Page 1: Fire Detection Control Panel Series Bc216
Fire Detection Control Panel Series BC216 User Manual Part A Description Operating Instructions Subject to change without notice... - Page 2 The pointing out of possible errors in the manual will be gratefully accepted by the authors. All brand names and product names used in this manual are trade names, sevice marks, trademarks, or registered trademarks of their respective owners. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/2...
-
Page 3: Table Of Contents
Description of the menu points ............37 HB216AE.SAM / 0130 / AN9161202... - Page 4 Periodic function tests ..............65 User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/4...
- Page 5 Index ................. . 72 HB216AE.SAM / 0130 / AN9161202...
- Page 6 User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/6...
-
Page 7: Introduction
User Manual Series BC216 / Part A Introduction Decades of research and development of LST in the field of fire detection control panel technology and the successful cooperation with renowned international test authorities led to the development of the new fire detection control panels BC216-1 and BCnet216 of LST. -
Page 8: Symbols And Type Fonts
Changes in the use of rooms or User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/8... -
Page 9: What To Do In Case Of A Fire Alarm
BC216-1 or BCnet216 by Labor Strauss Sicherungsanlagen- bau Ges.m.b.H. Wien (LST), or by persons being explicitly authorized by LST. The control panel has to be protected from moisture and damage of any kind. It is to be installed in a dry and clean room easy accessible to the safety personnel. -
Page 10: Standards, Ce-Labeling, Approvals
The fire detection control panels BC216-1 and BCnet216 have been approved by the test authorities in the following states: Austria: Prüfstelle für Brandschutztechnik des österreichischen Berufsfeuerwehrverbandes Germany: VdS Schadensverhütung GmbH., Zertifizierungsstelle (BCnet216: pending) Hungary: EMILABS GMBH. User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/10... -
Page 11: Warranty
A fire alarm, activated by automatic fire detectors that react to signs that are similar to those of fire but are caused by other agents, such as welding, steam, heat, etc. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/11 Chapter 1 • Introduction... - Page 12 BC216-1 or when using the fire detection control panel BCnet216 in each of BCnet sectional control panels, also more than two detectors can be combined to a "multiple detector" - dependency, still called "interdependence of two detectors" for simplicity. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/12...
- Page 13 The transmitting device alarms the public fire report post by us- HB216AE.SAM / 0130 / AN9161202 ZN5002/73/13 Chapter 1 • Introduction...
- Page 14 "multiple detector zone" - de- pendency, still called "two-zone dependency" for simplicity. User Person(s) who are responsible for the operation and the use of the fire detection system. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/14...
-
Page 15: Fire Detection Control Panel Series Bc216
Controls that are activated by the fire detection control panel can comprise single functions (e.g., switching off the ventilation) as well as elements combined to zones (e.g., several door closers in a fire area). HB216AE.SAM / 0130 / AN9161202 ZN5002/73/15 Fire brigade... -
Page 16: Typical Construction Of A Fire Detection System With Network Control Panel
BCnet sectional control panel it is connected to and is made via one or more therefore parameterized operable BCnet sectional control panels BC216-2. BC216-2 (A) BC216-2 User Manual Series BC216 / Part A BC216-2 BC216-3 HB216AE.SAM / 0130 / AN9161202 ZN5002/73/16... -
Page 17: Features Of The Fire Detection Control Panel Series Bc216
(e.g., the fire brigade) and to a country-specific fire brigade control unit, the optional Fire Brigade Interface is to be used. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/17 Chapter 2 • Fire detection control panel Series BC216... - Page 18 Remote maintenance is possible with an optional interface converter that connects the fire detection system to the Security System Manager (SAM) of LST. Automatic fire detectors are in steady contact with the air of the surveilled area. Due to the dirt in the air (e.g., dust), every detector will get dirty as time passes.
-
Page 19: Fire Detection Control Panel Bcnet216 (Network Control Panel)
BC216-1 or to the BCnet sectional control panels of a fire detection control panel BCnet216. The location of fire is identified by the zone number(s) dis- HB216AE.SAM / 0130 / AN9161202 ZN5002/73/19... -
Page 20: Acoustic And Optic Alarming Devices
42 in Chapter 4.7.9: "Displaying and operating transmitting devices - menu point [Transmit. device:]". The overall number of all transmitting devices is limited to 99 in a fire detection control panel BCnet216. User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/20... -
Page 21: Actuations
Series BC216, or with fire detection control panels BCnet216, also via gate- ways which are connected to the network. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/21 Chapter 2 • Fire detection control panel Series BC216... -
Page 22: Displaying And Operating Elements
ALARM. D EVIC E 1 On / o f f Silence buzzer Pan el reset Act iv at ed Fault/Disabled User Manual Series BC216 / Part A INFO-field INFO-button MENU-buttons ELEMENT-button NUMERIC keys RESET-buttons HB216AE.SAM / 0130 / AN9161202 ZN5002/73/22... -
Page 23: Info Field
Info-field - exemplary fire alarm with 5 current fire messages The first line displays the current alarm with the zone and element number. The second line displays the first text information for the zone of the current alarm. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/23 Kind of message... -
Page 24: Info'-Button
'Element'-button (the display shows "/") and entering the number of the element. For the installer: On the PC-keyboard, the 'Element'-button is represented by the dividing button of the numeric keypad ('÷'). User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/24... -
Page 25: Reset-Buttons
The function domain "notification of the fire brigade in case of fire" regionally is regulated differently. Therefore, the following list only presents the most important possibilities of this function domain of the fire detection control panel Series BC216. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/25 Chapter 3 • Displaying and operating elements... -
Page 26: Alarm. Device 1 - Field
(this repeating function is dependent on local re- quirements). The button 'On/off' is not assigned for general disablement of the alarming devices; User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/26... -
Page 27: Optional Led-Display Field
324 21.12.2002 08:33 DELAY.ACT 325 21.12.2002 08:36 AUTHORIZATION ON 326 21.12.2002 08:36 DISABLEM. 327 21.12.2002 08:36 ALARM.T 328 21.12.2002 08:36 AL-DEV.ACT.T 329 21.12.2002 08:36 ACTU.ACT.T HB216AE.SAM / 0130 / AN9161202 ZN5002/73/27 Chapter 3 • Displaying and operating elements 0002/014 1.Floor 0012 Loft Sirens Trans.dev.fire... - Page 28 46 in Chapter 4.7.12.10: "Printing - submenu point [Print-out]" and in the further parts of this User Manual. 0002 1.Floor User level User Manual Series BC216 / Part A Storage area HB216AE.SAM / 0130 / AN9161202 ZN5002/73/28...
-
Page 29: Basic Operation Of The Fire Detection Control Panels Series Bc216
Due to this, do not stay in authorization level 2 longer than needed for operation! Return to authorization level 1 immediately after completing the task, so that the disabled parts can be put into operation again. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/29 Chapter 4 • Basic operation of the fire detection control panels Series BC216... - Page 30 This level of authorization requires the opening of the control panel, special tools and pre- cise knowledge of the interactions of the software-modules. User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/30...
-
Page 31: Operations Using Single Buttons
For silencing and reactivating the primary alarming device authorization level 1 or 2 is required, de- pending on the parameterization of the control panel. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/31 Chapter 4 • Basic operation of the fire detection control panels Series BC216... -
Page 32: Alarm Delay Procedure Of The Primary Transmitting Device
Outside this time window, the timer switches directly to night-operation and fixes this condition. The switching times are entered on the control panel by the installer when putting the control panel into operation. User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/32... -
Page 33: Operations Using The Menu
Input of the numeric code for authorization level 2 As long as a numeric input is made in a main menu point of authorization level 1, it is evaluated as HB216AE.SAM / 0130 / AN9161202 ZN5002/73/33 Chapter 4 • Basic operation of the fire detection control panels Series BC216 '-buttons you scroll ring-shaped in the main menu. -
Page 34: Exiting The Menu
Unlimited operation of the control panel is facilitated by authorization level 2. Authorization level 3 is reserved for the installer of the fire detection system. User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/34... - Page 35 - independent of which menu point was called last. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/35 Chapter 4 • Basic operation of the fire detection control panels Series BC216...
-
Page 36: Entering And Exiting Authorization Level 2
Earlier activated devices are not put out of operation. By returning to authorization level 1 the parts are put back into operation again. User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/36... -
Page 37: Description Of The Menu Points
AL". Further information can be found starting page 55 in Chapter 5.2.5: "Fire alarm condition - spe- cial case: alarm in an interdependence of two detectors". HB216AE.SAM / 0130 / AN9161202 ZN5002/73/37 Chapter 4 • Basic operation of the fire detection control panels Series BC216 0003/029 1.ALARM... -
Page 38: Displaying Activated Actuations - Menu Point [Activated Actuations]
'-buttons (details see from page 58 in Chapter 5.5: 0003/018 2.ENERGY FAULT stand-by battery '-buttons (details see from page 61 in Chapter User Manual Series BC216 / Part A 0001 0003/029 '-buttons (details see from page 56 in HB216AE.SAM / 0130 / AN9161202 ZN5002/73/38... -
Page 39: Displaying Test Conditions - Menu Point [Test Conditions]
"0" - disable "1" - enable "2" - activate (for test purposes) "3" - test condition on. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/39 Chapter 4 • Basic operation of the fire detection control panels Series BC216 0003 '-buttons (details see from page 63 in... -
Page 40: Operating Single Elements Of Detector Zones
See from page 65 in Chapter 6.1.2: "Testing of detec- tors". By disabling and then enabling the detector you end the test condition of this detector. User Manual Series BC216 / Part A '-buttons or by menu-quick-operation, us- ÷ ") HB216AE.SAM / 0130 / AN9161202 ZN5002/73/40... -
Page 41: Displaying And Operating Actuations - Menu Point [Actuations:]
A disabled actuation or a disabled element of an actuation cannot carry out its purposes in case of an alarm. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/41 Chapter 4 • Basic operation of the fire detection control panels Series BC216 maint. -
Page 42: Operating Single Elements Of Actuations
Is a disabled transmitting device enabled while criteria for activation exist, it will be activated immediately. '-buttons or the menu-quick-operation, using numeric buttons: User Manual Series BC216 / Part A '-buttons or '-buttons or the menu-quick- HB216AE.SAM / 0130 / AN9161202 ZN5002/73/42... -
Page 43: Displaying And Operating Alarming Devices - Menu Point [Alarming Device:]
HB216AE.SAM / 0130 / AN9161202 ZN5002/73/43 Chapter 4 • Basic operation of the fire detection control panels Series BC216... -
Page 44: Menu Point [System]
'-buttons you can set the contrast of the LC-display in 10 steps, according to the position- ing of the control panel (viewing angle) and to local light conditions. Minimum requirement for this submenu point is authorization level 2. 0001/016 User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/44... -
Page 45: Correcting The Clock Time - Submenu Point [Clock Time Correction]
45 in Chapter 4.7.12.7: "Switching to summertime - sub- menu point [Winter/summertime]". The switch to standard time takes place at the set date at the time of 03:00 o'clock. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/45 Chapter 4 • Basic operation of the fire detection control panels Series BC216... -
Page 46: Displaying The Installed Componentries - Submenu Point [Componentries]
" (see from page 47 in Chapter 4.7.12.12: "Abort measured value print-out - submenu point [Stop measurement print-out:]"). This menu point is accessible in authorization level 2 and higher. The menu can be changed while the print-out is executed in the background. User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/46... -
Page 47: Repeating A Print-Out - Submenu Point [Repeat Print-Out]
2 or 3, depending on the current authorization level. (See from page 36 in Chapter 4.5: "Entering and exiting authorization level 2"). HB216AE.SAM / 0130 / AN9161202 ZN5002/73/47 Chapter 4 • Basic operation of the fire detection control panels Series BC216... -
Page 48: Operating The Control Panel By Using The Fire Brigade Control Unit
User Manual Series BC216 / Part A Operation on the control panel BC216-1 corresponds to the button "Panel reset" corresponds to the button "Silence buzzer" all alarming devices are silenced jointly all alarming devices are silenced jointly HB216AE.SAM / 0130 / AN9161202 ZN5002/73/48... -
Page 49: Operating Conditions Of Fire Detection Control Panels Series Bc216
By using the entries of the event memory, you can display events on the LC-display that have been terminated in the meantime (e.g., a temporary fault of a part of the system). HB216AE.SAM / 0130 / AN9161202 ZN5002/73/49 Chapter 5 • Operating conditions of fire detection control panels Series BC216... -
Page 50: Normal Condition
'-buttons, you can browse in an event-category (e.g., in all current alarms); by using 03.05.2002 16:32 User level User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/50... - Page 51 (See from page 39 in Chapter 4.7.7: "Displaying and operating detector zones - menu point [Zone:]"). HB216AE.SAM / 0130 / AN9161202 ZN5002/73/51 Chapter 5 • Operating conditions of fire detection control panels Series BC216 0003/029 1.ALARM...
-
Page 52: The First Operations On The Control Panel In Fire Alarm Condition
0003/029 first display 0016/020 press ' '-button 0003/010 0016/020 press ' '-button 0016/020 0016/020 press ' '-button 0003/029 you have arrived at the first display again 0016/020 User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/52... - Page 53 Parts of the system (e.g., actuations) that are disabled or have a fault, cannot cope with their assigned tasks. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/53 Chapter 5 • Operating conditions of fire detection control panels Series BC216...
-
Page 54: Resetting The Alarming Devices
Has, for example, the sign of fire not been reduced properly (e.g., for smoke detectors, by thoroughly ventilating a smoky room), a new alarm is activated after resetting. '-buttons. In these menu points you can scroll through the events by using the User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/54... -
Page 55: Fire Alarm Condition - Special Case: Alarm In An Interdependence Of Two Detectors
Actuation Nr. 4, actuation element Nr. 21 is displayed as the first activated actuation. The second and third lines contain text information regarding the actuation. Is no element-text available, the third HB216AE.SAM / 0130 / AN9161202 ZN5002/73/55 Chapter 5 • Operating conditions of fire detection control panels Series BC216 0004/021 1.ALARM... -
Page 56: Activating An Actuation In A Two-Zone Dependency
The message condition for technical messages is displayed on the control panel as follows: The yellow light-emitting diode 'Technical message' is illuminated. Condition User Manual Series BC216 / Part A '-buttons. Displaying (1st line) 1.ACTU.ACT 0004 1.ACTU.ACT 0004/021 1.TR-DEV.ACT 1.AL-DEV.ACT HB216AE.SAM / 0130 / AN9161202 ZN5002/73/56... -
Page 57: Resetting A Technical Message
LC-display that have been activated directly by other peripheral devices of the fire detection system. These messages are always "self resetting". Besides the displaying on the LC- HB216AE.SAM / 0130 / AN9161202 ZN5002/73/57 Chapter 5 • Operating conditions of fire detection control panels Series BC216 0005/011 '-buttons. -
Page 58: Fault-Message Condition
Have the parameters been set to transmit the current fault to a transmitting device for fault mes- sages, the red light-emitting diode 'Actuation activated' is illuminated to indicate that the transmit- ting device has been activated. 0011/029 1.FLT-ALARM 0012/028 <zone text1> <element text> User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/58... - Page 59 Fault in a detector zone (e.g., Nr. 3) for technical messages The transmitting of an alarm from the concerning detectors to the control panel is no longer ensured. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/59 Chapter 5 • Operating conditions of fire detection control panels Series BC216...
- Page 60 Condition Effect User Manual Series BC216 / Part A Displaying (1st line) 1.TECH.FLT 0003/005 1.FLT.FLT 0005 1.FLT.FLT 0005/014 1.ACTU.FLT 0002 1.ACTU.FLT 0002/018 1.TR-DEV.FLT 1.AL-DEV.FLT 1.SER-IF.FLT 1.SER-IF.FLT 0/02 1.LOOP.FLT 0001/012 1.EXTING.FLT 1.ENERGY FAULT 1.FAULT 1.FAULT HB216AE.SAM / 0130 / AN9161202 ZN5002/73/60...
-
Page 61: Disablement Condition
The disablement condition is displayed on the control panel as follows: The yellow light-emitting diode 'Disablement' is illuminated. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/61 Chapter 5 • Operating conditions of fire detection control panels Series BC216... - Page 62 Messages of the disablement condition '-buttons. Condition User Manual Series BC216 / Part A Displaying (1st line) 1.DISABLEM. 0004 1.DISABLEM. 0004/029 1.TECH.DIS 0003 1.TECH.DIS 0003/005 1.FLT.DIS 0005 1.FLT.DIS 0005/014 1.ACTU.DIS 0002 1.ACTU.DIS 0002/018 1.ACTU.DIS* 0002 1.TR-DEV.DIS 1.TR-DEV.DIS* 1.AL-DEV.DIS HB216AE.SAM / 0130 / AN9161202 ZN5002/73/62...
-
Page 63: Test Condition
(if available) is displayed. The fourth line is reserved for fire alarm messages. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/63 Chapter 5 • Operating conditions of fire detection control panels Series BC216... - Page 64 Displaying (1st line) 1.TEST COND 0004 1.TEST COND 0004/029 1.TECH.TEST 0003 1.TECH.TEST 0003/005 1.FLT.TEST 0005 1.FLT.TEST 0005/014 1.TEST-AL 0004 1.TEST-AL 0004/029 1.TECH.T-AL 0003 1.TECH.T-AL 0003/005 1.FLT.T-AL 0005 1.FLT.T-AL 0005/014 1.TR-DEV.TEST 1.AL-DEV.TEST 1.ACTU.TEST 0001 1.ACTU.TEST 0001/004 HB216AE.SAM / 0130 / AN9161202 ZN5002/73/64...
-
Page 65: Ensuring The Efficacy Of The System By The User
(one-man-maintenance). Make sure that you are activating only detectors that are in test condition! In addition, you can check on the executed activation of the detectors by reading the event memory subsequently. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/65 Chapter 6 • Ensuring the efficacy of the system by the user... -
Page 66: Testing The Alarming Devices
Make sure that all action data (e.g., fire prevention plans) are available in their latest edition for use in case of emergency. Should you find problems or have doubts during a test of your fire detection system, inform your maintainer. User Manual Series BC216 / Part A HB216AE.SAM / 0130 / AN9161202 ZN5002/73/66... -
Page 67: Reconditioning And Maintenance
Fire detection systems have to be serviced and - if necessary - reconditioned periodically by a qualified maintainer. Only specialized companies that are demonstrably periodically trained specifically for the functions of this specific fire detection system by LST or by persons being explicitly authorized by LST. -
Page 68: Event Memory - Entries
2 / element text zo. text 2 / element text fault cause zo. text 2 / element text fault cause zo. text 2 / element text zo. text 2 / element text HB216AE.SAM / 0130 / AN9161202 ZN5002/73/68... - Page 69 Test activation termination Alarming devices Activation Activation termination Disablement Enablement Fault Fault termination Test activation HB216AE.SAM / 0130 / AN9161202 ZN5002/73/69 Event text Text 2nd line FLT.TEST.T 0001/001 zone text 1 FLT.TEST 0001/001 zone text 1 ACTU.ACT 0001/001 actuation text 1 ACTU.ACT.T...
- Page 70 User Manual Series BC216 / Part A Text 3rd line Additional text (info-button) alarming device text 2 user level control unit fault cause fault cause fault cause fault cause fault cause fault cause fault cause fault cause HB216AE.SAM / 0130 / AN9161202 ZN5002/73/70...
- Page 71 At events which relate to a specific BCnet sectional control panel (e.g. "ENERGY FAULT") the third line of the LC-display shows the GSSnet member number of the corresponding BCnet sectional con- trol panel when using a network fire detection control panel BCnet216. HB216AE.SAM / 0130 / AN9161202 ZN5002/73/71 Event text Text 2nd line FAULT.T...
-
Page 72: Index
Reconditioning, 67 Remote maintenance, 18 Sectional control panel, 11, 17, 19, 29 - Operable, 22 Self-control, 10, 58, 65 Serial interface, 18, 21 Setting the parameters, 13 Signs of fire, 13 Siren output, 26 HB216AE.SAM / 0130 / AN9161202 ZN5002/73/72... - Page 73 - Of a transmitting device, 42 - Of an actuation, 41, 56 - Of an alarming device, 43 User, 7, 14 User code, 29, 30, 36 - At delivery, 47 - Change, 47 Warranty, 11 HB216AE.SAM / 0130 / AN9161202 ZN5002/73/73 Chapter 8 • Index...
