S P
ERVICE
I
DENTIFICATION
The following abbreviations are used throughout the parts lists in this section.
Abbreviation
NL Not Listed
NPN No Part Number
AR As required
TO HELP US SERVICE YOU BETTER. HAVE TUG MODEL AND SERIAL NUMBER AVAILABLE
NOTE: THIS MANUAL COVERS PARTS & SERVICE FOR EAGLE TT4—TT8 2WD AND ALL WHEEL DRIVE
MODELS WITH BOTH THE YANMAR TIER II AND TIER III ENGINES. PLEASE BE SURE TO CHECK THE
HEADING ON EACH PAGE TO SEE IF THE PARTS REFERENCED ARE FOR A :
YANMAR TIER II DIESEL
OR
YANMAR TIER III DIESEL
ALL PAGES WITHOUT THE ABOVE IN THE DESCRIPTION DENOTE PARTS ARE USED ON MODELS
POWERED WITH BOTH A YANMAR TIER II AND YANMAR TIER III ENGINE.
TO DETERMINE IF YOUR TUG IS POWERED BY A TIER II OR TIER III ENGINE YOU CAN CHECK THE
DISPLAY LOCATED ON THE DASHBOARD BY THE FOLLOWING.
1. TURN DISPLAY "ON"
2. PRESS ENTER
3. SCROLL TO "EAGLE SET UP"
4. PRESS ENTER
5. YOU WILL SEE "SELECT ENGINE : YANMAR TIER II OR YANMAR TIER III" ON YOUR SCREEN
TO DETERMINE IF YOUR TUG IS POWERED BY A TIER II OR TIER III ENGINE WITHOUT TURNING ON
DISPLAY.
ALL TIER II TUGS ARE EQUIPPED WITH A MANUAL ALUMINUM FOOT PEDAL AND ALL TIER III TUGS
ARE EQUIPEED WITH A BLACK PLASTIC ELECTRONIC FOOT PEDAL.
TT4-8 4TNV98
I
ARTS LLUSTRATIONS
K
EY
Meaning
WHEN ORDERING PARTS
& D
Part required but not shown on diagram
Parts shown and numbered, but not stocked and sold by Eagle.
Typically used for bolts, clamps, etc...
REV30 8.4.15
ETAIL
Purpose
15
