND FUNCTIONS OF PARTS Drainage device (built-in). during cooling. Drainage pipe (at air outlet) Water piping Air outlet Remote controller The built-in air filter removes dust and dirt Air intake grille 2.

  • Page 23: Precautions For Drainage Raising Pipe

    Cassette Type Fan Coil Unit Service Manual 3. PRECAUTIONS FOR DRAINAGE RAISING PIPE The install height of the drain raising pipe should less than 280mm. 300mm. 3..1 Instruction to endure the unnecessary outside force. The installation of the motorized valve should be done according as .Firstly connect one end of the guaranteed.

  • Page 24: Tric Wiring

    Cassette Type Fan Coil Unit Service Manual Both the tube joint and the motorized valve are G3/4" threaded. Prior to the connection, it is insulation. Body Vavle Intlet tube Outlet tube WATER VALVE Pipe sleeve Check the smoothness of drain after installation. Check the drain in the state of refrigerating after installation of the electric circuit.

  • Page 25: Installation Of Panel

    Cassette Type Fan Coil Unit Service Manual Precautions: Be sure to connect the indoor unit and outdoor unit at right poles. 5. INSTALLATION OF PANEL Install the decoration panel. to the hook of the indoor unit. (2 Positions) 2. Temporarily hang the remaining 2 latches to the hooks on the sides of the indoor unit.(be careful not to rise) covered.
  • Page 26 Cassette Type Fan Coil Unit Service Manual Fig 4 5.1 Precautions Fig.5 indoor unit body (Refer to Fig.6)
  • Page 27 Cassette Type Fan Coil Unit Service Manual Fig.6 Wiring of the decoration panel. Fig.7...
  • Page 28 Cassette Type Fan Coil Unit Service Manual MAINTENANCE...

  • Page 29: Maintenance

    Cassette Type Fan Coil Unit Service Manual MAINTENANCE 1.TROUBLESHOOTING Warning: buckle 1. Open the suction grille. 3. Then remove three air cleaners on it. shady place. Note: 4. The suction grille must be opened by skilled personnel. suction grille by hanging it to the projected portion above suction grille. Refer to step.1...
  • Page 30 Cassette Type Fan Coil Unit Service Manual How to clean to the suction grille 1. Open the suction grille 3. Remove the suction grille Open the suction grille at 45°and then lift. When the suction grille is very dirty, use soft brush and neutral 5.
  • Page 31 Cassette Type Fan Coil Unit Service Manual How to clean the air outer and case. 1. Check to make sure no objects obstructing the intake and outlets parts on both the indoor and outdoor units. damaged. End of season cleaning 3.

  • Page 32: Wiring Diagram

    Cassette Type Fan Coil Unit Service Manual 2. WIRING DIAGRAM FP-8XD-E; FP-10XD–E; FP-12.5XD-E; FP-14XD-E;FP-14XD-E;FP-18XD-E. POWER: LIMIT WATER VALVE Evaporator LIQUID HEAT PIPE TEMP Manual Panel ROOM TEMP COMMUNICATION CORD Attention:The Manal Panel is the optional accessory PUMP MOTOR POWER FANM OTOR Temperature limiter...
  • Page 33 Cassette Type Fan Coil Unit Service Manual FP-8XD/A-E; FP-10XD/A–E; FP-12.5XD/A-E; FP-14XD/A-E;FP-16XD/A-E; FP-18XD/A-E. POWER: LIMIT WATER VALVE Evaporator LIQUID PIPE TEMP. Manual Panel ROOM TEMP. COMMUNICATION CORD Attention:The Manual Panel is the optional accessory MOTOR POWERT PUMP MOTOR...
  • Page 34 Cassette Type Fan Coil Unit Service Manual Model; FP-51XD –E; FP-68XD –E. POWER: WATER VALVE LIQUID Manual Panel PIPE TEMP. ROOM TEMP. Attention:The Manual Panel is the optional accessory PUMP MOTOR POWERT FANM OTOR...

  • Page 35: Disassembly And Assembly Procedure Of Main Parts

    Cassette Type Fan Coil Unit Service Manual 3. DISASSEMBLY AND ASSEMBLY PROCEDURE OF MAIN PARTS Model;FP-8XD-E; FP-10XD–E; FP-12.5XD-E; FP-14XD-E;FP-16XD-E; FP-18XD-E;P-8XD/A-E; FP-10XD/ A–E; FP-12.5XD/A-E; FP-14XD/A-E;FP-16XD/A-E; FP-18XD/A-E. Disassembly Procedures of Indoor Unit Process Handling Description Push the left and right buckles on the grille of the 1.Disassemble the grille of the angle, after that pull...
  • Page 36 Cassette Type Fan Coil Unit Service Manual 5.Disassemble the 6.Disassemble the drain pan asher Fan Blade 7.Disassemble the fan blade...
  • Page 37 Cassette Type Fan Coil Unit Service Manual Mounting Plate Baffle take it out. buckles on both side, after that, take the baffle 8. Disassemble Connection Board the evaporator board of the evaporator, disconnect the earth Clamp electric heater and earth lead out through the Fixed Mount Evaporator Motor...
  • Page 38 Cassette Type Fan Coil Unit Service Manual FP-51XD –E; FP-68XD –E Process Handling Description Push the left and right buckles on the grille of the 1. Disassemble the grille of the angle, after that pull front panel Buckle Front Panel Open the cover of the electric box and 2.Disassemble...
  • Page 39 Cassette Type Fan Coil Unit Service Manual Screw Electrical Box Cover Screw 4. Disassemble the electrical box Screw Electrical Box Cover Baffle 5 . D i s a s s e m b l e the baffle at the pipe outlet. Screw Water Pump Screw...
  • Page 40 Cassette Type Fan Coil Unit Service Manual Left Fender 7. Disassemble Screw the left fender Fan Blade 8.Disassemble the fan blade Screw blade and then take it out. Connection Board 9.Disassemble the evaporator Evaporator Fixed Mount Motor 10.Disassemble the motor and take the motor out.

  • Page 41: Exploded Views And Spare Part Lists

    Cassette Type Fan Coil Unit Service Manual 4. EXPLODED VIEWS AND SPARE PART LISTS Model: FP-8XD-E; FP-10XD–E; FP-12.5XD-E; FP-14XD-E;FP-16XD-E; FP-18XD-E.
  • Page 42 Cassette Type Fan Coil Unit Service Manual FP-8XD-E (EM52000050) Tube Exit plate 02217102 Body Fixing Plate 01332701 01302718 01302715 Base Plate 01222701 01302714 Bottom Foam 52012722 Motor Gasket 76712711 Bolt M6 70212711 01702701 Motor FN35B 15012703 Electric Heater 32002701 Centrifugal Fan 10312705 Evaporator Linkage 01074042...
  • Page 43 Cassette Type Fan Coil Unit Service Manual FP-10XD-E (EM52000060) Tube Exit plate 02217102 Body Fixing Plate 01332701 01302718 01302715 Base Plate 01222701 01302714 Bottom Foam 52012722 Motor Gasket 76712711 Bolt M6 70212711 01702701 Motor FN35B 15012703 Electric Heater 32002701 Centrifugal Fan 10312705 Evaporator Linkage 01074042...
  • Page 44 Cassette Type Fan Coil Unit Service Manual FP-12.5XD-E (EM52000030) Tube Exit plate 02217102 Body Fixing Plate 01332701 01302718 01302715 Base Plate 01222701 01302714 Bottom Foam 52012722 Motor Gasket 76712711 Bolt M6 70212711 01702701 Motor FN35B 15012703 Electric Heater 32002701 Centrifugal Fan 10312705 Evaporator Linkage 01074042...
  • Page 45 Cassette Type Fan Coil Unit Service Manual FP-14XD-E (EM52000070) Tube-exit Plate 02217102 Body Fixing Plate 01332701 01302713 01302711 Base Plate 01222732 01302709 Bottom Foam 52012721 Motor Gasket 76712711 Bolt 70210012 01702701 Motor FN50T 15012710 Electric Heater 32002701 Centrifugal Fan 10310101 Evap Connection 01072735 Cable-cross Loop...
  • Page 46 Cassette Type Fan Coil Unit Service Manual Tube-exit Plate 02217102 Body Fixing Plate 01332701 01302713 01302711 Base Plate 01222732 01302709 Bottom Foam 52012721 Motor Gasket 76712711 Bolt 70210012 01702701 Motor FN50T 15012710 Electric Heater 32002701 Centrifugal Fan 10310101 Evap Connection 01072735 Cable-cross Loop 76515202...
  • Page 47 Cassette Type Fan Coil Unit Service Manual FP-18XD-E (EM52000040) Tube-exit Plate 02217102 Body Fixing Plate 01332701 01302713 01302711 Base Plate 01222732 01302709 Bottom Foam 52012721 Motor Gasket 76712711 Bolt 70210012 01702701 Motor FN50T 15012710 Electric Heater 32002701 Centrifugal Fan 10310101 Evap Connection 01072735 Cable-cross Loop...
  • Page 48 Cassette Type Fan Coil Unit Service Manual P-8XD/A-E; FP-10XD/A–E; FP-12.5XD/A-E; FP-14XD/A-E;FP-16XD/A-E; FP-18XD/A-E.
  • Page 49 Cassette Type Fan Coil Unit Service Manual FP-8XD/A-E (EM52000450) Tube Exit plate 02217102 Body Fixing Plate 01332701 01302718 01302715 Base Plate 01222701 01302714 Bottom Foam 52012722 Motor Gasket 76712711 Bolt M6 70212711 01702701 Motor FN35B 15012703 Centifugal Fan 10312705 Evaporator Linkage 01074042 Cable-cross Loop 76515202...
  • Page 50 Cassette Type Fan Coil Unit Service Manual FP-10XD/A-E (EM52000460) Tube-exit Plate 02217102 Body Fixing Plate 01332701 01302718 01302715 Base Plate 01222701 01302714 Bottom Foam 52012722 Motor Gasket 76712711 Bolt 70210051 01702701 Motor 15012703 Centifugal Fan 10312705 Evap Connection 01072710 Cable-cross Loop 76513101 Tube sensor 3900012125G...
  • Page 51 Cassette Type Fan Coil Unit Service Manual FP-12.5XD/A-E (EM52000470) Tube-exit Plate 02217102 Body Fixing Plate 01332701 01302718 01302715 Base Plate 01222701 01302714 Bottom Foam 52012722 Motor Gasket 76712711 Bolt 70210051 01702701 Motor 15012703 Centifugal Fan 10312705 Evap Connection 01072710 Cable-cross Loop 76513101 Tube sensor 3900012125G...
  • Page 52 Cassette Type Fan Coil Unit Service Manual FP-14XD/A-E (EM52000480) Tube-exit Plate 02217102 Body Fixing Plate 01332701 01302713 01302711 Base Plate 01222701 01302709 Bottom Foam 52012721 Motor Gasket 76712711 Bolt 70210051 01702701 Motor 15012710 Centifugal Fan 10310101 Evap Connection 01072710 Cable-cross Loop 76513101 Tube sensor 3900012125G...
  • Page 53 Cassette Type Fan Coil Unit Service Manual FP-16XD/A-E (EM52000490) Tube-exit Plate 02217102 Body Fixing Plate 01332701 01302718 01302715 Base Plate 01222701 01302714 Bottom Foam 52012722 Motor Gasket 76712711 Bolt 70210051 01702701 Motor 15012703 Centifugal Fan 10312705 Evap Connection 01072710 Cable-cross Loop 76513101 Tube sensor 3900012125G...
  • Page 54 Cassette Type Fan Coil Unit Service Manual FP-18XD/A-E (EM5200500) Tube-exit Plate 02217102 Body Fixing Plate 01332701 01302718 01302715 Base Plate 01222701 01302714 Bottom Foam 52012722 Motor Gasket 76712711 Bolt 70210051 01702701 Motor 15012703 Centifugal Fan 10312705 Evap Connection 01072710 Cable-cross Loop 76513101 Tube sensor 3900012125G...
  • Page 55 Cassette Type Fan Coil Unit Service Manual...
  • Page 56 Cassette Type Fan Coil Unit Service Manual FP-51XD –E (EM52000010) Remote Controller 30512506 Water Tray 20182703 Water Tray Foam for Fresh Air In taking 12312702 Water Tray Foam 12312703 Fan Fixer 76712709 Centrifugal Fan 10312702 Motor FN11T 15012707 01072714 01109501 01702702 Motor Gasket 76712705...
  • Page 57 Cassette Type Fan Coil Unit Service Manual FP-68XD –E (EM52000020) Remote Controller 30512506 Water Tray 20182703 Water Tray Foam for Fresh Air In taking 12312702 Water Tray Foam 12312703 Fan Fixer 76712709 Centrifugal Fan 10312702 Motor FN11T 15012707 01072714 01109501 01702702 Motor Gasket 76712705...
  • Page 58 JF00300710...
