LST BC016-1 Specification Sheet

Fire Detection Control Panel
BC016-1
• For application in small and
mid-sized systems
• Addressable conventional technology
with up to 16 detector zones
• Menu-driven operation
• Free parameter setup via PC
software or operating fi eld
• Factory settings allow for easy
commissioning
• EN 54/VdS-certifi ed
Fire is a permanent threat to life and property. There-
fore, immediate response to a fi re is imperative. The
main objective of the fi re detection control panel Series
BC016 is to alarm and to react in time and, conse-
quently, save lives and protect property. For decades
LST have focused their aims to undertaking unrivaled
efforts in order to realize new innovations in the security
area. Research, development and production are loca-
Description
Already in the basic version the fi re detection control
panel BC016-1 is equipped with eight detector lines in
conventional technology and, owing to its sophisticated
factory settings, is immediately ready for operation.
This allows for quick and effi cient application of the
product. The control panel can be expanded from 8 to
16 detector zones by means of the Detector Zone Ex-
tension MGE8-1.
The addressable conventional technology allows for the
connection of automatic and non-automatic fi re detec-
tors as well as special detectors with contact output.
Unambiguous identifi cation of the activated detector in
the event of an alarm facilitates the indication of the
detector number on the control panel's display. Auxiliary
outputs whose parameters can be freely set allow also
for the realization and clear display of challenging tasks
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
ted within LST premises, thus guaranteeing fl exible and
reliable individual solutions.
Using a powerful processor system, display texts, and a
large number of integrated functions, the fi re detection
control panels Series BC016 ensure topmost effi ciency
and speed – prerequisites for saving lives and minimi-
zing damage to property.
in the fi eld of fi re alarm technology.
In addition, one slot each is available for a Fire Brigade
Interface and for a Serial Interface Module, respectively.
The Fire Brigade Interface FWI016-1 allows for the con-
nection of country-specifi c standardized fi re brigade
control units or for the expansion of the control panel
with additional inputs and outputs for general control
tasks.
Via the Serial Interface Module SIM216-1 you can
address either a PC for the effi cient and clearly laid out
parameterisation of the fi re detection control panel, or
a printer. The Serial Interface Module SIM016-3 serves
for the connection of INFO-bus devices such as fi re bri-
gade control units, remote display and operating pa-
nels, remote indication units, etc.
A
