OWNER
S AND OPERATOR
S MANUAL
Vertical, Water-Cooled 4-Cycle Diesel Engine
CAUTION
Do not operate the Generator, or any other appliance, before you have read and
understood the instructions for use and keep near for ready use.
DGM60MK/LU
X750-020 73 0
X750801-370 0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DGM60MK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Shindaiwa DGM60MK

Summary of Contents for Shindaiwa DGM60MK

  • Page 1 S AND OPERATOR S MANUAL Vertical, Water-Cooled 4-Cycle Diesel Engine CAUTION Do not operate the Generator, or any other appliance, before you have read and understood the instructions for use and keep near for ready use. DGM60MK/LU X750-020 73 0 X750801-370 0...
  • Page 3 Introduction Thank you for purchasing this Shindaiwa soundproof diesel engine generator. This manual has been created to ensure safe usage of this generator. Be sure to read this manual before operation. Improper operation/handling of this generator will result in an accident or malfunction.

  • Page 4: Table Of Contents

    Table of Contents Safety Instructions ................2 Specifications .................. 5 2-1. Specifications ................5 2-2. Ambient Conditions ..............6 Applications ..................6 Part Names ..................6 4-1. External View/Part Names ............6 4-2. Operation Panel Part Names ............ 8 Equipment ..................9 5-1.

  • Page 5: Safety Instructions

    Safety Instructions WARNING : EXHAUST GAS POISONING Do not operate the generator in poorly ventilated areas such as indoors or tunnels, as the exhaust gas of the engine contains substances that are harmful to human health. Do not direct exhaust fumes at bystanders or buildings. WARNING : ELECTRIC SHOCK Before connecting or disconnecting load cables to/from the output terminal, always turn the output circuit breakers to the OFF position, stop the engine, and remove the ignition key.
  • Page 6 CAUTION : FIRE Do not bring flammable items (such as fuel, gas and paint) or items that are highly combustible near the generator as the muffler, exhaust gas and other parts become extremely hot. Position this generator 3 ft. (1 m) or more from walls or other hindrances, and on a level surface. Do not connect the generator output to indoor wiring.
  • Page 7 Warning/Caution Label Locations If warning or caution labels become damaged and difficult to read, replace with new labels in the indicated locations. Order labels using part number indicated in the parenthesis. Injury (Part no. : X505-004630) Simul-Phase (Part no. : X505-006960) Caution: gm spec LLC (Part no.

  • Page 8: Specifications

    Specifications 2-1. Specifications Model Unit DGM60MK/LU Revolving Field Brushless AC Generator Type Simultaneous 3 Phase-120V/240V 1 Phase Rated Frequency Three phase Rated Output 36/ [18] *1 Single phase 36/ [18] *1 Three phase 208/240/ [480] *1 Rated Voltage Single phase...

  • Page 9: Ambient Conditions

    2-2. Ambient Conditions Use this generator in ambient conditions as described below. Failure to provide these conditions can result in problems such as malfunction, insufficient output and reduced durability. Ambient temperature: 5 to 104 ° F (-15 to 40 ° C) ■...
  • Page 10 Radiator Plate Tie-Down Radiator Oil Separator * Shown with side-plate removed. Air Cleaner Coolant Sub-Tank Tie-Down Alternator Check Door Engine Check Door Oil Level Indicator Battery Oil Filter Fuel Tank Fuel Filter Fuel Pre-Filter Oil Filler Water Separator External Tank Fuel Inlet External Tank Fuel Return Oil Drain plug 3way fuel valve...

  • Page 11: Operation Panel Part Names

    4-2. Operation Panel Part Names ○ 3-Phase Circuit Breaker Engine Monitor Oil pressure/Water Temperature/Speed ○ 1-Phase Circuit Breaker Selector Switch ○ Voltｍeter Display Selector Switch ○ Amｍeter Available Output Monitor ○ Frequency Meter Fuel Meter ○ Pilot Lamp Hour Meter ○...

  • Page 12: Equipment

    Equipment 5-1. Available Output Monitor The available generated output for each output power source is displayed digitally. You can use the display selector switch to change the display in the following order: three-phase, single-phase three-wire U-W output, and single-phase three-wire U-N/G output. Three-phase output is constantly displayed when the engine is stopped.
  • Page 13 (1) WATER TEMP (Coolant Temperature) Warning Indicator (High Water Temp.) CAUTION: BURNS Do not open the radiator cap immediately after stopping the engine. Do so will result in hot steam gushing out. Hot steam gushes out from the coolant sub-tank if the generator overheats. Do not touch the coolant sub-tank.

  • Page 14: Meters And Gauges

    (5) AIR FILTER (Air Cleaner Clogging) Warning Indicator The AIR FILTER warning indicator lights up if the air cleaner element becomes clogged during operation. If it lights up, immediately stop the engine and clean or replace the air cleaner element. (Refer to section “10.
  • Page 15 (3) Fuel Meter Displays the amount of fuel in the internal fuel tank. When the tank is full, all lamps are lit up and FULL is displayed. The amount of lamps lit up decreases as the amount of fuel decreases as it approaches EMPTY. Add fuel immediately when only one lamp is displayed. The fuel meter on the control panel will only display the fuel level for the internal fuel tank.
  • Page 16 Switches (1) Starter Switch Breaker Trip 3-Phase 1-Phase STOP Selector Switch Breaker Breaker The engine is stopped and all power is cut off when in this position. The key can be inserted and removed when in this position. RUN/PREHEAT Position for operating the generator. It is also the position for air heater Am Meter Ｓtarter...

  • Page 17: Spill Containment

    < NOTE > If measuring the output current for a single-phase three-wire type, turn the ammeter selector switch to “L1+U” or “L3+W”. The voltage cannot be accurately measured if set to “L2”. Voltage Regulator/Engine Speed Switch (1) Voltage Regulator This dial is for regulating voltage output by the generator. Turn the dial clockwise to increase the voltage and counterclockwise to decrease it.

  • Page 18: Transporting/Installing

    < NOTE > When disconnecting piping from the external tank, turn the lever to the “A” side, and attach the included connecting hose to the external tank fuel inlet/return. (2) If using an external fuel tank: Pass the fuel hose from the external tank through the external fuel ports and connect to the external tank fuel inlet/return of the 3way fuel valve.

  • Page 19: Installation Procedures

    Lifting Tie-Down Hook < NOTE > Handle this generator with great care when raising, lowering and transporting. Roughly handling this generator can result in damage or malfunction. 6-2. Installation Procedures WARNING : EXHAUST GAS POISONING Do not operate the generator in poorly ventilated areas such as indoors or tunnels, as the exhaust gas of the engine contains substances that are harmful to human health.

  • Page 20: Load Connections

    Load Connections 7-1. Load Cable Selection CAUTION : PROPERTY DAMAGE Cable burnout can occur due to generated heat if the load current exceeds the allowable current of the cable. The voltage drop between cables is large if the cable is excessively long or thin, resulting in decreased input voltage to equipment using the generator, thereby causing decreased performance, faulty operation and malfunction.

  • Page 21: Connecting Load Cables

    7-2. Connecting Load Cables WARNING : ELECTRIC SHOCK Before connecting or disconnecting the load cables to/from the output terminal, always turn the output circuit breakers to the OFF position, stop the engine, and remove the ignition key. Close the output terminal cover before operating. Do not insert a pin, needle or other metal object into the electrical outlet.
  • Page 22 For single-phase load: Terminal voltage is 240/480 V. Load Load Load (2) Single-Phase Three-Wire Output Terminal and Receptacle For single-phase three-wire type load: U-W terminal voltage is 240 V. U-N/G terminal voltage is 120 V. W-N/G terminal voltage is 120 V. For single-phase 240 V load: For single-phase 120 V load: Load...
  • Page 23 Power available for use by each output terminal and receptacle are as show below. CON1 CON3 CON5 CON6 CON7 Load Load CON2 CON4 W-N/G Load Load Load Ｕ-W Ｕ-N/G Load Load Use is possible up to the kVA as shown below. 1-phase 240/120-V 1-phase 120-V receptacle 1-phase, 3-wire...

  • Page 24: Pre-Operation Inspection

    Pre-Operation Inspection WARNING : INJURY Always be sure to stop the engine and remove the engine key when performing inspection or maintenance. Do not open the check door during operation. Be careful of pinching or catching of moving parts such as the cooling fan and fan belt. CAUTION : BURNS Do not touch the engine and surrounding components immediately after stopping the engine as they are still hot.

  • Page 25: Checking Coolant

    (3) Engine Oil Replacement Amount Total Lubrication Oil Amount 3.5 (0.1) gal Value in parenthesis is the filter capacity. 8-2. Checking Coolant CAUTION : BURNS Do not open the radiator cap immediately after stopping the engine. Do so will result in steam gushing out. Hot steam gushes out from the coolant sub-tank if the generator overheats.

  • Page 26: Checking The Fan Belt

    Engine coolant could leak if the radiator is not completely tightened or there is a gap in the seating face. Always be sure to securely tighten the radiator cap. Do not add engine coolant past the FULL level line of the coolant sub-tank. (3) Coolant Amount Total Coolant Amount 3.3 (0.4) gal...

  • Page 27: Checking The Spill Containment

    < NOTE > The fuel injector pump, injectors and other parts of the fuel system and engine can be damaged if any fuel or fuel additives are used other than those specifically recommended by the engine manufacturer. Refer to the Engine Instruction Manual for the recommended Fuel Strainer Fuel Inlet fuels.

  • Page 28: Checking The Battery

    8-7. Checking the Battery CAUTION : EYE/SKIN INJURY Wear rubber gloves and other protective wear to protect eyes, skin and clothing from the battery fluid which contains diluted sulfuric acid. If the battery fluid contacts eyes or skin, wash out immediately with a large amount of water.

  • Page 29: Operating Procedures

    Operating Procedures 9-1. Initial Startup/Pre-Check WARNING : EXHAUST GAS POISONING Do not operate the generator in poorly ventilated areas such as an indoors or tunnels, as the exhaust gas of the engine contains substances that are harmful to human health. Do not direct exhaust fumes at bystanders or buildings.

  • Page 30: 240/480-V Switching Function

    After starting the engine, remove your hand from the starter switch. The engine idles for approximately five minutes. Turn the Throttle switch to RUN. Adjust the voltage regulator dial to the specified voltage. Turn the breakers to ON to start power transmission. 9-2.

  • Page 31: Procedures During Operation

    9-3. Procedures during Operation (1) Checks after Startup Make sure that all meters and indicators are in normal status. (Refer to section “5. Equipment”.) Check that there is no abnormal vibration or noise. Check that the exhaust gas color is normal. When operation is normal, the exhaust gas should be colorless or slightly bluish.

  • Page 32: Protective Functions

    9-5. Protective Functions WARNING : INJURY Do not open the check door during operation. Be careful of pinching or catching of moving parts such as the cooling fan and fan belt. Always be sure to stop the engine and remove the engine key when performing inspection or maintenance.

  • Page 33: Connecting With External Fuel Tank

    9-6. Connecting with External Fuel Tank CAUTION : FIRE Always make sure that the engine is stopped when working on piping. Always be sure to wipe up any spilled fuel. After working on the piping, check that there is no fuel leakage. Turn the 3way fuel valve lever to the 3Way Position A...

  • Page 34: Inspection/Maintenance

    10. Inspection/Maintenance WARNING : ELECTRIC SHOCK/INJURY Do not touch output terminals or internal electric parts while the generator is operating. Do not open the check door during operation. Be careful of pinching or catching of moving parts such as the cooling fan and fan belt. Always be sure to stop the engine and remove the engine key when performing inspection or maintenance.
  • Page 35 Every Every Every Every Every Every Every Every Description Daily 100 hrs 200 hrs 400 hrs 500 hrs 800 hrs 1000 hrs 1500 hrs 3000 hrs Each parts  (Clean/Tightening) Engine oil  (Check/Add)  Engine oil time at  (Replace) 50 hrs ...
  • Page 36 (1) Engine Oil Replacement First Time 50 hours Thereafter Every 200 hours Oil Level Indicator Remove the oil filler cap. Oil Filler Cap Remove the oil drain plug and drain the engine oil. Oil Filler After the oil has been drained, reinsert the oil drain plug with new packing.
  • Page 37 < NOTE > Inner air element must not be reused even if it is cleaned. Clip Replace the inner element when replacing the outer element. Always be sure to turn the cleaner cap in the direction indicated by the arrow. Air Cleaner Cap Replace the elements earlier if using in an excessively Air Cleaner...
  • Page 38 (5) Fuel Filter Replacement (Main and Pre-Filters) Replace Every 400 hours Remove the fuel filter using a filter wrench. Gasket Spread a thin layer of oil on a new fuel filter gasket. Thread the fuel filter by hand, and turn by hand (do not use a filter wrench) from when the gasket contacts the seal surface until it is securely tightened.
  • Page 39 Replace the packing of the coolant drain plug with new packing each time the coolant is changed. Packing part no.: 6C090-58961 (Kubota part no.) After reinserting the coolant drain plug and shortly after starting the engine, be sure to always check that there is no coolant leakage.
  • Page 40 (9) Spill Containment Cleaning/Inspection WARNING : INJURY Do not use the fuel tank lifting hook to suspend a gas tank that contains fuel, and do not suspend with the fuel tank and spill containment as a single unit. Doing so could result in the tank falling. Clean Every 500 hours Separate the spill containment from this generator to clean and inspect the spill containment.
  • Page 41 Lifting Hook Wire Connector Bolt Bolt Male Screw Fuel Tank Wire Connector Union Joint Fuel Line (Inlet Side) Fuel Line (Return Side) Spill Containment...

  • Page 42: Long-Term Storage

    (10) Oil Separator Filter Replacement Replace Every 1000 hours Remove the cover, and remove the O-ring and oil separator filter. Assemble a new O-ring to the cover and spread a thin layer of oil on the O-ring. Assemble a new oil separator filter and tighten the cover by hand. Loosen Tighten Oil Separator...

  • Page 43: Troubleshooting

    Clean and inspect the inside of the spill containment. (Refer to section “10. Inspection/Maintenance (9) Spill Containment Cleaning/Inspection”.) Remove the starter key and store in a secure location. Clean all generator components, and store in a dry and dust-free location. Also cover when storing so that rain cannot enter through the suction or exhaust ports.
  • Page 44 Inspect this generator when operation is poor to determine the fault/malfunction. Request the authorized distributor where the generator was purchased to perform maintenance if you cannot find any faults/malfunctions during inspection. Problem Suspected cause Action Starter motor 1. Battery output is weak 1.
  • Page 45 White smoke 1. Too much or too little oil to cylinder 1. Ask our distributor to repair comes out from 2. Water is interfused in fuel line 2. Drain water in water separator, fuel filter Muffler or fuel tank 3. Fuel injection nozzle is defective 3.

  • Page 46: Generator Circuit Diagram

    13. Generator Circuit Diagram...

  • Page 47: Engine Electrical Circuit Diagram

    14. Engine Electrical Circuit Diagram...
  • Page 48 ©2011...
