- Page 1 PowerPlus Steam 2000W – VPW2S Powerful Pressure Washer with Steam Cleaning Function Pressure washer with a hygienic steam cleaning function perfect for BBQs, garden furniture and more. VPW2S vax.co.uk...
-
Page 2: Let's Talk Safety
• It is your responsibility to check the suitability of the surface to precautions be cleaned. Vax UK Ltd cannot be held responsible for damage caused. • Keep fingers, hair and loose clothing from moving parts and openings whilst using the pressure washer/steamer. - Page 3 • Always wear suitable clothing footwear and eye protection whilst using the pressure washer/steamer. • Always connect the water supply, remove the lance and Do’s squeeze the trigger to run water through the machine before switching the power on (pressure washer function). •...
- Page 4 This steam cleaner should not be used to clean electrical appliances. Always remove the mains plug from the socket and allow the steam cleaner to cool down completely before topping up with water Don’ts • Don’t leave the pressure washer/steamer unattended or running when not in use for more than 5 minutes without depressing the trigger.
- Page 5 • Don’t use the pressure washer/steamer on electrical components, damaged/ delicate paint surfaces, tyres, engines/motors. • Don’t use the pressure washer/steamer with incorrect voltage as this may result in damage or injury to the user. The correct voltage is listed on the rating label.
- Page 6 This pressure washer is designed to make outdoor cleaning tasks as effective and efficient as possible and this user guide will help you get the most out of your machine. Completing outdoor cleaning tasks using a Vax pressure washer will keep your outdoor items and surfaces cleaner for longer.
-
Page 7: Table Of Contents
Contents VPW2S Included with your machine Let’s talk safety Getting to know your machine Pressure hose Getting started Trigger handle Using your machine Taking care of your machine Lance Let’s talk technical What to do if it goes wrong Jet nozzle (Orange nib) Getting in touch Turbo nozzle... -
Page 8: Getting To Know Your Machine
Universal Detergent Wash & Protect Vehicle Detergent 1-9-133398-00 Voltage 220-240V~50Hz 1-9-133400-00 Patio & Decking detergent Wattage 2000W 1-9-133401-00 Cord length 5m Steam Brush x3 Weight 6.5kg 1-1-135755-00 vax.co.uk Subject to technical change without notice. To purchase consumables and accessories, please visit... -
Page 9: Getting Started
Getting started PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE CAUTION: Always make sure the trigger safety lock is in the ‘locked’ position when not in use or connecting/disconnecting the pressure hose. Always check water hose, pressure hose, lance and nozzle are not damaged, broken or worn before use. -
Page 10: Using Your Machine
Using your machine IMPORTANT: Always use an RCD (Residual Current Device) adaptor when using the pressure washer. CAUTION: Never aim the high pressured water jet at people, animals, plants, electrical components, wires or the pressure washer/steamer itself. Make sure the water supply is not on. Connect the water hose pipe to a Firmly push the water hose pipe with suitable water supply and turn the... - Page 11 Using your machine Choose an accessory nozzle. Firmly Connect the power cord to the mains push nozzle into the lance until it supply via the RCD adaptor. clicks and locks into place. Gently pull the nozzle to make sure it is locked and secure before use.
- Page 12 1 minute. IMPORTANT: When using solution only use Vax solution and make sure you follow the dilution instructions. Solution can only be dispensed when low pressure accessories such as the solution nozzle, (brush and rotary brush...
- Page 13 Using your machine IMPORTANT: Please refer to the surface manufacturer’s care recommendations before use. Test your surfaces by running the steam cleaner over a small hidden area, if no damage occurs continue cleaning. Not suitable for use on leather, wax, polished surfaces, acrylic surfaces, synthetic, velvet or steam/water sensitive materials - paint/outer surfaces of cars or porous surfaces.
- Page 14 Using your machine 1 Minute Plug in the power cord to the mains Push the On/Off switch to ‘II’ position Allow 1 minute for the steamer to supply via the RCD adaptor. to switch on. warm up. Press the safety lock on the steamer Squeeze the trigger in short bursts.
-
Page 15: Taking Care Of Your Machine
Taking care of your machine IMPORTANT: If using the pressure washer/steamer with water from a water butt, the water filter will require more frequent cleaning. Cleaning water filter Unscrew and remove water inlet Using pliers gently pinch and pull the connector. - Page 16 Taking care of your machine IMPORTANT: Before storing your pressure washer/steamer always make sure no water remains in the pressure washer/steamer, hose, lance, nozzle and water tank. Once the pressure washer/steamer is switched off and before removing the lance, nozzle or trigger handle always squeeze the trigger until no further water is released, to prevent frost damage.
-
Page 17: Let's Talk Technical
Let’s talk technical CAUTION: Before carrying out any maintenance make sure the pressure washer/steamer is switched off and unplugged from the mains. Removing a blockage from the lance and nozzle To remove the nozzle from the lance, Remove the lance from the trigger Insert nozzle cleaning tool into end press the nozzle release button on handle, firmly push and twist the... -
Page 18: What To Do If It Goes Wrong
What to do if it goes wrong Problem Solution • Check the ‘This pack contains’ panel on the box to make sure the part is included with your machine. There is an accessory missing. • Make sure the On/Off switch is set to the position ‘I’... - Page 19 What to do if it goes wrong • Lance and nozzle not attached. The lance and nozzle must be attached to the trigger handle for pressurised water to be produced. Why won’t my pressure • Hose may be blocked or kinked, check for leaks in the hose and clear washer/steamer reach any blockages.
- Page 20 Getting in touch * Calls are charged at the UK local rate. Please make a note of the serial number and model number of the pressure washer before calling. † Registration required. Terms and conditions apply, see vax.co.uk for details.
-
Page 21: Trigger Handle
Accessories Accessories Don’t forget your accessories! Order at: www.vax.co.uk/spares-and-solutions Universal detergent 1-9-133398-00 Universal detergent to aid the break down and removal of stubborn dirt, moss, and grime. Patio & Decking detergent 1-9-133401-00 Patio & decking detergent to aid the break down and removal of stubborn dirt from patio and decked areas. -
Page 22: Turbo Nozzle
Accessories Jet nozzle 1-9-133754-00 Jet nozzle to apply concentrated pressure to dislodge dirt and grime on all surface types. Turbo nozzle 1-9-133753-00 A high pressure turbo nozzle to blast away tough embedded dirt from high traffic areas. Patio cleaning set 1-9-133767-00 A large circular cased brush, supplied with an extension tube for cleaning concentrated areas quickly and efficiently. - Page 23 Notes...
- Page 24 Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. © 2014 All rights reserved. VAX®, VAX Lozenge, are trade marks or registered trade marks of Techtronic Floor Care Technology Ltd.
