Installing The Ink Cartridges - Brother DCP-130C Quick Setup Manual

5

Installing the ink cartridges

Warning
If ink gets in your eyes, wash them out with water
at once, and if irritation occurs consult a doctor.
1
Make sure that the power is turned on.
The LCD shows:
No Cartridge
2
Open the ink cartridge cover (1).
3
Pull all the lock release levers down and
remove the yellow protective part (1).
Note
Do not throw away the yellow protective part. You
will need it if you transport the machine.
4
5
1
1
Setting Up the Machine
Take out the ink cartridge.
Carefully remove the protective yellow cap (1).
1
Improper Setup
DO NOT touch the area shown in the
illustration below.
Note
If the protective yellow cap comes off when you
open the bag, the cartridge will not be damaged.
7
