LST ES58-2 Specification Sheet

Safety Barrier
ES58-2
• Allows to create intrinsically safe
circuits
• Galvanic isolation of the detector line
voltage
• Connection of intrinsically safe
detectors
• Industrial plastic surface-mount case
• ATEX certifi ed
Description
The Safety Barrier ES58-2 for the galvanic isolation of
the detectors in the hazardous area serves for the de-
sign of an intrinsically safe electric circuit. The plastic
surface-mount housing allows to mount the safety bar-
rier near the hazardous area.
The built-in zener barrier limits the current and the vol-
tage of the detector line, as well as the electric energy
stored in the intrinsically safe circuit. The maximum
Specifi cations
Ignition protection
Ex classifi cation
Operating voltage
Quiescent current
Ambient temperature
Dimensions W × H × D
Colour
Weight
Approval
Order number
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
number of detectors depends on the country-specifi c
regulations and can be found in the Connection of De-
tectors.
Due to the galvanic isolation, the earth leakage moni-
toring can remain activated in the fi re detection control
panel. Thus, the installation can also be monitored in
the hazardous area.
intrinsically safe
EEx ia llC
Supply through the detector line voltage
approx. 5mA
-20°C to +60°C
120 × 160 × 90 (mm)
light grey, similar to RAL 7035
650g
BASEEFA98ATEX7343
228003
Safety Barrier/Conv. ES58-2
A
ES58-2_DBL_LST_EN_0805.PDF • PAGE 1
