Program Intercom and Doorbell into Existing Network

Do not program the new intercom and doorbell to each other before adding them to the existing network or they will form a separate network and
the memory will need to be cleared. First, program the intercom to the existing network, then program the doorbell. Before beginning, ensure that all
intercom are on the same channel (refer to Channel Button in the Operation section).
INTERCOM
1
Press and hold the learn button on the
new intercom until a beep is heard.
2 Within 10 seconds press and hold the learn button on any
intercom in the existing network until a beep is heard. Wait until
all the lights go out on the intercom (it may take up to 3-1/2
minutes for a secure network to be established).
3
Test by holding the talk button on the
new intercom until a beep is heard. This
will initiate a call to the other intercoms
in the network. Press and hold the talk
button on any network intercom to
answer the call.
Repeat for any additional intercoms or doorbells.

Mount Doorbell

Choose a mounting location for the doorbell that is within range of the intercom(s) to ensure the doorbell will work properly. The doorbell can be
mounted using the provided screws or by using the double-sided mounting tape. It is recommended to use the mounting tape on surfaces such as
metal or glass.
MOUNTING WITH SCREWS
Mount doorbell with small silver
1
screws. Screw the top two screws
halfway into the mounting surface.
Place back of doorbell over screws.
Tighten screws.
Put the remaining silver screws
2
into the bottom holes of doorbell.
Tighten screws.

Secure Cover

1 Secure cover with the two large
black screws.
DOORBELL
1
To add the doorbell to the network,
press and hold the learn button
on any intercom in the existing
network until a beep is heard.
2
Within 10 seconds press and
hold the learn button on the new
doorbell until a beep is heard.
3
Wait about 30 seconds for the
intercoms to sync, then test by
pressing the call button on the
doorbell. The call will be heard on
the intercoms in the network. Press
and hold the talk button on any
intercom to reply.
MOUNTING WITH TAPE
Clean back of doorbell and mounting
1
surface using the alcohol wipe.
2 Peel off white paper from mounting
tape. Firmly press mounting tape on
back of doorbell.
Peel paper from mounting tape.
3
Firmly press doorbell onto mounting
surface.
