LST Conventional Zone Module GWM-55000-845 Specifications

Conventional Zone Module
GWM-55000-845
• ADM loop technology with
Apollo/Discovery protocol
• Integration of conventional detectors
into the ADM loop
• Setting of module address by means
of address switch
• Integrated dual-isolator
Description
The addressable Conventional Zone Module GWM-
55000-845 serves for the integration of conventional
detectors into the bidirectional communication on the
ADM loop with Apollo/Discovery protocol.
Specifi cations
Operating voltage
Current consumption
Ambient temperature
Dimensions L × W × H
Colour
Weight
Approval
Order number
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
The address is easily selected by means of a built-in DIL
switch. The module has an integrated dual-isolator and
is fi tted into a plastic case.
Supply through loop voltage
4mA (quiescent)
-20°C to +70°C
150 × 90 × 48 (mm)
white
230g
VdS G201094
249075
Conventional Zone Module/Anal./XP95/Apo GWM-55000-845
A
GWM-55000-845_DBL_LST_EN_0804.PDF • PAGE 1
