LST FC600/BREL Specification Sheet

Relay Base Series FC600
FC600/BREL
• Suitable for automatic detectors in
conventional technology
• Relay output with dry changeover
contact
• Designed for indoor surface
mounting
• Terminals for connection of external
remote indicator
• Anti-tamper locking feature
Description
The detector base FC600/BREL is designed for the easy
connection of automatic detectors of Series FC600 in
conventional technology. Thanks to its robust sharable
connection terminals, the detectors can be durably wi-
red in secure screw joints with virtually no effort. The
base provides an easy connection option for an exter-
Specifi cations
Operating voltage
Current consumption
Contact rating
Ambient temperature
Relative humidity
Dimensions ø × h
Colour
Weight
Order number
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
nal remote indicator and is designed for wall mounting
in dry rooms. The integrated relay output with a dry
changeover contact is active when the detector is in
the alarm condition. By breaking out a plastic bolt in
the base, the detector that has been inserted can be
secured against unauthorized removal.
10 – 28VDC
max. 3µA (normal condition), 17mA (active)
1A at 30VDC
-30°C to +70°C
5 – 95% (no condensation)
111 × 27 (mm)
white
58g
246072
Detector Relay Base/FC600 FC600/BREL
A
FC600-BREL_DBL_LST_EN_0804.PDF • PAGE 1
