Installing the Battery

1. Align the battery to the battery tray of the machine

(Figure

40).

Note: Ensure that the positive and negative posts of

the battery are aligned as shown in

2. Secure the battery to the battery tray with the battery

clamp, carriage bolt, and locknut

3. Connect the battery cables; refer to

Battery (page

36).

Connecting the Battery

1. Connect the positive-battery cable to the terminal of

the battery

(Figure

2. Connect the negative-battery cable to the terminal of

the battery

(Figure

3. Install the battery cover onto the top of the battery

(Figure

40).

Charging the Battery

WARNING

Charging the battery produces gasses that can

explode.

Never smoke near the battery and keep sparks and

flames away from battery.

Important: Always keep the battery fully charged

(1.260 specific gravity). This is especially important to

prevent battery damage when the temperature is below

0° C (32° F).

1. Remove the battery from the machine; refer to

Removing the Battery (page

2. Connect a 3 to 4 amp battery charger to the battery

posts. Charge the battery at a rate of 3 to 4 amp for 4

to 8 hours (12 volts).

Note: Do not overcharge the battery.

3. Install the battery in the chassis; refer to

Battery (page

36).

Storing the Battery

If the machine will be stored for more than 30 days, remove

the battery and charge it fully. Either store it on the shelf or on

the machine. Leave the cables disconnected if it is stored on

the machine. Store the battery in a cool atmosphere to avoid

quick deterioration of the charge in the battery. To prevent

the battery from freezing, make sure it is fully charged.
