LST Input/Output Module 55000-875 Specifications

Input/Output Module
55000-875
• ADM loop technology with
Apollo/Discovery protocol
• One line-monitored input and one
dry relay output 230VAC
• Setting of module address by means
of address switch
• Integrated dual-isolator
• Status LEDs for input and output
Description
The addressable Module 55000-875 serves for the line-
monitored integration of a contact detector, such as a
manual call point, a sprinkler system contact or a su-
pervising contact, into the bidirectional communication
on the ADM loop with Apollo/Discovery protocol. Fur-
thermore, it can be used to actuate external devices by
Specifi cations
Operating voltage
Current consumption
Contact rating
Ambient temperature
Dimensions L × W × H
Colour
Weight
Order number
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
means of a relay output with a dry change-over contact,
via the ADM loop.
The address is easily selected by means of a built-in DIL
switch. Status LEDs indicate the condition of input and
output. The module has an integrated dual-isolator and
is fi tted into a plastic case.
Supply through loop voltage
approx. 1.25mA (quiescent)
2A/48VDC or 5A/230VAC
-20°C to +70°C
150 × 90 × 48 (mm)
white
240g
249078
Module 1xSurv.In 1xRel.Out-230/Apo 55000-875
A
55000-875_DBL_LST_EN_0804.PDF • PAGE 1
