LST GSA-45681-200 Specification Sheet

Detector Base Series 65
GSA-45681-200
• Suitable for automatic detectors in
conventional technology
• Screw terminals for secure
connection of multiple wires
• Terminals for connection of remote
indicator
• Mechanical theft protection can be
activated
Description
The Detector Base GSA-45681-200 is designed for the
easy connection of automatic detectors Series 65 in
addressable conventional technology. Due to its robust
multi-wire screw terminals, the detectors can be wired
with ease, thus achieving a secure and durable connec-
tion.
The base provides the possibility to easily connect an
Specifi cations
Ambient temperature
Relative humidity
Dimensions ø × H
Colour
Weight
Order number
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
external remote indicator, and has been designed for
surface mounting in dry rooms. For special applications
a range of accessories (for moist room, false ceiling or
fl ush installation) is available.
A mechanical theft protection of the detector can
optionally be activated at the detector base.
-20°C to +70°C (no condensation or icing)
10 – 95% (no condensation)
100 × 15 (mm)
white
50g
246021
Detector Base/Conv./60/65/Apo GSA-45681-200
A
GSA-45681-200_DBL_LST_EN_0804.PDF • PAGE 1
