Section 2.

Installation

2-1.

Preinstallation

The following requirements are applicable:
2-1-1.

Electrical Requirements

This unit should only be connected to a power supply outlet of the voltage, amperage, and frequency
marked on the rear panel. The laminator has a grounded plug (three prongs). To reduce the risk of
electrical shock, this plug is intended to fit only a grounded outlet of the proper amperage, and in only
one way.
The US versions of the ProSeal
European versions are provided with Euro appliance inlets (see also Section 8).
The electrical specifications of the machines are:
US version
EU version
The ProSeal machines must be installed next to the power outlet; extension cords are not to be
used. The plug and the outlet must be easily accessible by the operator.
For the US versions, there are two types of outlets (receptacles), shown below.
G
L
N L
NEMA 5-15R
Using 15 Amp Breaker Using 20 Amp Breaker
ProSeal 25
Note: T-slot is not applicable for
For both EU versions, in the UK, the following is applicable:
BS 1363 – 13A
wall receptacle:
Use the provided
BS 1363 plug
For both EU versions, mainland Europe, the following is applicable:
French
German, Netherlands
Belgium
Use the provided Schuko plug (10A).
T M
machines are provided with fixed powercables and NEMA plugs; the
ProSeal 25
110VAC/60Hz 12A
230VAC/50Hz 7A
G
N
NEMA 5-20R
ProSeal 44
Canada
Portugal, Spain
ProSeal 44
110VAC/60Hz 16A
230VAC/50Hz 9A
2-1
Installation
