Wirecolours:
General (EU) USA
Blue White
Yellow/Green Yellow/Green
Brown Black
2-1-2.

Workspace Requirements

•
This unit should be situated away from heat sources such as heat registers or stoves.
•
The laminator's location or position should not interfere with its proper ventilation.
•
There should be enough space around the laminator to feed-in, exit, and trim mounted and/or
laminated images.
•
The background dust level must not exceed that found in a typical office/computer room
environment.
•
The work area should be level, flat, and well lit.
2-2.

Setup

Procedure:
1. Open the box, and lift the machine out (at least two persons necessary!). Grasp the machine 8"-
10" (200mm-250mm) from either side, at the bottom aluminum extrusions. Be careful: the
polyethylene bag is slippery!
2. Place the machine on the work area described under 2-1-2.
3. Remove the protective polystyrene foam end covers.
4. Remove the polyethylene bag.
5. Remove the protective sheet, placed between the rollers. To do this: push the knob, situated at
the right-hand side, fully inward, and rotate fully clockwise.
6. Check for damages.
7. Plug the power cable into the grounded outlet as described under 2-1-1. The machine will now
start and heat up.
Name
Neutral
Ground
Phase (Live)
2-2
Installation
February 2000
